Summary of Contents for Tekneka 170
-
Page 2: Table Of Contents
TEK170/en_V0.1 OIL TESTER MANUAL Table of Contents 2.Safety ..................3 3.Technical Specification.............. 4 4.Measurements................5 4.1 The Effect of Additives............5 4.2 Contrast with Laboratory Methods..........5 4.3 Measuring................5 4.4 Start Measuring..............6 4.5 Please follow the points below to get the most accurate results in the meaurement .............. - Page 3 OIL TESTER MANUAL 1. Introduction The Tekneka 170 is a deep-frying oil tester that helps you determine the quality of frying oil with a measuring range of 0 to 40% TPM. It can also measure temperatures from 30 to 200°C (86 to 392°F).
-
Page 4: Safety
• The appliance should be cleaned with a damp cloth after each use. Use only pH-neutral cleaner, no abrasives or solvents. • The device must only be used with accessories from TEKNEKA or equivalent. • When the frying oil tester is not used for a longer period of time, remove the batteries. -
Page 5: Technical Specification
We do not assume liability for printing errors or any other mistakes in this manual. We expressly point to our general guarantee terms, which can be found in our general terms of business. If you have any questions, please contact info@tekneka.com. The contact details can be found at the end of this manual. -
Page 6: Measurements
TEK170/en_V0.1 OIL TESTER MANUAL 4. Measurements • Oil testers can achieve rapid continuous measurement, so after the completion of a measurement, without waiting for the next direct measurement, they can carry out another. What kind of oil I grease can this instrument apply to? •... -
Page 7: Start Measuring
TEK170/en_V0.1 OIL TESTER MANUAL 4.4 Start Measuring 1. Press the Power [ ] button and release It. 2. The temperature bar shows “LO” 3. TPM measurement shows - - - 4. Press the HOLD button in the measurement mode to activate the HOLD mode 5. -
Page 8: Configuration Options
TEK170/en_V0.1 OIL TESTER MANUAL • Press [◄] or [ ►] to enable or OFF Auto power off option • Press [Hold] to confirm. 1. LED colour code indication (LEO) mode • Press [◄] or [ ►] to turn the LED on or off. •... -
Page 9: User Calibration
TEK170/en_V0.1 OIL TESTER MANUAL 8. User calibration 1. Heat the calibration oil to about 50°C. 2. After entering the user calibration immerse the sensor into the calibration oil, pay attention to the depth of invasion. 3. When the TPM value shown in the table is stable, short press [◄] or [ ►] to increase /decrease the measured value by increments 0.5 %TPM 4. - Page 10 Copyright © 2023 Tekneka, Canada. All rights reserved including the right of reproduction in whole or in part in any form info@tekneka.com www.tekneka.com TEK170/en_V0.1...
