- Page 1 Benutzerhandbuch User Guide Manuel d‘utilisation Manuale d‘uso Manual del usuario F A N T I C C a b a l l e r o 1 2 5...
- Page 2 I n s t a l l a t i o n F A N T I C C a b a l l e r o 1 2 5 1. Install the display unit and route the CUMPAN cable from the cockpit to the battery Example mounting position Example mounting position 2.
- Page 3 3. Connect RPM signal cable » Locate 2-pin connector (1) (2 white wires) behind the filter box » Connect black cable (2) from CUMPAN with branch connector (3) to white cable (4) 4. Connect gear sensor plug » Locate 2-pin connector with green-yellow cable...
- Page 4 » Disconnect blue cable from the connector » Insert green-yellow cable from step 4 instead 6. Insert the blue cable from step 5 into the enclosed green connector (1) and connect it to the 6-pin connector (2) on the motor side (purple cable) CUMPAN...
- Page 5 English 7. On the 6-pin connector, swap the white cable with the pink cable Final allocation:...
- Page 6 B E R O T E C 8. Connect the green gear sensor plug (1) from the CUMPAN to the 6-pin plug (2) on the engine side 9. Connect the gear sensor plug with the black-white cable CUMPAN...
- Page 7 English 10. Insert engine temperature sensor (M6x20) » left engine side on cylinder, upper screw on water pump 11. Power connection → Ground connection (CUMPAN and gear sensor plug) → 12V line CUMPAN → 12V line gear sensor plug →...
- Page 8 BEROTEC GmbH Georg-Schlatter-Straße 10 75031 Eppingen +49 7262-6168573 info@berotec.de www.berotec.de...
