- Page 1 IF00427.0 Livit Base Cabinets Installatiehandleiding | Installation manual | Manuel d’installation | Montageanleitung | Návod k instalaci | Instrukcja instalacji | Telepítési kézikönyv | Руководство по установке...
- Page 2 IF00427.0...
- Page 3 IF00427.0 Supply and discharge dimensions (mm) Glaze Top Velvet Slim 600/800/1000/1200 600/800/1000/1200 680 755 Velvet Top Stone Slim 600/700/800/1000/1200 600/800/1000/1200 745 820 Stone Top Washbowls 600/700/800/1000/1200...
- Page 4 IF00427.0 1. Check supply & discharge dimensions 2. Measure & mark wall brackets W - 38 900 - 40 - H H = Height Washbasin W = Width Base Cabinet 3. Drill holes & insert wall plugs 4. Mount wall brackets Ø8 5.
- Page 5 IF00427.0 7. Insert drawers back into the cabinet 8. Adjust & level drawers 1. Pull out sliders & 2. Gently push drawer & place drawers on top pull slider until click sound 9. Place washbasin/countertop & seal 10. Finish sealing 11.
- Page 6 IF00427.0 13. Place washbowl 14. Seal washbowl 15. Attach pop-up & siphon (Washbasin) 16. Attach pop-up & siphon (Washbowl) Only for non-intergrated overflow Turn anti-clock wise to remove. 17. Remove inner box (In Between cabinet) Turn clock-wise to fixate.
