- Page 1 KAIXIN W1/W2 B Mode Ultrasonic Scanner (Vet) User’s Manual Xuzhou Kaixin Electronic Instrument Co., Ltd.
- Page 2 Statement Kaixin has the final explanation right of this user’s manual. Kaixin was considered responsible for the safety, reliability and performance in case of meeting all the following requirements: 1. Assembly, expansion, readjustment, improve and repair are all performed by professionals recognized by Kaixin;...
- Page 3 This user’s manual contains warnings for predictable dangers. Users shall also exercise care at any time to be aware of the dangers unforeseen in this manual. Kaixin shall not be liable for the damages and losses arising out of neglecting to follow the operation instructions herein described.
- Page 4 B Mode Ultrasonic Scanner User’s Manual V1.00 Safety Cautions 1. Warning Symbols and Definitions The following warning symbols are used in this manual to indicate safety level and other important items. Please remember these symbols and understand the meaning as you read this user’s manual. These symbols convey specific meanings as detailed in the table below: Symbols &...
-
Page 5: Table Of Contents
User’s Manual V1.00 Contents Chapter 1 Overview........................- 6 - 1.1 Introduction..........................- 6 - 1.2 Appearance (take W1 as an example)..................- 6 - Chapter 2 Technical Specifications.....................- 7 - 2.1 Technical Data.........................- 7 - 2.2 Primary Functions........................- 7 - Chapter 3 System Configuration....................- 8 -... - Page 6 B Mode Ultrasonic Scanner User’s Manual V1.00 8.3.9 Full screen display....................... - 18 - 8.4 Body Mark selection......................- 18 - 8.5 Save image..........................- 18 - 8.6 One-key storage........................- 18 - 8.7 View images..........................- 18 - 8.8 Play back and Measurement....................- 19 - 8.9 Notes.............................- 19 - 8.10 Arrow mark.........................
-
Page 7: Chapter 1 Overview
Overview 1.1 Introduction W1, W2 are veterinary B Mode Ultrasonic Scanners, which are equipped with 3.5MHz convex array, 7.5MHz line array wireless probes. Wireless probe connects to ultrasound APP on the Pad or Smart Phone via Wi-Fi to form an ultrasonic diagnostic instrument for ultrasonic diagnosis. -
Page 8: Chapter 2 Technical Specifications
B Mode Ultrasonic Scanner User’s Manual V1.00 Chapter 2 Technical Specifications 2.1 Technical Data 1. Gray scale: 256 2. Adapter ratings: 100-240V~, 50-60Hz, 25VA 3. Output of adapter: DC5.0V 3.0A 4. Main unit size: approx. 165 * 80 * 30mm3 (L * W * H) 5. -
Page 9: Chapter 3 System Configuration
B Mode Ultrasonic Scanner User’s Manual V1.00 Chapter 3 System Configuration 3.1 Typical configuration 1. Main unit W1 or W2 1 unit 2. Ultrasonic APP software 1 PC 3. USB cable 1 PC - 8 -... -
Page 10: Chapter 4 Operation Condition
B Mode Ultrasonic Scanner User’s Manual V1.00 Chapter 4 Operation Condition 4.1 Power supply Adapter ratings: 100-240V~, ±10% Frequency: 50-60Hz±1Hz Rated input: DC5.0V 2.0-3.0A 4.2 Operation environment Ambient temperature: 10℃-40℃ Relative humidity: 30%-75% (without condensation) Atmospheric pressure: 700hPa-1060hPa. Altitude: < 2000 m Overvoltage: Overvoltage CategoryⅡ... -
Page 11: Chapter 5 System Check
Warning: 1. When the equipment works abnormally, do stop working, turn off the power and check the reason, then contacts the KAIXIN Company about it. 2. Turn off power after ultrasonic diagnostic operation. 5.1 Place equipment Please carefully read through and fully understand the safety cautions before moving and placing the equipment. - Page 12 3. If the charger is wet, soaked or severe moisture, please stops using and contact the KAIXIN or agents. 4. Do not use the equipment while charging, may cause a safety risk. 5. Use unapproved or incompatible power supply, charger or battery, which may cause a fire, explosion or other hazards.
-
Page 13: Chapter 6 Getting Started
B Mode Ultrasonic Scanner User’s Manual V1.00 Chapter 6 Getting Started Attention : If you cannot install “Ultrasound APP”, it may be caused by 360 software block, please check whether the phone has been installed 360 software, if installed, please uninstall. -
Page 14: Change The Language For App
5-6 seconds and then open the ultrasound APP. 2. The network ID of W1 or W2 equipment is the default number displayed on the shell of W1 or W2. For example, W1 shows “W11702806” or W2 shows “W21702906”. -
Page 15: Chapter 7 Settings
B Mode Ultrasonic Scanner User’s Manual V1.00 Chapter 7 Settings In the frozen state, press key to display Setup dialog box, as shown below. In the Setup dialog box, you can set company name, gray ruler, grid, goat variety, wireless channels; also can view the software version. -
Page 16: Set Wireless Channel
B Mode Ultrasonic Scanner User’s Manual V1.00 7.5 Set wireless channel 1. In the Setup dialog box, slide up and down to select the Wireless; 2. Then slide up and down to select the channel, the equipment supports AUTO, Channel1 to Channel13;... -
Page 17: Chapter 8 Functional Operation
B Mode Ultrasonic Scanner User’s Manual V1.00 Chapter 8 Functional Operation 8.1 New Patient 1. In real-time state, press key to display New Patient dialog box, as shown below; 2. The cursor is in the input box, tap the text input box, the onscreen keyboard will automatically open;... -
Page 18: Image Quality Adjustment And Image Control
8.3.6 Frequency adjustment (Frequency conversion) In real-time state, repeatedly press key to convert the frequency. The frequency value is displayed at “Freq:” on the right side of the image area. W1 frequency conversion is 2.0/2.5/3.5/5.0; W2 frequency conversion is 6.0/6.5/7.5/9.0. 8.3.7 Image Post-process adjustment In real-time state, repeatedly press key to realize image post-process. -
Page 19: Full Screen Display
8.6 One-key storage Freeze the current image; press and hold key on the W1 or W2 equipment for a few seconds until “Save Success” prompt appears; the file name is automatically created according to the current date and time of this equipment. -
Page 20: Play Back And Measurement
B Mode Ultrasonic Scanner User’s Manual V1.00 8.8 Play back and Measurement Play back In real-time state, the system is always saving the scanning image. The playback images are for a period time images before freeze. Freeze image, press key to enter the automatic playback status, and then press key to return to manual playback status, press keys to choose the image needed playback. -
Page 21: Chapter 9 B General Measurement
B Mode Ultrasonic Scanner User’s Manual V1.00 Chapter 9 B General Measurement In B, B|B frozen mode, press key to enter B general measurement dialog box, as shown below: Attention: The accuracy of software measurement: distance measurement ≤ 0.1mm; area measurement ≤... -
Page 22: Trace Measurement
B Mode Ultrasonic Scanner User’s Manual V1.00 9.2 Trace measurement Function: measure the circumference/area of a confined area with the trace method. Operation steps: 1. In the B general measurement dialog box, slide your finger up or down to select 【 Trace】 item, click OK to start the trace measurement and the positioning icon appears on the screen;... - Page 23 B Mode Ultrasonic Scanner User’s Manual V1.00 2. Tap the starting point of the measurement with your finger, appear white mark “ ”, the location of the white mark as the first point of the measurement; 3. Along the boundary of the measurement range, continue to tap with your finger to mark the required points;...
-
Page 24: Chapter 10 M General Measurement
B Mode Ultrasonic Scanner User’s Manual V1.00 Chapter 10 M General Measurement In B|M, M frozen mode, press key to enter M general measurement dialog box, as shown below: 10.1 Slope measurement Function: measure the slope (speed) between two points on the M image and at the same time measure the depth and time between the two points. -
Page 25: Time Measurement
B Mode Ultrasonic Scanner User’s Manual V1.00 6. Press key to clear measurement mark and the result. 10.3 Time measurement Function: measure the time interval between two points in M image. Operation steps: 1. In the M general measurement dialog box, slide your finger up or down to select【Time】item, click OK to start the time measurement and the positioning icon appears on the screen;... -
Page 26: Chapter 11 Obstetric Measurement
B Mode Ultrasonic Scanner User’s Manual V1.00 Chapter 11 Obstetric Measurement Obstetric calculations are generally performed in B mode. When the measurement is beyond the image area, the measured value is not displayed as an invalid value. In B, B|B frozen mode, press to enter obstetric measurement dialog box, as shown below: 11.1 Measurement and Calculation items Measure the gestational age and estimated date of confinement for bovine, equine, ovine, canine, feline,... - Page 27 B Mode Ultrasonic Scanner User’s Manual V1.00 2. Measure fat thickness. Slide the green mark “ ” with your finger to the endpoint, now the mark can only move vertically, the fat thickness value is displaying on the right side of the screen in real-time, tap the Confirm key , the fat thickness value is displayed on the right side of the screen;...
-
Page 28: Chapter 12 System Maintenance
B Mode Ultrasonic Scanner User’s Manual V1.00 Chapter 12 System Maintenance The system maintenance should be performed by the user and service engineer. Users shall be in full charge of maintenance and operation of the system after purchasing the product. Warning : The following maintenance must not be performed when inspecting. -
Page 29: Use And Maintenance For The Rechargeable Battery
1. Only use battery provided by KaiXin Company. 2. The equipment has an internal rechargeable battery. Don’t attempt to replace the battery yourself; you may damage the battery or the equipment. The battery should be replaced only by KAIXIN authorized service personnel. -
Page 30: Troubleshooting
International Trade Dept of Kaixin for support. If the following problems occur after turned on the equipment, try to make corrections following the methods in the table. If the problem remains unsolved, please contact International Trade Dept of Kaixin for support. -
Page 31: Maintenance By Service Personnel
12.4 Maintenance by service personnel To ensure the equipment performance and safety, it must be checked after using 1 year. When check the equipment, please consult the Kaixin company dealers, as they need to have professional technology engineers. Inspect sorts... -
Page 32: Storage And Transportation
B Mode Ultrasonic Scanner User’s Manual V1.00 Chapter 13 Storage and Transportation Storage and Transportation 1. If the equipment is stored over 3 months, take out the equipment from the packing case, connect it to power supply for 4 hours, and then disconnect the power. Place it in the case again following the direction indicated by arrows on the package. - Page 33 KAIXIN ELECTRONIC XUZHOU KAIXIN ELECTRONIC INSTRUMENT CO., LTD. Kaixin Mansion, C-01. Economic Development Zone, Xuzhou, Jiangsu, China Post Code: 221004 Tel: +86-516-87732932/87733758 Fax: +86-516-87732932/87792848 Website: http://www.kxele.com E-mail: info@kxele.com Information contained in this manual is subject to change without further notice.
