PCB Piezotronics ICP 339B32 Installation And Operating Manual page 16

4
PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
B
A
4
3

.47 [11.9]
.28 [7.1]
3
2
MINI 4-PIN CONNECTOR
8-36 UNS - 2A
Y-AXIS OUTPUT
GROUND
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES DIMENSIONS IN MILLIMETERS
[ IN BRACKETS ]
DECIMALS XX ±.03 DECIMALS X ± 0.8
XXX ±.010 XX ± 0.25
ANGLES  2 DEGREES ANGLES  2 DEGREES
FILLETS AND RADII FILLETS AND RADII
.003 - .005 0.07 - 0.13
2
1
REVISIONS
REV DESCRIPTION
NR RELEASED TO DRAFTING
Z-AXIS OUTPUT
+Z
X-AXIS OUTPUT
DRAWN CHECKED ENGINEER
KRM 11/21/16 JDM 11/21/16 RMB 11/21/16
3425 WALDEN AVE. DEPEW, NY 14043
TITLE
(716) 684-0001 E-MAIL: sales@pcb.com
OUTLINE DRAWING
DWG. NO.
MODEL 339B32 CODE
IDENT. NO.
TRIAXIAL ACCELEROMETER
52681
SCALE:
1
DIN
46175
B
A
65950
6X SHEET 1 OF 1
