Ironton 37552 Owner's Manual

5FT. x 8FT. HD TRAILER
WITH 5.30-12 TIRES
OWNER'S MANUAL
WARNING:
Read carefully and understand all INSTRUCTIONS
before operating. Failure to follow the safety rules and other basic
safety precautions may resultin serious personal injury.
Item#s 37552
Thank you very much for choosing an Ironton Product! For future reference, please complete the
owner's record below:
Model: _______________ Purchase Date: _______________
Save the receipt, warranty and these instructions. It is important that you read the entire manual
to become familiar with this product before you begin using it.
This trailer is designed for certain applications only. The distributor cannot be responsible for
issues arising from modification. We strongly recommend this trailer is not modified and/or used
for any application other than that for which it was designed. If you have any questions relative to
a particular application, DO NOT use the trailer until you have first contacted distributor to
determine if it can or should be performed on the product.
For technical questions, please call 1-800-222-5381.
WARNING:
Read carefully and understand all INSTRUCTIONS before operating.
Failure to follow the safety rules and other basic safety precautions may result in serious
personal injury.
Save these instructions in a safe place and on hand so that they can be read when required.
Keep these instructions to assist in future servicing.

TECHNICAL SPECIFICATIONS

DESCRIPTION
ITEM
Tires 5.30-12 Tubeless
Bed Dimensions 5-ft. x 8-ft.
Ball/Coupler Size 2 Inch
Load Capacity 1,715 lbs. max.
GVWR 1,980 lbs.

GENERAL SAFETY REGULATIONS

WARNING:
Read and understand all instructions. . Failure to follow all instructions
listed below may result in electric shock, fire and/or serious injury.
WARNING:
The warnings, cautions, and instructions discussed in this instruction
manual cannot cover all possible conditions or situations that could occur. It must be
understood by the operator that common sense and caution are factors that cannot be built
into this product, but must be supplied by the operator.
• Keep the work area clean and dry. Damp or wet work areas can result in injury.
• Keep children away from work area. Do not allow children to handle this product.
• Always wear ANSI-approved safety glasses and heavy-duty work gloves during assembly
and use. Do not wear loose clothing or jewelry which can get caught in moving parts.
• Check for damaged parts. Before using this product, carefully check that it will operate
properly and perform its intended function. Check for damaged parts and any other conditions
that may affect the operation of this product. Replace damaged or worn parts immediately.
• Do not overreach. Keep proper footing and balance at all times to prevent tripping, falling,
back injury, etc.
• DO NOT use this trailer when tired or distracted.
• Industrial applications must follow OSHA requirements.
5FT. x 8FT. HD TRAILER WITH 5.30-12 TIRES
OWNER'S MANUAL
1 of 11
