DAST5040Li
Lithium snowblower
USER'S MANUAL
www.daewoopowerproducts.com
Manufactured under license of Daewoo International Corporation, Korea

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DAST5040Li and is the answer not in the manual?

Questions and answers

Summary of Contents for Daewoo DAST5040Li

  • Page 1 DAST5040Li Lithium snowblower USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...

  • Page 2: Table Of Contents

    INDEX 1. SYMBOLS MARKED ON THE PRODUCT ..................... 2 2. GENERAL SAFETY RULES ........................3 3. GENERAL IDENTIFICATION ........................5 4. TECHNICAL DATA ........................... 6 5. ASSEMBLY .............................. 7 6. ADJUST DISCHARGE DIRECTION AND HEIGHT ................9 7. STARTING .............................. 10 8.

  • Page 3: Symbols Marked On The Product

    WARNING: For your own safety please read this manual before attempting to operate your new unit. Failure to follow instructions can result in serious personal injury. Spend a few moments to familiarize yourself with your snow thrower before each use. 1.

  • Page 4: General Safety Rules

    2. GENERAL SAFETY RULES The purpose of the safety rules is to attract your attention to possible dangers. The safety symbols and the explanations with them, require your careful attention and understanding. The safety war- nings do not by themselves eliminate any danger. The instruction or warnings they give are not substitutes for proper accident prevention measures.
  • Page 5 Operation 1. Do not put hands or feet near or under rotating parts. Keep clear of the discharge opening at all times. 2. Exercise extreme caution when operation on or crossing gravel drives, walks, or roads, stay alert for hidden hazards or traffic. 3.

  • Page 6: General Identification

    22. Be careful during adjustment of the machine to prevent entrapment of the fingers between moving auger and fixed parts of the machine. 23. Never pick up or carry an appliance while the motor is running. 24. Recharge only with the charger specified by the manufacture .Using a charge with an incompati- ble battery pack may create a risk of fire.

  • Page 7: Technical Data

    4. TECHNICAL DATA Model DAST5040Li Rated voltage : 40V d.c. Auger speed: 2600/min Working height: 270mm Working width: 460mm Auger diameter: 180mm LED light: Yes Snow discharge angle range: 190° Net weight: 19.5 kg Degree of protection against liquid IPX1 Sound pressure level at the operator’s position: 67.3dB(A) K=3 dB(A)

  • Page 8: Assembly

    5. ASSEMBLY 5.1 Assemble the folding handle 1. Connect the lower handle (2-1) and middle handle (2-2) with the bolts (2-3, M8*52), washers (2-4) and locking knobs (2-5). ( Fig. 2A/2B/2C) 2. Connect the upper handle and middle handle with bolts (2-3, M8*52), washers (2-4) and locking knobs (2-5).
  • Page 9 5.3 Assemble the isolator key Insert the isolator key into the slot. （ Fig. 4) Fig. 4 5.4 Assemble the direction adjustment lever 1. Insert the upper lever (5-2) through the hole of the rubber protector (5-1). (Fig. 5A ) 2.

  • Page 10: Adjust Discharge Direction And Height

    Fig. 6A Fig. 6B Fig. 6C 5.6 Remove the battery 1. Lift and hold up the battery door. 2. Press and hold the battery latch button (7-1) at the bottom of the battery pack. 3. Remove battery pack from the product. Fig.

  • Page 11: Starting

    Fig. 8A Fig. 8B Fig. 8C Fig. 8D Fig. 8E 7. STARTING 7.1 Starting Switch on the isolator key. Start the motor as follows (Fig. 9): a) Press the safety push-button (1). b) And meanwhile, pull the the switch handle (2), and keep it in grasp. Lift the front of the machine and switch off isolator key while crossing gravel or roads surface.

  • Page 12: Maintenance And Care

    Switch mark”I” is “ON”, “O” is “OFF”. WARNING: Do not irradiate on the eyes of the bystanders. WARNING: Always ensure that the ventilation openings are kept clear of debris. 8. MAINTENANCE AND CARE 1. After use, switch off the isolator key and remove the battery pack and check for damage. 2.

  • Page 13: Environmentally Friendly Disposal

    10. ENVIRONMENTALLY FRIENDLY DISPOSAL According to EU directive 2012/19/EU on electric and electronic equipment and its implementation into national law, all electric tools must be separately collected and environmentally friendly recy- cled. Alternative disposal: If the owner of the power tool does not return the tool to the manufactu- rer, he is responsible for proper disposal at a designated collection point that prepares the device for recycling according to national recycling laws and regulations.

  • Page 14: Warranty

    WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 1 year for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed.
  • Page 15 Manufactured under license of Daewoo International Corporation, Korea...
