ribbon G5 Line Access Gateway R4.7 Interoperability Manual

Interop with zoom
Hide thumbs

Advertisement

Quick Links

Download this manual
Ribbon G5 Line Access Gateway R4.7 Interop with Zoom :
Interoperability Guide
Table of Contents
Interoperable Vendors
Copyright
Document Overview
Non-Goals
Audience
Prerequisites
Product and Device Details
Network Topology Diagram
Ribbon G5 Deployment Topology
Interoperability Test Lab Topology
Section A: Zoom Configuration
Section B: Ribbon G5 Configuration
1. G5 SIP using the CTG Cards
2. Connecting a PC/Laptop to a G5
System
3. Performing G5 Initial Provisioning
Procedure
4. Backing up the G5 Configuration
Caveats
Supplementary Services and Features
Coverage
Support
References
Conclusion
Confidential and Proprietary. Copyright © 2020-2023 Ribbon Communications Operating Company, Inc. © 2020-2023 ECI Telecom Ltd.

Advertisement

loading
Need help?

Need help?

Do you have a question about the G5 Line Access Gateway R4.7 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ribbon G5 Line Access Gateway R4.7

  • Page 1 2. Connecting a PC/Laptop to a G5 System 3. Performing G5 Initial Provisioning Procedure 4. Backing up the G5 Configuration Caveats Supplementary Services and Features Coverage Support References Conclusion Confidential and Proprietary. Copyright © 2020-2023 Ribbon Communications Operating Company, Inc. © 2020-2023 ECI Telecom Ltd.

  • Page 2: Document Overview

    Communications Inc. The trademarks, logos, service marks, trade names, and trade dress (“look and feel”) on this website, including without limitation the RIBBON and RIBBON logo marks, are protected by applicable US and foreign trademark rights and other proprietary rights and are the property of Ribbon Communications Operating Company, Inc.
  • Page 3 Figure 1: Ribbon G5 Deployment Topology Interoperability Test Lab Topology The following lab topology diagram shows connectivity between Zoom and Ribbon G5 LAG. Figure 2: Interoperability Test Lab Topology Confidential and Proprietary. Copyright © 2020-2023 Ribbon Communications Operating Company, Inc. © 2020-2023 ECI Telecom Ltd.

  • Page 4: Section A: Zoom Configuration

    The G5 shelf is a single 23" wide, 10 rack unit (RU) high shelf. The shelf includes a chassis, backplane, optional fan module, and 26 card slots which can be equipped as follows: Confidential and Proprietary. Copyright © 2020-2023 Ribbon Communications Operating Company, Inc. © 2020-2023 ECI Telecom Ltd.
  • Page 5 Common Language Location Identifier (CLLI) for the system. The TID can have a maximum of 20 ASCII characters. A null TID (that is, successive colons) can be used when the OS communicates directly with the Network Element. Confidential and Proprietary. Copyright © 2020-2023 Ribbon Communications Operating Company, Inc. © 2020-2023 ECI Telecom Ltd.
  • Page 6 If Tera Term is not available, use another terminal emulation program such as Putty or Secure CRT. 3. Click OK. cttf5000lf login: 4. Enter the following at the Linux login prompt and press Enter. cttf5000lf login: tl1s password: tl1s Confidential and Proprietary. Copyright © 2020-2023 Ribbon Communications Operating Company, Inc. © 2020-2023 ECI Telecom Ltd.
  • Page 7 HostName (or IP Address): [192.168.1.11] ssh tl1s@192.168.1.11 11. Press the semicolon ( ; ) key a few times to verify that the system is responding. Confidential and Proprietary. Copyright © 2020-2023 Ribbon Communications Operating Company, Inc. © 2020-2023 ECI Telecom Ltd.
  • Page 8 Address for use in step 7. 4. Click on the SOFTWARE link under Update in the upper left hand corner of the Web page. Figure 4: Software Update Confidential and Proprietary. Copyright © 2020-2023 Ribbon Communications Operating Company, Inc. © 2020-2023 ECI Telecom Ltd.
  • Page 9 6. When the Software download on the system completes, a window asking to select the Swap button will appear: Figure 6: Swap button Select OK. Confidential and Proprietary. Copyright © 2020-2023 Ribbon Communications Operating Company, Inc. © 2020-2023 ECI Telecom Ltd.
  • Page 10 7. After the Standby CTG card reboots, a window asking to click the Reset to complete the Update appears: Figure 8: Reset Select OK, then select the Reset button. Confidential and Proprietary. Copyright © 2020-2023 Ribbon Communications Operating Company, Inc. © 2020-2023 ECI Telecom Ltd.
  • Page 11 After the CTG and POTS cards are updated, issue a RTRV-EQPT command and verify that all of the cards in the system are in service (IS) and that the software is displayed correctly. Confidential and Proprietary. Copyright © 2020-2023 Ribbon Communications Operating Company, Inc. © 2020-2023 ECI Telecom Ltd.
  • Page 12 If the system will use the optional TLS/SRTP, use the command to set SSPORT=5061, and PROXY CERT, SSL CERT and SSLKEY to the customer provided certificates and key. Confidential and Proprietary. Copyright © 2020-2023 Ribbon Communications Operating Company, Inc. © 2020-2023 ECI Telecom Ltd.
  • Page 13 22. ENT-T0. Use the Enter T0 (ENT-T0) command to create a SIP Subscriber Identity on a POTS line. (Refer to Appendix F for SIP scripting.) For example: ENT-T0::1-2-1:9:::POTSLINETYPE=LS,POTSLINEIMP=900,RTLP=-6; ENT-T0::1-2-2:9:::POTSLINETYPE=LS,POTSLINEIMP=900,RTLP=-6; ENT-T0::1-2-3:9:::POTSLINETYPE=LS,POTSLINEIMP=900,RTLP=-6; ENT-T0::1-2-4:9:::POTSLINETYPE=LS,POTSLINEIMP=900,RTLP=-6; ENT-T0::1-2-5:9:::POTSLINETYPE=LS,POTSLINEIMP=900,RTLP=-6; ENT-T0::1-2-6:9:::POTSLINETYPE=LS,POTSLINEIMP=900,RTLP=-6; ENT-T0::1-2-7:9:::POTSLINETYPE=LS,POTSLINEIMP=900,RTLP=-6; Confidential and Proprietary. Copyright © 2020-2023 Ribbon Communications Operating Company, Inc. © 2020-2023 ECI Telecom Ltd.
  • Page 14 Reference the Network Engineering Specbook to determine if applicable. [G5] ED-DIALPLAN:[<tid>]:<aid>:<ctag>::<dialplan>[:DESC=<desc>]; For example: ED-DIALPLAN::DEFLT:ctag::STAR&STAR7&STAR10&POUND&SPECIAL&LOCALOP&LONGOP& 7DIGIT& LONGDIST&10DIGIT&INTL&ROUTINE&PRIORITY&IMMEDIATE&FLASH&FLASHOVR:DESC="North American Dial Plan"; Confidential and Proprietary. Copyright © 2020-2023 Ribbon Communications Operating Company, Inc. © 2020-2023 ECI Telecom Ltd.
  • Page 15 29. ssh tl1s@<IP Address> password: tl1s 33. Log back into the G5. [ G5] ACT-USER:: SUPERUSER:<ctag>::ADMIN.5; 34. RTRV-SHELF (Retrieve Shelf Information) Confidential and Proprietary. Copyright © 2020-2023 Ribbon Communications Operating Company, Inc. © 2020-2023 ECI Telecom Ltd.
  • Page 16 The Installation laptop may be used as the FTP server, but the backup file will need to be sent to the location specified by the customer. 3. Back up the database files. [5000LF] COPY-RFILE:::<CTAG>:::TYPE=BACKUPDB,UID=<"FTP Server UserID">,PID=<"FTP Server Password">,IPADDR=<FTP Server IP Address>,DEST="<FTP Server directory location>"; Ex. [5000LF] COPY-RFILE:::9:::TYPE=BACKUPDB,UID="admin",PID="password", IPADDR=10.123.2.1,DEST="/database/5000lf"; Confidential and Proprietary. Copyright © 2020-2023 Ribbon Communications Operating Company, Inc. © 2020-2023 ECI Telecom Ltd.
  • Page 17 Basic Call Setup Basic Call Termination Call Hold/Resume Call Transfer - Blind (Cold transfer) Call Transfer - Consult (Warm transfer) Conference Group Call Pickup Call Park Confidential and Proprietary. Copyright © 2020-2023 Ribbon Communications Operating Company, Inc. © 2020-2023 ECI Telecom Ltd.
  • Page 18 Conclusion This Interoperability Guide describes a successful configuration covering Zoom interop involving the Ribbon G5 LAG. All the necessary features and serviceability aspects stand covered as per the details provided in this interoperability document. All features and capabilities tested are detailed within this document - any limitations, notes or observations are also recorded in order to provide the reader with an accurate understanding of what has been covered, and what has not.
