Page 1 User Manual activemobility.com.au...
Page 2: Table Of Contents
User Manual Contents PREFACE AND INTRODUCTION SAFETY NOTICE Before driving While driving Labeling PARTS INTRODUCTION Parts description OPERATION Control panel How to operate your scooter Assembling and disassembling BATTERY CHARGING AND CARE Charging the battery Battery INSPECTION AND MAINTENANCE Inspection Regular checking record Battery, fuses, and tyres Storage...
Page 3: Preface And Introduction
To maximize your battery efficiency and service life, please fully charge your new battery before first  Suggestion time use. Active Mobility | xtaga Impala | User Manual...
Page 4: Safety Notice
Do not use this vehicle to carry or haul goods. • As the maximum weight can be carried, please refer to “MAX USER WEIGHT” in “7. SPECIFICATION” • Maximum load weight for basket 3 kg. Active Mobility | xtaga Impala | User Manual...
Page 5: While Driving
• Please slow down when driving on roads with inclines. • Do not make sudden turns when driving on gravel roads or ramps. • Always lean forward when climbing a steep gradient. Active Mobility | xtaga Impala | User Manual...
Page 6 SPECIFICATION “. Overloading past the weight limit may lead to damage of your scooter or cause it to malfunction and will endanger your safety. The warranty does not cover this type of damage. Active Mobility | xtaga Impala | User Manual...
Page 7 1. Release the speed control lever completely. The vehicle will automatically brake and stop. 2. Turn the power switch to (OFF). Then remove the key. Driving on the pavement • The maximum driving speed for pavement use is 10Kph. Active Mobility | xtaga Impala | User Manual...
Page 8: Labeling
Please carefully read all labels on the scooter before driving it. For your future reference, do not remove them. TILLER LOCK WARNING EMI FREEWHEEL LABEL LABEL LABEL TILLER DUMPING SEAT PINCH WIRING DIAGRAM FOR WARNING LABEL WARNING LABEL BATTERY LABEL Active Mobility | xtaga Impala | User Manual...
Page 9: Emi
These usually have the antenna mounted on the outside of the Vehicle, 3. Long-range transmitters and transceivers, such as commercial broadcast transmitter (radio and TV broadcast antenna towers) and amateur (HAM) radios; Active Mobility | xtaga Impala | User Manual...
Page 10: Parts Introduction
Parts Introduction 3.1 PARTS DESCRIPTION 1. Power Switch 4. LED Headlight 7. Width Adjustable Armrests Knob 2. Basket Bracket 5. Tiller Lock Knob 8. Circuit Breaker 3. Seat Rotation Lever 6. Armrest Active Mobility | xtaga Impala | User Manual...
Page 11: Operation
The horn will beep when the vehicle is in reverse. • Release the speed control lever completely while either going forward or reverse, and the electromagnetic brake in the motor will be activated, and the vehicle will stop. Active Mobility | xtaga Impala | User Manual...
Page 12 • The remaining power suggested by the battery indicator will vary by the actual driving time incurred and how you drive. Repeated starting, stopping, climbing will consume the power more quickly. Active Mobility | xtaga Impala | User Manual...
Page 13 Ensure the limit switch is set to the slowest setting when ☞ using the scooter on the pavement. It is an offence to Attention traveler when driving faster than 4mph on the pavement. Active Mobility | xtaga Impala | User Manual...
Page 14 When the voltage in your scooter’s batteries becomes low or when the scooter is operating under excessive loads or steep inclines, the main circuit breaker may trip to protect the motor and electronics from damage. Press to reset. Active Mobility | xtaga Impala | User Manual...
Page 15: Assembling And Disassembling
6. Turn key switch to “ON”. Make sure battery gauge indicates sufficient power. Disassembling The Scooter The xtaga Impala can be disassembled into four pieces, the seat, the front section, the rear section and battery pack. To avoid personal injury, ask for assistance, if necessary, ...
Page 16: Battery Charging And Care
While returning the battery pack to the battery pack Attention cavity of shroud, use caution ensuring fingers or hands are not in a position where they could be caught between Battery pack and scooter body. Active Mobility | xtaga Impala | User Manual...
Page 17: Battery
• The batteries carry a six-month manufacturer's warranty. This warranty only covers issues relating to manufacturing faults, and not faults relating to failure to recharge the batteries as instructed above. Active Mobility | xtaga Impala | User Manual...
Page 18 The improper layout of the wiring system may cause the wires to pinch in the battery box and result in  Warning an electronic system failure. 2. Be sure the battery wires are connected to their right battery terminal. Active Mobility | xtaga Impala | User Manual...
Page 19 Suggestion driving distances will be shorter in the winter. If the vehicle is not used for a long time, please charge the battery at least every week. 4. Replace both batteries together. Active Mobility | xtaga Impala | User Manual...
Page 20: Inspection And Maintenance
To make sure your scooter is correctly serviced, take it to your dealer for regular maintenance checks. This should be at intervals of six months after the first inspection after one month. Your dealer may charge a fee for this service. Active Mobility | xtaga Impala | User Manual...
Page 21 • Do not use petrol, solvents, or vaporizing solution as  Suggestion these may deform or damage the shrouds. • Do not use wax. Active Mobility | xtaga Impala | User Manual...
Page 22: Storage
Lift the scooter by the chassis, and not by the bumpers. Lifting the scooters by the bumper could cause damage or injury. • For your safety, always ask for help if required. You will need 2 or 3 persons when moving or lifting the vehicle. Active Mobility | xtaga Impala | User Manual...
Page 23: Trouble Shooting & Specification
Maximum driving distance is based on an ambient temperature of 20 C, a 75kg driver and a brand new fully NOTE charged battery and constant driving speed at 6.4 km/h with 70% battery power discharged. Active Mobility | xtaga Impala | User Manual...
Page 24: Warranty
All figures, measurements and capacities shown in this manual are approximate and do not constitute specifications. Authorized Service Agent: Active Mobility Unit 8, 110-120 Silverwater Rd, Silverwater NSW 2128 (02) 9649 2111 Active Mobility | xtaga Impala | User Manual...
