Summary of Contents for Melec LOX
-
Page 3: Product Information
• Maintenance Free connections • Fast & easy snap install • Fits up to 4mm cable year warranty TECHNICAL INFORMATION Data subject to change, please visit our website for upto date specifications: melec.com.au ML-LOX-4-2J ML-LOX-4-3J ML-LOX-4-5J Solid conductor 0.2-4mm2 / 24-12AWG Stranded conductor 0.2-4mm2 / 24-12AWG... - Page 4 INSTALLATION GUIDE 1. Strip the wire back by 11mm. 2. Lift up the lever of the LOX connector to open the port. 3. insert the wire ensuring that it is pushed all the way in. 4. After the wire is inserted, push the lever back down. Repeat steps 1 to 3 for additional connections. To remove the wire push the lever up and pull the wire back out.
- Page 5 F F R R E E E E O O N N S S I I T T E E W W A A R R R R A A N N T T Y Y F F O O R R 3 3 Y Y E E A A R R S S I I N N C C L L U U D D E E S S P P A A R R T T S S &...
