SCAN EXAM™

Digital imaging plate scanner

User Manual

224361-PTU rev. 1

ENGLISH

Table of Contents

Need help?

Do you have a question about the SCAN EXAM and is the answer not in the manual?

Questions and answers

Lucy Birss

July 15, 2025

Hi We purchased a scan exam in 2020 from Australian Imaging. Last week a plate was put into the unit incorrectly and jammed. We called Dental Concepts (they used to look after our old digora unit) they came in a removed the plate which was bent. They inspected and tested – the test was done taking an image of a mirror which looked a bit lacking in contrast but ok. Later that day we put through a **** wing radiograph which was grainy an unreadable. We tested using other x-ray units to rule them out as the problem all images came out grainy and un-unusable. The technician from dental concepts came again and checked everything again and did not know what the issue was so took it back to be sent off for repair. They have now informed me that the company they use is no longer in business. I also tried Australian Imaging they seem to be out of business. I called Henry Schein Halas they very unhelpful and will not assist with the unit. Can you help at all?

Summary of Contents for DEXIS SCAN EXAM

Page 1 SCAN EXAM™ Digital imaging plate scanner User Manual 224361-PTU rev. 1 ENGLISH...
Page 3 Copyright Copyright © 2022-05 by PaloDEx Group Oy. All rights reserved. DEXIS™ is a registered trademark or a common law trademark of Dental Imaging Technologies Corporation. Scan eXam™ and CLINIVIEW™ are either registered trademark or trademark of PaloDEx Group Oy in the United States and/or other countries.
Page 5: Table Of Contents
Contents 1. Scan eXam™ ..................... 1 1.1 Introduction ....................1 1.2 System installation ..................2 2. Intraoral imaging plate unit ................4 2.1 Main parts and controls ................4 2.2 Accessories ....................5 2.3 Display symbols and what they mean ............7 3 Using the system ....................11...
Page 6 A.5 Electromagnetic Compatibility (EMC) tables ..........A-5 Appendix B. Installation and setup ..............B-1 B.1 System installation ...................B-1 B.2 Connecting the unit to a PC / LAN ............B-2 B.3 Setup options in CLINIVIEW ..............B-10 B.4. Scan eXam settings with DTX Studio™ Core ........B-21 B.5 Troubleshooting ..................B-26...
Page 7: Scan Exam
1. Scan eXam™ 1. Scan eXam™ 1.1 Introduction This manual describes how to use the Scan eXam digital imaging plate scanner (the unit) which is part of the digital intraoral imaging plate system (the system). The complete system comprises the...
Page 8: System Installation
1. Scan eXam™ Only use the imaging plates, protective covers and hygiene bags supplied by the manufacturer of the unit. Please read the section 7. Warnings and precautions before using the unit. 1.2 System installation Positioning the unit Do not position the unit in direct sunlight or near bright light.
Page 9 1. Scan eXam™ Positioning the PC The PC connected to the unit should not be used in the patient environment. The minimum horizontal distance between the patient and the PC is 1.5 m (4.5 ft). The minimum vertical distance between the patient and the PC is 2.5 m (6.5 ft).
Page 10: Intraoral Imaging Plate Unit
2. Intraoral imaging plate unit 2. Intraoral imaging plate unit 2.1 Main parts and controls SCAN EXAM...
Page 11: Accessories
Standard (STD) version. The standard version has no identiﬁ cation mark on the active side of the plate. Hygiene bags. For IPs 0, 1, 2 , 3 and Occlusal 4C. Never use hygiene bags more than once. Risk of infection. SCAN EXAM...
Page 12 IP storage box For storing IPs safely and conveniently. Microﬁ ber cloth For cleaning IPs. IP holders For bitewing, periapical and endodontic exposures (optional, not included) See section 3.4 Imaging plate holders for more information. SCAN EXAM...
Page 13: Display Symbols And What They Mean
PC (e.g. PC number 2). UV disinfection in progress The system is carrying out automatic UV disinfec- tion cycle. Remaining cycle time will be displayed. Occlusal 4C mode System is in occlusal projection imaging mode. SCAN EXAM...
Page 14 System is in occlusal projection imaging mode, insert second size 3 IP. Unit door Protective cover and imaging plate Yellow: remove protective cover Imaging plate Yellow: wrong way round, rotate Protective cover Remove / disconnect Insert / connect SCAN EXAM...
Page 15 Unit in UV disinfection mode, the remaining/elapsed disinfection time is shown. Unit in erasing mode Check Something wrong or take alternative action. Dental imaging software Software not open, not ready or waiting for user ac- tion. Unit connection Not connected or connection not working. SCAN EXAM...
Page 16 2. Intraoral imaging plate unit Rotate Error state and error number Check documentation supplied with the unit Unit in service mode (Service technicians only) SCAN EXAM...
Page 17: Using The System
See section “B.3 Setup options in CLINIVIEW” or “B.4. Scan eXam settings with DTX Studio™ Core” for more information. 3.2 Preparing the system 1. PC: Switch on the PC connected to the unit.
Page 18 When the status light turns green and ready ani- mation, indicating IP insertion, appears on the unit display, the unit is ready to use (in the ready state). NOTICE: If the ready animation does not appear, check the system setup described in the installation instructions. SCAN EXAM...
Page 19: Preparing An Ip For Exposure
3. Turn the protective cover and IP over so that the black side of the protective cover is uppermost. This makes it easier to slide the protective cover and IP into the hygiene bag. SCAN EXAM...
Page 20 7. Turn the sealed hygiene bag over and check that the IP and protective cover are in the cor- rect position. You must be able to see the light side of the pro- tective cover and the metal disk on the IP. SCAN EXAM...
Page 21: Imaging Plate Holders
Problems caused by manually positioning the IP include: incorrect vertical alignment distortion cone cut oﬀ poor projection standardization inferior image quality For more information on imaging plate holders and systems, contact you dealer. SCAN EXAM...
Page 22: Taking An Exposure
X-ray unit being used and may vary by ±1 step from the values in the following table. If the exposure time is too short images will be noisy. Such images may still usable for some diagnostic purposes. SCAN EXAM...
Page 23 3. Protect yourself from radiation and take the exposure. 4. After the exposure remove the sealed hygiene bag from the patient’s mouth. CAUTION: If there is a risk of cross contamination, wash, disinfect and dry the hygiene bag before open- ing it. SCAN EXAM...
Page 24: Reading An Imaging Plate
2. Keep the IP in the protective cover so that you do not touch the IP or allow it to be exposed to ambient light, and then slide the protective cover and IP out of the hygiene bag. NOTICE: Dispose of the used hygiene bag. SCAN EXAM...
Page 25 If after repositioning the IP it still does not slide into the unit press the Start key to manually switch the unit from the standby to the ready state and the IP will then slide into the unit when the protective cover is removed. SCAN EXAM...
Page 26 (it is not ejected into the plate collector). When the IP is in the plate carrier the IP is easier to handle and stricter hygiene measures can be observed. Refer to Appendix B.3.4 Workﬂ ow page. SCAN EXAM...
Page 27 3. Using the system After the IP has been ejected or removed the ready animation will reappear on the display. The unit is now ready to read the next IP. SCAN EXAM...
Page 28 Wait until the device is released or ready. GRAY - The device cannot be found, is switched oﬀ , disconnected or is still connecting. Check that the device is on and connected to the PC and wait for the connection. SCAN EXAM...
Page 29: Removing Ips From The Plate Collector
The unit will automatically exit the standby mode as soon as a new imaging plate is inserted into the unit or when the Start key is pressed. After four hours (default) the unit will exit the stand- by mode and automatically shut down. SCAN EXAM...
Page 30: Retrieve Last Image
NOTICE: You may also select diﬀ erent parameters (for example resolution) for the image to be re- trieved. 3. PC: Click Save to close the Setup window. The last processed image is transferred to the PC. SCAN EXAM...
Page 31: Shutting Down The Unit
(4 seconds) the start key. NOTICE: If there is an untransferred image in the unit’s memory the unit cannot be shut down. The im- age must be transferred ﬁ rst. Refer to section 3.9 Retrieve last image. SCAN EXAM...
Page 32: Ip Erasing Mode (Initial Erasing Of The Ips)
The IP can now be used to take an exposure. 4. To exit the erasing mode, either wait 15 sec- onds for the unit to automatically exit the erasing mode or press and hold down the Start key until the erase animation disappears. SCAN EXAM...
Page 33: Taking An Occlusal Projection Image
1. PC: Set occlusal image processing to Occlusal 4C from the Device settings. For more information, see sections “B.3 Setup options in CLINIVIEW” and “B.4. Scan eXam settings with DTX Studio™ Core”. 2. Place two size 3 IPs into their corresponding protective covers.
Page 34: Errors And Warnings
IP is read it indicates that the image may not be within the factory set quality limits. If the image looks ﬁ ne, no action is necessary. If the message appears frequently, contact your autho- rized distributor for assistance. SCAN EXAM...
Page 35 3. Using the system SCAN EXAM...
Page 36: Handling And Care Of Imaging Plates
4. Handling and care of imaging plates 4. Handling and care of imaging plates The correct use, handling, cleaning and storage of imaging plates guarantees the best image quality and maximum service life of the imaging plates. 4.1 General • X-ray exposures DO NOT cause IPs to age.
Page 37: Cleaning
4. Handling and care of imaging plates 4.3 Cleaning If IPs are handled and stored correctly cleaning should not be necessary or can be kept to an abso- lute minimum. Clean the IP if there you see any visible marks or stains (which are not obvious scratches) on the im- age or if there is a reason to believe that the IP is contaminated.
Page 38: Replacement
4. Handling and care of imaging plates 4.5 Replacement Replace an IP if: • the image shows marks, spots or dots, which still appear on images even after the IP has been properly cleaned. • the IP is mechanically damaged (scratched), badly bent or show any signs of deterioration af- fecting the image quality.
Page 39: Unit Care And Maintenance
Do not use any disinfecting sprays as the vapor could ignite and cause injury. Disinfecting techniques for both the unit and the room where the unit is used must comply with all local and national regulations and laws concerning such equipment and its location. SCAN EXAM...
Page 40: Maintenance
The unit includes some or all of the following parts that are made of or include materials that are non-environ- mentally friendly or hazardous: - electronic circuit boards - electronic components - UV lamp (Hg) SCAN EXAM...
Page 41: Symbols That May Appear On The Unit And Accessories
Refer to operating instructions for more information. The operating instructions can be supplied electroni- cally or in paper format. CLASS II equipment (Double insulated electrical appliance) Type B applied part Direct current Eternet connector RJ45 straight cable Indoor use SCAN EXAM...
Page 42 This symbol indicates that the waste of electrical and electronic equipment must not be disposed as unsorted municipal waste and must be collected separately. Please contact an authorized represen- tative of the manufacturer for information concerning the decommissioning of your equipment. SCAN EXAM...
Page 43 6. Symbols that appear on or in the unit SCAN EXAM...
Page 44: Warnings And Precautions
This unit can interfere with other devices due to its EMC characteristics. • Other devices can interfere with this unit due to their EMC characteristics. • Unit not suitable for use in the presence of ﬂ ammable anaesthetic mixture with air or with oxygen or nitrous oxide. SCAN EXAM...
Page 45 The PC / Ethernet switch to which unit is connected to, should be approved appropriately (e.g. EN 60950, IEC 60950, UL 60950). After installation check that the IEC 60601-1 leakage current levels are not exceeded. SCAN EXAM...
Page 46 The PC and any other external devices shall not be connected to an extension cable. • If the unit needs to be connected to a multiple socket-outlet, it shall not be placed on the ﬂ oor. • Multiple extension cables shall not be use. SCAN EXAM...
Page 47: Appendix A. Technical Specifi Cations
Intended use The Scan eXam system is intended to be used only by dentist and other qualiﬁ ed dental professionals to process X-ray images ex- posed to the imaging plates from the intraoral complex of the skull.
Page 48: Imaging Plates And Hygiene Bags
Imaging plates contain small amount of Barium and should be considered hazardous or special waste. At the end of the useful working life, make sure to follow the national and local regulations regarding disposal of the imaging plates. Never use damaged imaging plates! SCAN EXAM...
Page 49: Main Dimensions
Single use only. Do not reuse. Disposal Observe relevant national requirements. A.3 Main dimensions SCAN EXAM...
Page 50: Device Labels
The device labels are located at the rear of the device. Type label: NOTICE! The type label shown below is for refer- ence only. The texts may be diﬀ erent in the actual label. CLASS 1 Laser product warning label: SCAN EXAM...
Page 51: Electromagnetic Compatibility (Emc) Tables
Exceptions for professional healthcare facility envi- ronment: Not to be used or installed near active HF SURGICAL EQUIPMENT and the RF shielded room of an ME SYSTEM for magnetic resonance imag- ing, where the intensity of EM DISTURBANCES is high. SCAN EXAM...
Page 52 Exceptions for professional healthcare facility en- vironment: Not to be used or installed near active HF SURGICAL EQUIPMENT and the RF shielded room of an ME SYSTEM for magnetic resonance imaging, where the intensity of EM DISTURBANC- ES is high. SCAN EXAM...
Page 53 61000-4-8 and/ or hospital environment. The device shall not be used closer than 15cm to sources of 50/60Hz magnetic ﬁ eld. NOTICE! UT is the a.c. mains voltage prior to application of the test level. SCAN EXAM...
Page 54 ** Over the frequency range 150 kHz to 80 MHz, ﬁ eld strengths are less than 3 V/m. The Recom- mended Separation Distances are listed in the next table. NOTICE! These guidelines may not apply in all situations. Electromagnetic propagation is af- fected by absorption and reﬂ ection from structures, objects, and people. SCAN EXAM...
Page 55 WARNING! Use of accessories, transducers and cables other than those speciﬁ ed or provided by the manufacturer of this equipment could result in increased electromagnetic emissions or decreased electromagnetic immunity of this device and result in improper operation. SCAN EXAM...
Page 56 Interference may occur in the vicinity of equipment marked with the following symbol: A-10 SCAN EXAM...
Page 57: Appendix B. Installation And Setup
The PC(s) connected to the unit should not be used in the patient environment. The minimum horizontal distance between the patient and the PC(s) is 1.5 m (4.5 ft). The minimum vertical distance between the patient and the PC(s) is 2.5 m (6.5 ft). SCAN EXAM...
Page 58: Connecting The Unit To A Pc / Lan
The detection starts automatically at the software application install. 1. If the software is already installed or fails to start the Add Device Wizard automatically, launch it from the Image Capturing -window. 2. Select Settings from the Image capturing -window. SCAN EXAM...
Page 59 B. Installation and setup 3. This will open a Settings dialog. Click Add to launch the Add Device Wizard. 4. Select the desired device from the list and press Finish to complete the connection conﬁ guration. SCAN EXAM...
Page 60 3. The Add Device manually window will appear. The window displays a pictorial list of all the devices that can be connected to the PC. 4. Click the picture of SCAN EXAM to select it. Then click Next, or double click the picture of the device.
Page 61 The connection to the unit will be checked. After the connection has been checked and the device connected, click Finish. NOTICE: If you wish to change the IP-address of the device click the Change device IP address... button and follow the onscreen instructions that appear. SCAN EXAM...
Page 62 See the instructions in chapter “B.3 Setup options in CLINIVIEW” to enable the Express Share. The procedure must be repeated at all workstations operating the unit. SCAN EXAM...
Page 63 B. Installation and setup B.2.1.4 Activate the Scan eXam unit From the image capturing window of the imaging application software, activate the unit by clicking the appropriate device button. Before activating the device, observe the current status of the device. Before processing the imaging plates, make sure that the unit is READY.
Page 64 - If the device does not appear on the list, click Scan network. - If the device still does not appear on the list, add the device manually by clicking Manually search device and ﬁ ll the prompted device information ﬁ elds. SCAN EXAM...
Page 65 B. Installation and setup 5. Select the Scan eXam device from the list. SCAN EXAM...
Page 66: Setup Options In Cliniview
B. Installation and setup B.3 Setup options in CLINIVIEW The Scan eXam setup options allow you to conﬁ gure the unit to the user’s clinical preferences. From the imaging application software you are using select unit Device settings/Device page (for more instruction on how to access setup page, review application software manual).
Page 67 ﬁ rst PC releases the device. The timeout feature ensures that no device can be permanently reserved and unavailable to other users. The device can be reserved in advance from another PC. SCAN EXAM B-11...
Page 68 If required you can select diﬀ erent parameters (e.g. resolution, show image preview etc.) for the image to be retrieved. 3. PC: Click OK to close the Setup page. The last read image will be transferred to the PC. B-12 SCAN EXAM...
Page 69 -100 ... 100 Contrast -100 ... 100 Gamma -100 ... 100 Sharpening 0 ... 100 Noise reduction Oﬀ , Classic, Progressive Click Save to save any adjustments. Click Reset to reset the image adjustment to the factory settings. SCAN EXAM B-13...
Page 70 The Start delay: option allows the start delay time to be selected. Short = approximately 0.2 seconds Medium = approximately 0.4 seconds B-14 SCAN EXAM...
Page 71 “wake up” from the standby mode as soon as the sensor detects a movement within a distance of 20 cm. If it is NOT selected the unit will “wake up” when the start is pressed. SCAN EXAM B-15...
Page 72 Select this and audible signal will be heard when the scanner enters the standby mode. Shutdown after (minutes) Allows you to select the length of time the scanner will remain unused before the unit automatically switches itself oﬀ . B-16 SCAN EXAM...
Page 73 The remaining UV disinfection time appears on the unit display. Disabled: Switched oﬀ UV disinfection so that it does not operate. Also, all warning messages related to UV lamp status are discarded. SCAN EXAM B-17...
Page 74 UV disinfection will automatically stop after 15 minutes. If you wish to stop manual UV disinfection before the complete cycle is ﬁ nished, press the Manual UV disinfection control / Cancel key or press and hold down (4 seconds) the start key. B-18 SCAN EXAM...
Page 75 This will cancel the Occlusal 4C mode for this operation and produce a single size 3 image. Size 3 image from each size 3 plate This option allows size 3 IPs to read as individual IPs. SCAN EXAM B-19...
Page 76 B.3.6 Default Exposure Values page If required, the exposure values used to take an exposure can be entered into these ﬁ elds. The values will be added to the image metadata. Voltage (kV) Current (mA) Time (s) B-20 SCAN EXAM...
Page 77: Scan Exam Settings With Dtx Studio™ Core
B. Installation and setup B.4. Scan eXam settings with DTX Studio™ Core NOTICE: For most accurate and up to date information, refer to DTX Studio™ Instructions for Use. 1. Sign into DTX Studio™ Core with the same user credentials as you use to login to DTX Studio™.
Page 78 Device name: Device identiﬁ cation shown in DTX Studio™ software. • Image processing computer: Normally, the workstation where DTX Studio™ Core is in- stalled. • Device color: Device identiﬁ cation shown in DTX Studio™ software. • Autorelease timeout: default: 40s B.4.2. Power settings B-22 SCAN EXAM...
Page 79 Enable or disable if the device serial number is added to all images. • Add default exposure values to metadata: En- able or disable if the device’s default exposure values (kV, mA, s) are saved to image metadata. SCAN EXAM B-23...
Page 80 (default) in all conditions. B.4.4 Workﬂ ow settings In Workﬂ ow settings, you can view and set the fol- lowing: Readout start: • Manual: Imaging plate processing starts after start button is pressed. B-24 SCAN EXAM...
Page 81 • Occlusal 4C: Two sequential size 3 imaging plates are stitched together to create a single occlusal image. Preview time Set the time how long the preview image is shown on the device display (default 5s). SCAN EXAM B-25...
Page 82: Troubleshooting
Replace if faulty. PROBLEM Animation displaying either Unit connection or Dental imaging software (ﬂ ashing yellow) appear on the unit display and the unit will not work. CAUSE / SOLUTION • Defective RJ45 cable. Replace. B-26 SCAN EXAM...
Page 83 If the Insert animation appears on the unit display while inserting the IP but the unit does not insert the IP into the unit nor start scanning, the reﬂ ective sensor in the unit door is faulty (refer to the service manual). SCAN EXAM B-27...
Page 84 If the problem persists ask your network administrator for assistance. iii. Network connection not functioning or not stable due to LAN signal quality problems. Install a network switch between the unit and PC or network socket. B-28 SCAN EXAM...
Page 85 The unit display is not active but the power on / oﬀ status light is on, green or orange. CAUSE / SOLUTION • Green LED - defective display or its cabling. Replace • Orange LED - unit is in standby (energy save) mode. SCAN EXAM B-29...
Page 86 Contact your PaloDEx Group Oy representative for the most current information. Copyright © by PaloDEx Group Oy. All rights reserved. DEXIS™ is a registered trademark or a trademark of Dental Imaging Technologies Corporation. Headquarters PaloDEx Group Oy Nahkelantie 160 | FI-04300 Tuusula | FINLAND Tel.
