Shenzhen Hongdian Technologies H8922SS User Manual

4g intelligent gateway
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
www.hongdian.com
User Manual
4G Intelligent Gateway

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H8922SS and is the answer not in the manual?

Questions and answers

Related Manuals for Shenzhen Hongdian Technologies H8922SS

Summary of Contents for Shenzhen Hongdian Technologies H8922SS

  • Page 1 www.hongdian.com User Manual 4G Intelligent Gateway...
  • Page 2 3G/4G/5G Router User Manual We Hongdian provide full support to customers, contact us freely if any questions. Hongdian Corporation Tower A, Hongdian Building, 100 Huabao Road, Pinghu, Longgang District, Address Shenzhen, China Website http://www.hongdian.com Technical Support +86-0755-88864288-4 Fax number 0755-83404677 Postalcode 518112 Copyright ©...

  • Page 3: Table Of Contents

    3G/4G/5G Router User Manual Contents 1 The Configuration of Router......................About this chapter..............................Overview..................................1.1 Basic configuration............................... 1.1.1 Logging in to the WEB Configuration Page....................1.2 Network settings..............................Overview................................1.2.1 LAN................................1.2.2 WAN................................1.2.3 Modem................................ 1.2.4 WLAN................................1.2.5 Parameter select (Recommend to Single module dual SIM version)............1.2.6 Network type..............................
  • Page 4 3G/4G/5G Router User Manual 1.4.5 Anti-attack..............................1.5 Forward configuration............................Overview................................1.5.1 NAT................................1.5.2 Routing Configuration..........................1.5.3 QoS................................1.5.4 Dynamic Routing (Optional)........................1.6 VPN configuration..............................Overview................................1.6.1 VPDN configuration............................ 1.6.2 Tunnel configuration........................... 1.6.3 IPSec configuration............................. 1.6.4 Open VPN Configuration..........................1.6.5 DMVPN Configuration..........................1.6.6 EOIP Configuration............................
  • Page 5 3G/4G/5G Router User Manual 2.5 Schedule................................3 FAQ/Exception handling......................... About this chapter..............................3.1 Hardware Failure..............................3.1.1 All LED off..............................3.1.2 SIM Slot............................... 3.1.3 Ethernet Connection........................... 3.1.4 Antenna Connection........................... 3.2 Dial Online Problem............................. 3.2.1 Dial discontinue............................3.2.2 No Signal..............................3.2.3 Cannot find SIM/UIM card.......................... 3.2.4 Poor Signal..............................

  • Page 6: The Configuration Of Router

    3G/4G/5G Router User Manual The Configuration of Router About this chapter Section Brief Introduction of Contents 5.1 Overview the configuration of the 4G Intelligent Gateways in the WEB mode is introduced in this section briefly . 5.2 basic configuration what the 4G Intelligent Gateways need to complete before performing advanced configuration is introduced in this section briefly.

  • Page 7: Basic Configuration

    3G/4G/5G Router User Manual 1.1 Basic configuration Through the "5.2.2 Network Settings", you can realize the basic functions of dial-up Internet access and access to the public network. 1.1.1 Logging in to the WEB Configuration Page Step 1 Open the Internet Explorer browser of the configuration computer and enter "http://192.168.8.1/"...

  • Page 8: Network Settings

    3G/4G/5G Router User Manual ---END 1.2 Network settings Overview The network settings mainly complete LAN, WAN, WLAN, mobile network, parameter selecting, network type, link backup, DHCP server and other configurations. After the configuration is completed, the basic network communication needs can be met. 1.2.1 LAN The LAN port configuration is mainly used for the connection between the router and the lower device, so that the lower device can access the external network through the router, and at the same time ensure...

  • Page 9: Wan

    3G/4G/5G Router User Manual Table 1-1 The instruction of LAN Parameter Parameter Details Operation Host name The name of router Manual input, Maximum length limited to 32 word type character,Please refer to the “Parameter Specification Table” for input specifications. IP1~4 Used to divide subnets, these Enter it manually.
  • Page 10 3G/4G/5G Router User Manual Figure 1-1 The page of WAN Step 3 Configure the connection type of the WAN port The parameter description is shown in Table 5-2. Table 1-1 The instruction of WAN connection type parameter Parameter Details Operation Dropdown List Selection: Static IP:manually configure the IP address of the ...
  • Page 11 3G/4G/5G Router User Manual Parameter Details Operation "Static IP". input specifications. example: 192.168.10.1/24 “Connection Type” select “DHCP” get IP address from DHCP Select DHCP “Connection Type” select “PPPoE” The unique identifier of PPPoE is not configurable. an interface. It is used The interface name of the PPPoE configured on the when other functions are web page is specified by the system.

  • Page 12: Modem

    3G/4G/5G Router User Manual 1.2.3 Modem Mobile network is one of the core functions of 4G Intelligent Gateway. 4G Intelligent Gateway supports single-mode single-card dialing and single-mode dual-card backup dialing. It provides high-speed wireless broadband access for users. Internet access speeds of 3G can usually reach 1 to 5 Mbps, 3.5G networks can reach be up to 20 Mbps, and LTE can be up to nearly 100 Mbps.
  • Page 13 3G/4G/5G Router User Manual Figure 1-2 The page of Modem(single-mode dual-card) Add the "Modem" parameter. Table 5-3 describes the parameters of the modem. Table 1-1 The instruction of the parameters of the modem Parameter Details Operation Enable the current modem parameter Button selection: Auto-dialup for modem dialing.
  • Page 14 3G/4G/5G Router User Manual Parameter Details Operation services has a fixed service code. specifications. Username The identity of the access operator WORD type / CODE type, each of which has network is used to access different a maximum length of 64 bytes, which are /Password private network services to isolate both present or empty at the same time.
  • Page 15 3G/4G/5G Router User Manual Parameter Details Operation Port is manually entered: Enter the corresponding port address. use port 22 by default. Interval is manually entered: Enter the Tcpping packet sending interval. Ithe default is 10 (seconds). It is not recommended to configure the advanced Click to display the advanced settings.
  • Page 16 3G/4G/5G Router User Manual Parameter Details Operation Compress Disable  Connection-I Whether allow TCP/IP Negotiation  communicate by compressing ID in Compressio the first More Disable  Debug Enable PPP dialing log, default value Negotiation  is enable, in order to check more info about dialing, suggest no changing Disable ...
  • Page 17 3G/4G/5G Router User Manual Figure 1-3 The page of Modem (Single module single SIM) Click “Save” to complete the parameter configuration for Modem..  Modify As shown in Figure 5-5, determine a parameter configuration record and click Modify to modify the parameter record. The parameter description is shown in Table 5-3. ...

  • Page 18: Wlan

    3G/4G/5G Router User Manual ---END 1.2.4 WLAN 4G Intelligent Gateway provides two functions of WLAN AP and Station client. Through the AP function, 4G Intelligent Gateway can provide wireless LAN hotspots. Through the Station client function, 4G Intelligent Gateway can be connected to other AP device,The lower device of the 4G Intelligent Gateway can access the external network through the connected AP device.
  • Page 19 3G/4G/5G Router User Manual Figure 1-5 The page of Station mode configuration Figure 1-6 The Scanning page when selecting a station Step 3 Configure parameters related to WLAN. The parameter description is shown in Table 5-4. Table 1-1 The instruction of WLAN parameter Parameter Details Operation...
  • Page 20 3G/4G/5G Router User Manual SSID The identity of the WLAN server. General WORD type, maximum 32 bytes, please refer to "Parameter Specification Table" for input specifications. WLAN work mode, support ap/station Wireless Dropdown List Mode  station  Network WLAN network mode, different Dropdown List Mode network models are quite different...

  • Page 21: Parameter Select (Recommend To Single Module Dual Sim Version)

    3G/4G/5G Router User Manual station) the AP. IP(when When "IP allocation" selects static, Format: A.B.C.D Wireless you need to configure the address please refer to “Parameter Specification Mode to establish communication with Table”for input specifications. station) the AP. WLAN Encryption Security Mode Configure the WLAN encryption Dropdown List...
  • Page 22 3G/4G/5G Router User Manual For details, see “5.2.1 Logging In to the WEB Configuration page”. Step 2 Single click “Network > parameter select”. Open the page of “Parameter Select” , as shown in Figure 5-11. Figure 1-1 The page of “Parameter select” Step 3 Configure the parameters related to Parameter Select.
  • Page 23 3G/4G/5G Router User Manual 2. Add a "parameter select" rule. Table 1-1 The instruction of Parameter Parameter Details Operation Enable  Status Enable the current rule. All enabled rules have only Disable  one rule running at a time, and the associated interfaces in all disabled rules are disabled.

  • Page 24: Network Type

    3G/4G/5G Router User Manual  Enable Click "Enable" to enable and apply the Parameter select Rule.  Disable Click “Disable” to disable the Parameter Select Rule.  Refresh Click “Refresh” to refresh the current page. To ensure that the user controls the uplink and downlink of the router, the 4G Intelligent Gateways provide multiple functions for the modem/modem2, such as parameter select, link backup, ICMP detection, task management, and trigger settings.The task management is to perform the action on the modem/modem2 and keep the state after the action is executed, and the parameter select, the link backup, and the ICMP detection all perform the action on the modem/modem2 but do not maintain...

  • Page 25: Link Backup

    3G/4G/5G Router User Manual Table 1-1 The instruction of Parameter of “Network Type” Parameter Details Operation Default route Default route Dropdown List Gateway When the default route is wan and Format:A.B.C.D wan is static IP, you need to configure Example: 192.168.10.254 the next hop gateway address of the wan port address.
  • Page 26 3G/4G/5G Router User Manual Intelligent Gateway supports both cold and hot backup modes. The advantage of hot backup is that it can communicate directly after link switching. However, the disadvantage is that communication costs will be generated when the backup link is online in real time, which increases the cost. Step 1 Log in to the WEB configuration page of the 4G Intelligent Gateway.
  • Page 27 3G/4G/5G Router User Manual Table 1-1 Link Backup Parameter Parameter Details Operation Enable  Status Enable or Disable Link Backup feature Disable  Value area: 0-9  Rule Name Link Backup rule name identification Note: 0 can act as chain link or backup link, 1-9 only can act as backup link 1-9 can take the priority according to the number, the smaller the number the greater the priority...

  • Page 28: Dhcp Service

    3G/4G/5G Router User Manual Step 5 Single click “save” to complete the configuration of “Link Backup”. When the link backup function is enabled, the default route of the router is the default route of the link backup rule.When the link backup is the master-slave switchover, the master link is switched to the primary link as soon as the primary link is detected successfully.
  • Page 29 3G/4G/5G Router User Manual Step 3 Configure “DHCP Server” Settings. Table 1-1 lists the DHCP server settings parameters Parameter Details Operation Enable  DHCP Server Enable or Disable DHCP feature Disable  Basic Settings(DHCP is not recommended configure in the case of no special network requirement) Dropdown List ...

  • Page 30: Application Setting

    3G/4G/5G Router User Manual Parameter Details Operation lease time in more than half the time. IP lease time Default value: 3600 is mainly used to release idle IP to avoid that IP address resources are also occupied after the DHCP client shutdown IP, MAC binding is used to assign a fixed MAC within the specified range of IP addresses Binding with the specified MAC: when a DHCP Manual input...
  • Page 31 3G/4G/5G Router User Manual Figure 1-2 The page of “ICMP Check” Step 3 "Add," "Edit," "Delete," "Enable," and "Disable" operations for "ICMP Detection." Click “Add”. The Add page of ICMP Detection is displayed, as shown in Figure 5-18. Figure 1-3 The Add page of ICMP Detection Configure parameters for the ICMP detection service.
  • Page 32 3G/4G/5G Router User Manual Parameter Details Operation Basic Config Rule Name ICMP Check rule name, just to distinguish different rules WORD type, max 12 bytes Check Type Destination address of ICMP check, it supports two Dropdown list: methods of detecting ICMP and Domain. icmp ...

  • Page 33: Ddns Configuration

    3G/4G/5G Router User Manual As shown in Figure 5-18, determine a parameter configuration record and click Modify to modify the parameter record. The parameter description is shown in Table 5-9.  Delete As shown in Figure 5-18, determine a parameter configuration record and click Delete to delete the parameter record.
  • Page 34 3G/4G/5G Router User Manual Figure 1-4 The page of DDNS Step 3 Configure DDNS parameter. The parameter description is shown in Table 5-10. Table 1-3 DDNS Parameter instruction Parameter Details Operation DDNS Service Set whether enable DDNS service Button function Enable ...

  • Page 35: Gps Configuration

    3G/4G/5G Router User Manual Parameter Details Operation Username/Pass Set user name/password of the DDNS Normal WORD type/CODE type, word service registered in the service provider Maximum 64 bytes. User Domain Set the domain of the DDNS service Normal WORD type, max 64 bytes provided by the service provider Update Interval Set the interval of the DDNS client...
  • Page 36 3G/4G/5G Router User Manual Figure 1-5 The configuration page of “GPS” Step 3 Configure GPS parameter. Table 1-4 The instruction of GPS Parameter Parameter Details Operation Radio button selection. GPS Service Enable GPS service. Enable  Disable  Basic settings Work Mode The working mode of the router Drop-down box selection.
  • Page 37 3G/4G/5G Router User Manual Parameter Details Operation Server IP or IP address or domain name of the Format: Domain GPS server. A.B.C.D or word type Server Port The port used by the GPS server. Value range: 1 to 65535 Packet header Set the content in the GPS data Enter it manually.

  • Page 38: Dtu Configuration

    3G/4G/5G Router User Manual 1.1.4 DTU configuration H8922SS 4G Intelligent Gateway system has built-in communication function with registration center and data center, which can provide similar DTU (Data Transfer Unit), which is used to convert serial port data into IP data or convert IP data into serial port.
  • Page 39 3G/4G/5G Router User Manual Figure 1-7 The configuration page of DTU client Doc. Version 1.0...
  • Page 40 3G/4G/5G Router User Manual Figure 1-8 The configuration page of DDP Step 3 If the DTU works in the server working mode, you need to configure the DTU as the parameter in the server working mode, as shown in Figure 5-20. Step 4 If the DTU works in the client/DDP client working mode, set the "working mode"...
  • Page 41 3G/4G/5G Router User Manual Table 1-5 The instruction of DTU Parameter Parameter Details Operation DTU Service Enable/disable the DTU service. Single box Enable Disable Basic settings Work Mode DTU working mode, can be set to: Dropdown list selection:  Server: The router is used as a DTU server. Server ...
  • Page 42 3G/4G/5G Router User Manual Parameter Details Operation Received Packet When the DDP client is selected as the working mode, it Enter it manually. Max Length needs to be configured to indicate the maximum length of Value range: 1 to 65535 the packets that can be received when the UDP+DDP Unit: Byte.
  • Page 43 3G/4G/5G Router User Manual Parameter Details Operation characters Broker Port Message proxy server corresponding port Enter it manually. Value range: 1 to 65535 Username/Passw Used for MQTT user authentication Enter it manually. Value range: up to 64 characters Client ID The unique identifier of the client, the server is used to Enter it manually.

  • Page 44: Snmp Configuration

    3G/4G/5G Router User Manual Parameter Details Operation Even Default: None (no parity) Databits Data transfer bit. Drop-down list selection. Set according to the actual serial port requirements of the DTU. Value range: 5, 6, 7, 8 Default: 8 Stopbits Data stop bit Drop-down list selection.
  • Page 45 3G/4G/5G Router User Manual Figure 1-9 The configuration page of “SNMP”(the V2 version configuration page above, the following figure is the V3 version configuration page) Doc. Version 1.0...
  • Page 46 3G/4G/5G Router User Manual Step 3 Configure SNMP parameter. Table 1-6 The instruction of SNMP Parameter Parameter Details Operation SNMP service To enable or disable SNMP service Options: Enable   Disable Basic Config SNMP Version SNMP version setting, support for SNMPV2c Dropdown list: and SNMPV3 SNMPV2c...
  • Page 47 3G/4G/5G Router User Manual Parameter Details Operation router for identification Trap IP Link-state router report server address Manual input Format: A.B.C.D/Mask Trap Port Link-state router report server address’s port Value area: 1~65535 Default: 162 Loopback Status Match with "LAN" page loopback address, in Options: the "Loopback Status"...

  • Page 48: M2M Configuration

    3G/4G/5G Router User Manual Trap: One of the five data types of the SNMP protocol, which refers to the trap message reported by the managed device, indicating that the device is faulty or changed. 4G Intelligent Gateway reports the type and content of the trap including: modem connection status and which interface, which SIM card dial, VPDN/TUNNEL/IPSec interface connection and disconnection.

  • Page 49: Schedule Configuration

    3G/4G/5G Router User Manual Parameter Details Operation Protocol Data transfer protocol selection between Dropdown list: device and M2M platform Mqtt  wmmp  Server IP or Set the server IP or domain of M2M platform Normal WORD type, max 64 Domain bytes Server Port...
  • Page 50 3G/4G/5G Router User Manual Figure 1-11 The configuration page of “Schedule” Step 3 To add a new task management rule, click “Add” to enter the task management rule settings page, as shown in Figure 5-24. Figure 1-12 Task management rule settings page Step 4 Configure task management rule parameters.
  • Page 51 3G/4G/5G Router User Manual Parameter Details Operation reasonable time task control. Basic Config Task name Name of a timing task Maxium 12 bytes Task type Task type has action task and status task. Action Dropdown List options: task is for time point or time interval, while status modem-online ...

  • Page 52: Sms Settings

    3G/4G/5G Router User Manual time type is "interval", you do not need to enable "system time". To use "System Time",please see "5.7.4 System Time". Due to the stability of the modem, the router has multiple functions for modem operation, such as task management, parameter switching, link backup, ICMP detection, trigger setting.

  • Page 53: Radius Settings

    3G/4G/5G Router User Manual Parameter Details Operation provided by the SMS function. specifications, please refer to the “Parameter Specification Table”. Step 4 Click "Add" to add the entered trust number Step 5 Click delete to delete the added trust number. When no trust number is added, the SMS service function can be used for any mobile phone number;when there is a trusted number, only the trusted number can use the SMS service function.

  • Page 54: Security Configuration

    3G/4G/5G Router User Manual Parameter Details Operation with the Radius server Supports up to 64 characters Source Interface Server IP or domain The source interface IP carried by the communication for getting the GPS message with Radius, the MASQ function needs to be data disabled when using this function, otherwise the source IP may be changed.
  • Page 55 3G/4G/5G Router User Manual Figure 1-15 The configuration page of”IP Filter” In the forwarding filtering rules.  Black List: The default allows packet forwarding, in line with the list of "discarded" rules packet cannot be forwarded through the router.  White List: The default refuses packet forwarding, in line with the list of "accept"...
  • Page 56 3G/4G/5G Router User Manual Figure 1-17 The configuration of “Forward” type of IP filter Table 1-11 The instruction of IP filter parameter Parameter Details Operation Type Select a filter type, you can choose Dropdown List options according to their needs, "Input" or ...
  • Page 57 3G/4G/5G Router User Manual Parameter Details Operation Dropdown List options  Protocol Protocol used by IP packets    icmp  The source IP address of the packet  Source IP Manual input Format: A.B.C.D/Mask Example: 92.168.8.1 192.168.8.1/24 Source Port The source Port of the packet, when the Value area:...

  • Page 58: Domain Filter

    3G/4G/5G Router User Manual 1.2.2 Domain Filter Domain filter support black list and white list. It is used to forbid PCs in LAN from visit some websites or allows them to visit specific websites. Step 1 Log in to the 4G Intelligent Gateway WEB configuration page. For details, see “5.2.1 Logging In to the WEB Configuration Page”.

  • Page 59: Mac Filter

    3G/4G/5G Router User Manual Accept.  Default action Actions to filter the keyword Drop  Step 4 Single click “Save” to finish configuring a rule. --END 1.2.3 MAC filter MAC filter also supports black and white lists, which are usually used to control host access to routers. In addition to this function, the 4G Intelligent Gateways can also restrict the external network access rights of specific MAC hosts, or only allow hosts with specific MAC addresses to access the external network.

  • Page 60: Remote Access

    3G/4G/5G Router User Manual Parameter Details Operation black list / white through router. list. White list: rules in white list can visit external network,  other MACs cannot visit external network through router. Step 3 Click “Add” to add a new MAC filter rule and configure MAC filtering parameter. See below: Figure 1-21 The configuration of MAC Filter Table 1-14 The instruction of MAC Filter Parameter...
  • Page 61 3G/4G/5G Router User Manual In addition, some customers have banned ping service requirements, and the page has added a ping function that prohibits all ports except the br0 port. Step 1 Log in to the 4G Intelligent Gateway WEB configuration page. For details, see “5.2.1 Logging In to the WEB Configuration Page”.
  • Page 62 3G/4G/5G Router User Manual Figure 1-23 The editing page to open Ports Table 1-15 Description of port open configuration parameters Parameter Details Operation Interface The interface that needs to be configured for the port. No action required The default is not to choose. The SSH port can be chosen to open or close .

  • Page 63: Anti-Attack

    3G/4G/5G Router User Manual Figure 1-24 The editing page to ping Table 1-16 Description of port open configuration parameters Parameter Details Operation Interface The interface that needs to be configured for the port. No action required The default is not to choose. The ping can be chosen to turn ping on or off ping Radio button selection.

  • Page 64: Forward Configuration

    3G/4G/5G Router User Manual Figure 1-25 The configuration page of “Anti-attack” Table 1-17 The instruction of Parameter for Anti-attack Parameter Details Operation DDoS service The DDos can be chosen to enable Radio button selection. or disable. Enable  Disable  The function of port Scan Limit can be Port Scan Limit Radio button selection.
  • Page 65 3G/4G/5G Router User Manual Figure 1-26 The configuration page of “NAT” Step 2 Click the "Add" button and select a new DNAT rule with the conversion type "DNAT", see below: Figure 1-27 The configuration page of DNAT rule Doc. Version 1.0...
  • Page 66 3G/4G/5G Router User Manual Step 3 Configure parameters for the DNAT rule. Table 1-18 DNAT Parameter instruction Parameter Details Operation Basic Settings Protocol destination address Select from dropdown List: translation performed  which protocol packet.   icmp  Original Address Type The external address, the address Dropdown List needs to be converted...
  • Page 67 3G/4G/5G Router User Manual Step 2 After the conversion type is set to SNAT, the configuration page. See below: Figure 1-1 The configuration page of SNAT rule Step 3 Configure the paraneter of SNAT rule. Table 1-1 The instruction of parameters of SNAT rule Parameter Details Operation...
  • Page 68 3G/4G/5G Router User Manual Parameter Details Operation Format: Mapping Address New source address after source address A.B.C.D replacement Mapping Port The new port which replaces the original port Value area: 1-65535 of source address. [1-65535], it can be a range, or a single port Step 4 Single click “save”...
  • Page 69 3G/4G/5G Router User Manual Parameter Details Operation and the outside.  modem  eth0  eth1  Step 3 Single click “save” to finish the configuration of MASQ. MASQ rule: the source address of all packets in the LAN need to be transferred into the specific ip address of the router, so the PC from the LAN can send packets out;...

  • Page 70: Routing Configuration

    3G/4G/5G Router User Manual Parameter Details Operation address between the router LAN and the outside. List:  modem  eth0   eth1 Mapping Address The address after the original destination address Format: A.B.C.D is replaced. Step 3 Single click “save” to finish the configuration of DMZ. ---END 1.3.1 Routing Configuration Routing provides a specific forwarding path for routers to forward packets, which must be manually...
  • Page 71 3G/4G/5G Router User Manual Figure 1-2 The configuration page of Static Routing Figure 1-3 The configuration page of Policy Routing Table 1-1 The instruction of parameters of Routing Parameter Details Operation Basic Setting Dropdown List  Routing Type To select “Static Route” or “Policy Route”...
  • Page 72 3G/4G/5G Router User Manual Parameter Details Operation A.B.C.D If the gateway type select interface, the  gateway needs to select from dropdown list Enter it manually. Priority Static route priority Range: 3-252 configuration The smaller the value, the higher the priority When Routing Type is “Policy Route”...

  • Page 73: Qos

    3G/4G/5G Router User Manual 1.3.2 QoS QoS (Quality of Service) quality of service, is a security mechanism for the network, is a technique to solve the network bandwidth allocation and network priority and other issues. When the network is overloaded or congested, QoS to ensure that critical traffic is not delayed or dropped, while ensuring the efficient operation of the network, our 4G Intelligent Gateway supports custom QoS services.

  • Page 74: Dynamic Routing (Optional)

    3G/4G/5G Router User Manual Parameter Details Option follow-up can not be modified The rule name can not be repeated, otherwise the rule will be covered after the rule is added in front of the cover Control Interface The interface type of QOS, Dropdown List include: ...
  • Page 75 3G/4G/5G Router User Manual network and used in a continuous regional networks that the rate change is not big, 4G Intelligent Gateway supports RIP v2 protocol. For more complex environments, generally do not use the RIP protocol. Step 1 Click “Forward > RIP”. Step 2 Open the configuration page of “RIP”.
  • Page 76 3G/4G/5G Router User Manual Figure 1-7 The configuration page of RIP route Step 4 Configure RIP route parameter instruction. See below: Table 1-4 RIP parameter instruction Parameter Details Operation Add Type Add the type of RIP Click the button to select Add Type route When it is “Network”, need to configure ...
  • Page 77 3G/4G/5G Router User Manual Step 2 Open the configuration page of “OSPF” . See below: Figure 1-8 The configuration page of OSPF Table 1-5 OSPF parameter instruction Parameter Details Operation OSPF Service Enable or disable OSPF Service Click the button to select ...
  • Page 78 3G/4G/5G Router User Manual Figure 1-9 The configuration of OSPF route Step 4 Configure OSPF route parameter instruction. See below: Table 1-6 OSPF route parameter instruction Parameter Details Option When Add Type is “Network”, Network Set the network address as ospf sending Manual input address Format1: A.B.C.D/Mask...
  • Page 79 3G/4G/5G Router User Manual Step 5 Single click “save” to finish OSPF route setting. OSPF is a link-state (Link-state) routing protocol, commonly used for the same routing domain. Here, the routing domain is an autonomous system, which refers to the routers can switch routing information through a unified network switching or routing protocol routing policy in the AS, all OSPF routers maintains an identical description of the database structure AS, which is stored in the database link status information corresponding routing domain, OSPF router is through this database to calculate its OSPF routing table.
  • Page 80 3G/4G/5G Router User Manual BGP configuration Border Gateway Protocol (BGP) is a routing protocol for an autonomous system running on TCP. BGP is the only protocol used to handle networks like the size of the Internet, and the only protocol that can properly handle multiple connections between unrelated routing domains.
  • Page 81 3G/4G/5G Router User Manual Step 4 Click “Add” to create a new BGP rule. See below: Figure 1-11 The configuration page of BGP Step 5 Configure the rule parameters of the route mode. See below:BGP rule parameter instruction Parameter Details Option When "Notification Type"...

  • Page 82: Vpn Configuration

    3G/4G/5G Router User Manual Synchronization BGP synchronization switch Dropdown list: Enable  Disable  Step 6 Click “Save” to complete the configuration of the BGP rule. BGP (Border Gateway Protocol) is a distance vector routing protocol that implements reachable routes between ASs (Autonomous System) and selects the best route.
  • Page 83 3G/4G/5G Router User Manual Point to Point Tunneling Protocol (PPTP) is a network technology that supports multi-protocol virtual private networks. It is also a Layer 2 protocol. Through this protocol, remote users can securely access the corporate network through Windows mainstream operating systems and other systems equipped with peer-to-peer protocols, and can dial into the local ISP to securely connect to the corporate network through the Internet.
  • Page 84 3G/4G/5G Router User Manual Step 3 Configure VPDN rule parameter. See below: Table 1-8 VPDN rule parameter instruction Parameter Details Operation VPDN service To enable or disable the VPDN rule single button:  Enable Disable  Basic Settings Interface name Name of this VPDN rule Cannot be modified after save.
  • Page 85 3G/4G/5G Router User Manual Parameter Details Operation Disable  Address/Control Whether compress IP address Negotiation  Compression Disable  Protocol Field Whether compress Whether compress IP Negotiation  Compression address Disable  VJ TCP/IP Header Whether allow TCP/IP to communicate by ...

  • Page 86: Tunnel Configuration

    3G/4G/5G Router User Manual Figure 1-14 L2TP tunnel status ---END 1.4.2 Tunnel configuration Tunnel technology transfers data between the networks through the Internet infrastructure. In the whole process of transmission, when the encapsulated data package delivered on a public Internet, the logic path which the packet passes through is called tunnel.
  • Page 87 3G/4G/5G Router User Manual Figure 1-15 Tunnel configuration Table 1-9 Tunnel rule parameter instruction Parameter Details Operation IP Tunnel Service To enable or disable IP tunnel service Button selection: Enable   Disable Basic Settings Tunnel name Name of the tunnel, cannot be modified after An easily identifiable name save recommended.

  • Page 88: Ipsec Configuration

    3G/4G/5G Router User Manual Parameter Details Operation Local Extern This parameter will need to be set if “interface” Select from Dropdown List. interface is selected in “interface type”. Choose any modem  connected interface as external interface eth0  Local extern IP This parameter need to be set if “static IP”...
  • Page 89 3G/4G/5G Router User Manual Figure 1-16 The page of IPSec Step 3 Click “Add” to add a new IPSec rule. There are 3 phases for IPSec configuration: Phase 1 parameter Figure 1-17 IPSec phase 1 configuration Doc. Version 1.0...
  • Page 90 3G/4G/5G Router User Manual Table 1-10 The instruction of parameters of IPSec Phase 1 Parameter Details Operation Basic Settings Select Set the phase type of IPSec, including Select “Phase 1” the first phase, the second phase, and the third phase. Policy Name The name of this stage is mainly used for To input the name of phase 1.
  • Page 91 3G/4G/5G Router User Manual Parameter Details Operation Group Name Configured here as the key length for the Select from Dropdown List first phase of IKE negotiation. group768  group1024  group1536  group2048   group3072 Grouo4096  DPD Service To enable DPD service,The DPD peer Dropdown list: detection needs to be supported by the...
  • Page 92 3G/4G/5G Router User Manual Figure 1-18 The configuration page of IPSec phase 2 See below parameters instruction of the second phase of the IPSec rule. Table 1-11 The parameters of the second phase of the IPSec rule Parameter Details Operation Basic Settings Select Set the phase type of IPSec, including...
  • Page 93 3G/4G/5G Router User Manual Parameter Details Operation Hash The second stage of hash algorithm Select from Dropdown List selection  sha1  Sha2_256  Group Name Used when perfect forward Select from Dropdown List encryption enabled, here group768  configured as the key length for IPSec group1024 ...
  • Page 94 3G/4G/5G Router User Manual The protocol code of the local protocol port and the remote protocol port must be the same, indicating that one protocol is encrypted. When the local protocol port and the remote protocol port are configured, IPSec encrypts the protocol and port, and other communications are not encrypted.

  • Page 95: Open Vpn Configuration

    3G/4G/5G Router User Manual Parameter Details Operation phase configuration. Match Phase2 To select a matching name of “phase2” Select from Dropdown List Select the policy name for the second phase configuration. Destination IP IP or domain name of the IPSec peer server. Fill in the IP or domain name of the or Domain IPSec peer server.
  • Page 96 3G/4G/5G Router User Manual Figure 1-20 The configuration page of OpenVPN Step 2 Set the parameters of Open VPN. See below: Table 1-13 The instruction of the parameters of OpenVPN Parameter Detail Operation OPENVPN Enable OPENVPN Service. Click button options: Service Enable ...
  • Page 97 3G/4G/5G Router User Manual Parameter Detail Operation Work Mode Supports two working modes: Dropdown list options:  Client mode: client type mode client  multi   Multi mode: peer to peer working mode (peer is non-server) Select the required working mode from dropdown list.
  • Page 98 3G/4G/5G Router User Manual Parameter Detail Operation Encrypt Data encryption method Dropdown list options: NONE   SHA1  SHA224   SHA256 SHA384  SHA512  Specifies the file path for the client CA WORD type，max 32 bytes. certificate Specifies the private key path for the current WORD type，max 32 bytes.

  • Page 99: Dmvpn Configuration

    3G/4G/5G Router User Manual 1.4.5 DMVPN Configuration Dynamic Multipoint VPN, dynamic multipoint VPN. DMVPN is a MGRE+NHRP+IPSEC solution that is a simple, dynamic, and scalable way. DMVPN supports spoke dynamic addresses, adding new spokes, without changing the hub configuration. The spoke to spoke dynamic generation tunnel is triggered by traffic and is encrypted using IPSec.
  • Page 100 3G/4G/5G Router User Manual Figure 1-22 The configuration page of “DMVPN” Step 4 Configure DMVPN rule parameters. See below: Table 1-14 The instruction of the parameters of DMVPN Parameter Detail Operation Button selection: DMVPN Service DMVPN service switch Enable  Disable ...
  • Page 101 3G/4G/5G Router User Manual Parameter Detail Operation IP address of the public network. It Format:A.B.C.D can also be the IP address of different intranets.。 Local Virtual IP The virtual IP address of the local Enter it manually. tunnel. Format:A.B.C.D The virtual IP address of the local Peer Virtual IP Enter it manually.
  • Page 102 3G/4G/5G Router User Manual Parameter Detail Operation Self Identify Configure the IPSEC local ID to You can fill in the IPSec local ID. It must be indicate the identity of the local the same as the peer ID preset by the IPSec end.

  • Page 103: Eoip Configuration

    3G/4G/5G Router User Manual Parameter Detail Operation also be selected in the drop-down list. Enter it manually. Nhrp Cisco NHRP next routing Maximum support input of 64 characters. Secrets resolution protocol is used to solve point-to-multipoint environmental data communication problems. Fill in the NHRP key here, and it needs to be consistent with the peer.

  • Page 104: System Management Configuration

    3G/4G/5G Router User Manual Figure 1-24 The configuration page of “EOIP” Step 4 Configure parameters for EOIP rules. See below: Table 1-15 The instruction of the parameters of EOIP Parameter Detail Operation Enter it manually. Input of EOIP ID value Input range: 1~65535 ID cannot be modified after saving Tunnel Name...

  • Page 105: Remote Log

    3G/4G/5G Router User Manual For details ,please see “5.2.1 Logging In to the WEB Configuration Page”. Step 2 Click “System>Local Log”. Open the configuration page of”Local Log”. See below: Figure 1-25 Local Log tab Step 3 Select type of “Local Log” and then click “View” to see log. Click “Clear”...

  • Page 106: Clock

    3G/4G/5G Router User Manual Step 2 Click “System>Remote Log”. Open the configuration page of”Remote Log”. See below: Figure 1-26 The configuration page of Remote Log Step 3 Configure parameters for the system log. See below: Table 1-16 The instruction of Remote log parameter Parameter Details Operation...
  • Page 107 3G/4G/5G Router User Manual For details ,please see “5.2.1 Logging In to the WEB Configuration Page”. Step 2 Click “System > Clock” to open the page of “Clock”. See below: Figure 1-27 “NTP” Time Synch. Figure 1-28 Manually configure Time Sync Type Step 3 Configure parameters for system time.

  • Page 108: Account

    3G/4G/5G Router User Manual Select from Dropdown List: Time Synch. Type Type to synchronize system time Ntp(correcting time via the network)  manual(using the manual method for  proofreading time) When select “NTP” in “Time Synch. Type” Select from Dropdown List: Source Interface The original interface with the modem...
  • Page 109 3G/4G/5G Router User Manual Step 2 Click “System > Account” to open the page of “Account”.AS shown in figure 5-74. Figure 1-29 The page of Account Step 3 Configure parameters of account. The parameter description is shown in Table 5-47. Table 1-18 The instruction of Account parameter Parameter Details...

  • Page 110: Network Test

    3G/4G/5G Router User Manual Parameter Details Operation Default: 80 “Account” only provides the user's modification function, and does not provide functions such as adding and deleting. If the "port" parameter has not been modified, you can log in to the router page by directly entering the IP address of the router.
  • Page 111 3G/4G/5G Router User Manual Figure 1-30 The configuration page of Network Test Step 3 Input IP address or domain to be tested in “Destination”, click “Ping, to check whether the router can be linked with destination. See below: Table 1-19 The instruction of parameters of Network Test Parameter Details Operation...

  • Page 112: Files

    3G/4G/5G Router User Manual Trace: Traceroute. Through Traceroute, we can know what path the computer from the computer to the other end of the Internet is. It takes a long time to send a small packet to the destination device until it returns. Each device Traceroute on one path is measured 3 times.
  • Page 113 3G/4G/5G Router User Manual ---END Upgrade in CFE mode When the program is upgraded to the router (generally, the program upgrade is a comprehensive replacement upgrade), if the file size exceeds 6MB or the upgrade fails through the WEB configuration page, you can choose to upgrade in CFE mode.
  • Page 114 3G/4G/5G Router User Manual Figure 1-33 The page of upgrading in CFE mode Step 4 Click “Browse” and select the upgrade file on the local PC, and then click Upload to start the upgrade. See below: Figure 1-34 The Page being upgraded in CFE mode The upgrade process will last for about 3 to 6 minutes.
  • Page 115 3G/4G/5G Router User Manual Figure 1-35 Backup setting page After the backup file is imported, the system automatically restarts a Key: adding a key when exporting a file, you need to enter the key when importing the file. Otherwise, the router will be garbled; the key can be left blank.

  • Page 116: Status

    3G/4G/5G Router User Manual 1.6 Status Overview 4G Intelligent Gateway provides status display information. Through the status page, you can quickly view the basic information, network status, and routing table information of the router. 1.6.1 Base Information You can learn the basic information of the 4G Intelligent Gateway system by viewing the basic information of the 4G Intelligent Gateway.

  • Page 117: Lan

    3G/4G/5G Router User Manual 1.6.2 LAN By viewing the "LAN Status" information of the 4G Intelligent Gateway, you can learn the basic information of the "LAN Status" of the 4G Intelligent Gateway. The specific operation method is as follows. Step 1 Log in to the WEB configuration page of the 4G Intelligent Gateway.

  • Page 118: Wan

    3G/4G/5G Router User Manual 1.6.3 WAN By viewing the "WAN Status" information of the 4G Intelligent Gateway, you can learn the basic information of the "LAN Status" of the 4G Intelligent Gateway. The specific operation method is as follows. Step 1 Log in to the WEB configuration page of the 4G Intelligent Gateway.

  • Page 119: Modem

    3G/4G/5G Router User Manual Figure 1-42 WAN status in PPPoE form Table 1-22 The instruction of parameters of WAN status Parameter Details Operation WAN Status Shows whether the status of the current WAN interface Not available function is enabled or disabled. Wan Type Displays the type of the current WAN interface.
  • Page 120 3G/4G/5G Router User Manual Step 2 Click “Status > Modem” to open the page of “Modem”. As shown in figure 5-88. The parameter description is shown in Table 5-52. Figure 1-43 The page of Modem Status Table 1-23 The instruction of parameter of Modem Parameter Details Operation...

  • Page 121: Wlan

    3G/4G/5G Router User Manual Parameter Details Operation IP Address 4G Intelligent Gateway obtained the external network IP address Not available when dialing. 4G Intelligent Gateway obtains the preferred DNS address when Not available dialing. SIM Status The working status of the SIM corresponding to the card slot Not available currently used by the 4G Intelligent Gateway.
  • Page 122 3G/4G/5G Router User Manual Figure 1-44 Status page in ap mode Figure 1-45 Status page in station mode Doc. Version 1.0...
  • Page 123 3G/4G/5G Router User Manual Table 1-24 The instruction of Parameter in ap mode Parameter Details Operation Basic information Work Mode The working mode of the WLAN. Not available SSID Representation of ap. Not available AP Isolation The isolation status of the WLAN client device. Not available Channel The working channel of ap.

  • Page 124: Routing Table

    3G/4G/5G Router User Manual 1.6.6 Routing Table By querying the status of the routing table, you can learn the routing information of the 4G Intelligent Gateway. Step 1 Log in to the WEB configuration page of the 4G Intelligent Gateway. For details ,please see “5.2.1 Logging In to the WEB Configuration Page”.

  • Page 125: Gps

    3G/4G/5G Router User Manual 1.6.7 GPS By querying the status of the routing table, you can learn the GPS information of the 4G Intelligent Gateway. Step 1 Log in to the WEB configuration page of the 4G Intelligent Gateway. For details ,please see “5.2.1 Logging In to the WEB Configuration Page”. Step 2 Click “Status>GPS”.

  • Page 126: Traffic Statistics

    3G/4G/5G Router User Manual --END 1.6.8 Traffic Statistics By querying the status of the routing table, you can learn the traffic statistics of the 4G Intelligent Gateways. Step 1 Log in to the WEB configuration page of the 4G Intelligent Gateway. For details ,please see “5.2.1 Logging In to the WEB Configuration Page”.

  • Page 127: Reset Button Function

    3G/4G/5G Router User Manual Figure 1-49 The page of LAN Traffic Statistic Table 1-28 The instruction of Traffic Statistic Parameter Details Operation Flow chart The traffic usage information of the interface is displayed in Not available real time through the picture. The speed of uploading and downloading can be seen through the picture, the red line indicates uploading, and the blue line indicates download。...

  • Page 128: Typical Application

    3G/4G/5G Router User Manual ---END Typical application About this chapter Chapter Brief introduction of content 6.1 Overview This section briefly introduces several typical application functions of the 4G Intelligent Gateway. Link backup This section briefly introduces a typical application example of the Router function trigger setting function.

  • Page 129: Link Backup Function

    3G/4G/5G Router User Manual 2.2 Link backup function Scene introduction 4G Intelligent Gateway supports link switching between wireless and wireless, wireless and wired. When the working link of the router fails, it can quickly switch to other links and continue to work on the switched link. For example, the shopping mall POS card needs a stable network to ensure that if the wired network used by the POS fails, the 4G Intelligent Gateway can quickly switch to the wireless network to ensure the normal operation of the POS card card service.

  • Page 130: Application Result

    3G/4G/5G Router User Manual Figure 2-2 Backup link (modem) configuration Application result After all the parameters are configured, the default route of the router goes to the eth0 (WAN) interface of the primary link. If the router can ping the IP address of 202.170.138.60, the router will always work on the primary link.

  • Page 131: Parameter Select Function

    3G/4G/5G Router User Manual Figure 2-4 The primary link fails to be detected and is switched to the backup link. 2.3 Parameter select function Scene introduction 4G Intelligent Gateway provides parameter switching function to switch between working or temporarily stopped links. For example, when the working L2TP link fails to work properly for some reason, it can switch to the standby PPTP or IPSec link.
  • Page 132 3G/4G/5G Router User Manual Figure 2-6 The configuration of parameter select 1 Figure 2-7 The configuration of parameter select 2 Doc. Version 1.0...

  • Page 133: Vpn

    3G/4G/5G Router User Manual When the working L2TP link is disconnected from the server for some reason, the router performs the parameter "check icmp" in the parameter switch, and pings the configured destination IP to detect whether the router is disconnected from the network operator. After failing to ping the destination IP address three times, the router will switch to the PPTP link, maintain the connection with the server, and continue to work.
  • Page 134 3G/4G/5G Router User Manual Figure 2-9 Establishing IPSec communication PC1 establishes an IPSec link with the company's router through the VPN function of and uses tunnel mode communication. The LAN address on the side is 192.168.86.1/24, and the LAN address on the router side of the company is 192.168.99.1/24.
  • Page 135 3G/4G/5G Router User Manual Figure 2-10 IPSec Phase 1 Figure 2-11 IPSec Phase 2 Doc. Version 1.0...
  • Page 136 3G/4G/5G Router User Manual Figure 2-12 IPSec The same configuration should be used on the router of the company. The difference is that the configuration of the local end identifier, the peer end identifier, the local subnet, and the terminal network are opposite to those of the 4G Intelligent Gateway.
  • Page 137 3G/4G/5G Router User Manual 2.5 Schedule Scene introduction 4G Intelligent Gateway support timing task, by setting timing task, at certain time, router will operate reboot, online command. Etc. Easier the customer operation. I assume set the router online at certain time and keep a moment, then reboot every 24 hours.
  • Page 138 3G/4G/5G Router User Manual FAQ/Exception handling About this chapter Chapter Content 7.1 Hardware failure Possible hardware failure during using 4G Intelligent Gateway and how to handle them 7.2 Dial online problem Possible problem during dialing and how to handle them 3.3 VPN Possible problem when connecting VPN config...
  • Page 139 3G/4G/5G Router User Manual 3.1.2.5 Possible Reason  SIM slot damaged  SIM card wrong direction 3.1.2.6 Solution  SIM slot damaged, please contact us to repair  Check the SIM card direction, please make sure the SIM goldfinger is up 3.1.3 Ethernet Connection 3.1.3.7 Phenomenon...
  • Page 140 3G/4G/5G Router User Manual 3.2 Dial Online Problem 3.2.1 Dial discontinue 3.2.1.13 Phenomenon 4G Intelligent Gateway discontinue during dialing, dial failure 3.2.1.14 Possible Reason  SIM card network type do not match  SIM charges owed  Power supply do not match ...
  • Page 141 3G/4G/5G Router User Manual  SIM bad contact 3.2.3.21 Solution  Replace SIM card  Re-install SIM card 3.2.4 Poor Signal 3.2.4.22 Phenomenon 4G Intelligent Gateway no signal or poor signal 3.2.4.23 Possible Reason  Antenna connect wrong  Area signal weak 3.2.4.24 Solution ...
  • Page 142 3G/4G/5G Router User Manual 3.3.1.29 Possible Reason  VPDN port work abnormal  VPDN parameter wrong  VPDN peer server abnormal 3.3.1.30 Solution  Make sure Modem is online  Set the correct port to VPDN  VPDN parameter wrong ...
  • Page 143 3G/4G/5G Router User Manual 3.4 WEB config problem 3.4.1 Updating firmware failure 3.4.1.37 Phenomenon Updating firmware failure 3.4.1.38 Possible Reason  Auto reboot during updating 4G Intelligent Gateway  Power supply problem  Wrong firmware  Power off during updating router 3.4.1.39 Solution ...
  • Page 144 3G/4G/5G Router User Manual 3.4.3.45 Solution  Check patch format, change to a right one  Change the patch name to a simple one 3.4.4 CFE Updating failure 3.4.4.46 Phenomenon CFE updating failure, firmware edition no change 3.4.4.47 Possible Reason ...
  • Page 145 3G/4G/5G Router User Manual 3.4.6.54 Solution After router power on, push and hold RESET button over 10 seconds then release, then re-power on router, router will back to factory mode (Username/Password both admin), but patch will reserve When router is power on, press and hold RESET button around 1s, router will reboot and kept all setting. Doc.
  • Page 146 3G/4G/5G Router User Manual FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
