Ruian BoYu Automobile Parts BYMLX26 User Manual

1. General Description

Tire pressure sensor is composed of RF chip, battery, antenna and
matching network. It is applied to monitor tire pressure, temperature and
acceleration and the tire data is transmitted via center frequency
433.92MHz/.

2. Operation Functions

Transmitter ID Programming:transmitter ID can be progranmmed for easy
replacement
Alarm Record Inquity:automatically record the 10 alarm records
Standard Pressure Programming: standard pressure for each tire can be
programmed on monitor

3. Product Features

Powerful functions including low pressure alarms in 3 levels,fast leak alarm
and standard pressure setting etc.
Monitor connects to continuous power to ensure full-time monitoring
Design of the whole system matches the rtuck perfectly
Simple operation for function programming and inquiry

Installing structure

4.
TPMS Sensor
User manual
Rf
1. Valve rod
2. cushion
3. nut
4. valve cap
