Summary of Contents for Blizzard infinipix SPEKTRO
- Page 1 Blizzard Lighting, LLC http://www.blizzardpro.com Waukesha, WI USA Copyright (c) 2022...
-
Page 2: Table Of Contents
Control Panel Menu Structure DMX Values In-Depth Static Color Values Built-In Program Values Dimensional Drawings 5. Appendix Keeping Your Infinipix™ Spektro As Good As New Returns (Gasp!) Shipping Issues Page 2 Infinipix™ Spektro Manual Rev. A © 2022 Blizzard Lighting, LLC... -
Page 3: Getting Started
We’ll be happy to help, honest. Disclaimer: The information contained in this document are subject to change without notice. Blizzard Lighting™ assumes no responsibility or liability for any errors or omissions that may appear in this user manual. -
Page 4: Safety Instructions
Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please open a support ticket at www.blizzardpro.com/support. Page 4 Infinipix™ Spektro Manual Rev. A © 2022 Blizzard Lighting, LLC... -
Page 5: Meet The Infinipix™ Spektro
Program Speed Strobe Block 1 Red, Green, Blue 19-21 Block 7 Red, Green, Blue 1-28 Static Colors Section 1 Red, Green, Blue 82-84 Section 28 Red, Green, Blue Page 5 Infinipix™ Spektro Manual Rev. A © 2022 Blizzard Lighting, LLC... -
Page 6: Infinipix™ Spektro Pin-Up Picture
Section 2 Section 1 Figure 2: Rear Connections DMX IN DMX OUT DMX IN DMX OUT POWER IN POWER OUT 5-pin DMX In/Out 3-pin DMX In/Out Power In/Out Page 6 Infinipix™ Spektro Manual Rev. A © 2022 Blizzard Lighting, LLC... -
Page 7: Setup
Neutrik AG, Neutrik USA and their related entities, however they are not manufactured by, affiliated with or endorsed by Neutrik AG, Neutrik USA, or any related entity. Neutrik® and powerCON® are registered trademarks of Neutrik AG. Page 7 Infinipix™ Spektro Manual Rev. A © 2022 Blizzard Lighting, LLC... -
Page 8: Cable Connectors
Place a DMX Next terminator on the output of the final fixture to Fixture in Chain ensure best communication. DMX IN DMX OUT Page 8 Infinipix™ Spektro Manual Rev. A © 2022 Blizzard Lighting, LLC... -
Page 9: Assembly Instructions
To mount the fixture, use a suitable "C" or "O" type clamp. The clamp should be rated to hold at least 10x the fixture’s weight to ensure structural stability. Do not mount to surfaces of unknown strength, and ensure properly rated rigging is used. Page 9 Infinipix™ Spektro Manual Rev. A © 2022 Blizzard Lighting, LLC... -
Page 10: Operating Adjustments
To return to the previous option or menu without changing the value, press the <MENU> button. Page 10 Infinipix™ Spektro Manual Rev. A © 2022 Blizzard Lighting, LLC... -
Page 11: Control Panel Menu Structure
000 <-> 255 Built-In Effects (see Built-In Program Values on p.14) 000 <-> 255 Static Colors (see Static Color Values on p.14) 000 <-> 255 Program Speed (slow <-> fast) Page 11 Infinipix™ Spektro Manual Rev. A © 2022 Blizzard Lighting, LLC... - Page 12 000 <-> 255 Section 12 000 <-> 255 Section 26 000 <-> 255 Section 13 000 <-> 255 Section 27 000 <-> 255 Section 14 000 <-> 255 Section 28 Page 12 Infinipix™ Spektro Manual Rev. A © 2022 Blizzard Lighting, LLC...
- Page 13 000 <-> 255 Section 28, Red 000 <-> 255 Section 14, Blue 000 <-> 255 Section 28, Blue 000 <-> 255 Section 14, Green 000 <-> 255 Section 28, Green Page 13 Infinipix™ Spektro Manual Rev. A © 2022 Blizzard Lighting, LLC...
-
Page 14: Static Color Values
189 <-> 191 Sound 1 060 <-> 062 Effect 20 126 <-> 128 Effect 42 192 <-> 255 Sound 2 Dimensional Drawings 62.5" (158.5 cm) 5.2" (13 cm) Page 14 Infinipix™ Spektro Manual Rev. A © 2022 Blizzard Lighting, LLC... -
Page 15: Appendix
104 degrees F (40 degrees C) ambient Control Protocol USITT DMX-512, RDM DMX Channels 3/4/5/7/21/28/84-channel DMX modes Input/Output 3/5-pin XLR Male/Female Other Operating Modes DMX512, M/S, standalone, auto, sound active Warranty 2-year limited warranty Page 15 Infinipix™ Spektro Manual Rev. A © 2022 Blizzard Lighting, LLC... - Page 16 Enjoy your product! Our sincerest thanks for your purchase! --The team @ Blizzard Lighting...
