Summary of Contents for Oasis Berco Oasis Linear Duo
- Page 1 Space to think PODS (Duo, Small Team & Large Team) GLAZED REAR WALL SAFETY AND INSTALLATION INSTRUCTIONS Updated March, 2019 www.oasis-berco.com...
-
Page 2: Important Safety Instructions
Oasis Berco Installation, Operating & Safety Instructions Linear & Soft Pod, Booth and Hub • All Oasis Berco products are intended for commercial use. • Please note that specific installation drawings and instructions are provided at the end of this document. -
Page 3: Grounding Instructions
Space to think GROUNDING INSTRUCTIONS This product is for use on a nominal 120-volt circuit and has a grounding plug that looks like the plug illustrated in the sketch below. Make sure that the product is connected to an outlet having the same configuration as the plug. - Page 4 Space to think Tools needed for assembly: Before you start: • 3.5MM Allen Wrench Read instructions and check that all parts are accounted for • Torx – 30 driver bit before you start building. • #2 phillips driver bit 2. Begin assembly as close to final product location as possible. •...
- Page 5 Space to think Install the side walls. Place the panel with the grommet hole in the bottom to the side where you want the power cord to exit. Secure each wall to the corner posts using 8 – ¼ x 20 x 2” machine screws. Use Allen wrench to adjust the glides in each of the corners to level the unit.
- Page 6 Space to think Make sure the structure is square and all panels line up with the top posts and frame headers. Tighten all bolts once all is square. Install the door side glass panels into position. Be careful not to set the glass on a corner or it will chip or break.
- Page 7 Space to think Install the rear glass panels. Be careful not to set the glass on a corner or it will chip or break. You can install from either inside or outside the Pod. Lift one panel into the top groove and slide down into bottom groove. iii.
- Page 8 See Electrical Troubleshoot section at the end of this document. If all connections are secure, please contact Oasis Berco at 888-772-4788 and ask for Dave Dunn or James Holborow in Engineering. Secure the ceiling panel using 4 - #8 x 1 ½” wood screws from the hardware kit.
- Page 9 Space to think To finish the ceiling lift the white ceiling cover into position with the air inlet towards the left of the booth. Attach the fan cover over the air inlet and secure with 4 - #8 x ¾” wood screws from the hardware kit.
- Page 10 Space to think Hang the glass door panel. Adjust the top hinge to make sure the glass sits even in the frame. Install the door handle from the hardware kit. With the door in a closed position make sure the door is square and the gaps are even. The side glass panels may need to be moved to even the gaps.
- Page 11 Space to think Test the door again to make sure the closing speed is working properly. If the door needs adjustment, see instructions at the end of this document. Give the booth a final clean on the all painted profiles, glass & work surface. Remove the film covering that is protecting the threshold.
- Page 12 Space to think OPTIONAL PEDESTAL TABLE Tools needed for assembly: Before you start: • #2 Phillips Screwdriver/Bit Read instructions and check that all parts are accounted for before you start building. 2. Begin assembly as close to final product location as possible. Additional assembly instructions may be required depending on Hardware/Accessory Kit: specification of product ordered.
- Page 13 Space to think OPTIONAL SOFA Tools needed for assembly: Before you start: • None Read instructions and check that all parts are accounted for before you start building. 2. Begin assembly as close to final product location as possible. Additional assembly instructions may be required depending on Hardware/Accessory Kit: specification of product ordered.
-
Page 14: Door Adjustment
Space to think DOOR CLOSING SPEED ADJUSTMENT CRL 380 HYDRAULIC PATCH HINGE PATCH HINGE INSTALLATION (CONTINUED) DOOR ADJUSTMENT 8. Adjust the closing speed. )LJ Adjustment of closing speed: Valve No. 2 -Two regulating valves (No. 1) and (No. 2) Decrease closing speed Valve No. - Page 15 Space to think ELECTRICAL TROUBLESHOOTING www.oasis-berco.com...
