- Page 1 MFLEX LIGHT SYSTEM RAPID HANG GUIDE...
- Page 3 LET’S GET YOU UP TO SPEED ON WHAT’S INSIDE. HANGING STRAP CORDURA® MFLEX CARRYING CASE FULLY ASSEMBLED LED LIGHT STRIPS, INCLUDING: MFlex 12-meter white light strip MFlex 12-meter blackout light strip 16 Hanging clips 16 Hanging hooks 16 Cord locks LED Y POWER CABLE...
- Page 4 Take a closer look at the control panel. THIS IS WHERE YOU’LL OPERATE THE LIGHTS. ON/OFF LIGHTING LED TOGGLE CONTROL DIAL Switches between white light, Adjusts light output to low, neutral and blackout operations. medium or high. USB CHARGING STATION Allows for charging of handheld devices.
-
Page 5: Let's Get Started
120V power cable extending out the side, and plug into an AC outlet. If connecting to a NATO-approved battery, use a Frontline battery cable only or damage to the unit could result. CONNECT the LED Y power cable to the 24 VDC Out port, located on top of the control box inside the case. - Page 6 DECIDE which hanging pattern works best to provide light where you need it. Here are several common layouts, but you can hang the lights in whichever pattern meets your mission requirements. MFLEX strips may need to be hung closer to the wall in smaller shelters, and 4-6 feet from the wall in larger shelters since the LEDs radiate at 180°.
- Page 7 Hang the lights. MFLEX LIGHT STRIPS COME PREHUNG. SO THEY CLIP QUICKLY TO SHELTER RIBBING. UNROLL the light strips, keeping the male connectors closest to the carrying case. Lay the strips out flat and in parallel, making sure there are no twists in the lines.
- Page 8 Shelter striking operations. UNPLUG the MFlex Lighting System from the AC power outlet. The LED light strips will remain in the shelter once packed. STORE the MFlex carrying case in a safe location until the next use.
- Page 9 HERE’S HOW TO ORDER THEM. MFLEX LIGHT KIT COMPONENTS CALL US. 724.841.0101 AND PART NUMBERS SEND AN EMAIL. admin@FrontlineLighting.com 1 MFlex light system carry case MFLK-Kit-Bag-0001 ORDER ONLINE. frontlinelighting.com 2 LED Y power cable MFLK-PWRCBL-0001 3 Power supply with connectors...
- Page 10 WARNINGS! Failure to follow these instructions may result in injuries, fatalities or permanent damage of the MFlex Light Kit system and void the warranty. • Only use an external power supply input within these specifications: 100-277 Vac @ 50/60Hz. •...
