Network Function Edition
(PT-L785U)
This projector has networking functions which allow it to be
controlled through a web browser on a PC.
The controlled items are:
• Projector's settings and adjustment
• Projector's status display
• Transmission of a E-mail message when the projector has a
problem
TQBJ0158

Advertisement

Table of Contents
loading

Related Manuals for Panasonic PT-L785U

Summary of Contents for Panasonic PT-L785U

  • Page 1 This projector has networking functions which allow it to be controlled through a web browser on a PC. The controlled items are: • Projector’s settings and adjustment • Projector’s status display • Transmission of a E-mail message when the projector has a problem TQBJ0158...

  • Page 2: Table Of Contents

    Contents Connecting a PC ...3 System requirements ...3 Connection example ...3 Projector Settings ...4 Network settings screen ...4 Network status screen ...5 Using Web Browser Control ...6 Access procedure ...6 Basic control page ...7 Detail control page ...8 Status information page ...9 Error information page...10...

  • Page 3: Connecting A Pc

    Touching the LAN port with your hand (or body) when you are carrying a static charge may damage the equipment due to a discharge of static electricity. Therefore, be careful not to touch the LAN port or metal parts of the LAN cable. Projector LAN cable (straight)

  • Page 4: Projector Settings

    STANDBY OFF: During standby, the lamp in the projector cannot be turned The default setting is “panasonic” (all lower case). Use the following procedure to change the password. This procedure sets the password which is entered on page 6.

  • Page 5: Network Status Screen

    Network status screen Select [NETWORK] on the screen discussed on the preceding page, then press the [ENTER] button. Use the [ ] buttons to select a parameter, then change its setting. Parameter IDs are identification numbers under which settings are stored. Three different IDs can be stored (LAN1 through LAN3).

  • Page 6: Using Web Browser Control

    Enter “user1” in the user name field, then enter the password in the password field. The default setting is “panasonic” (all lower case). If you have changed the password, enter the new password here. If you forget your password, set a new password using the procedure described on page 4.

  • Page 7: Basic Control Page

    Basic control page This page is the first page displayed when the projector is accessed through a web browser. To move from another page, click [Projector Control], then [Basic control]. Input channel switching Lamp power switching Volume control (+: increase volume;...

  • Page 8: Detail Control Page

    Using Web Browser Control (continued) Detail control page Click [Projector Control], then [Detail control] to display the Detail control page. AUTO SETUP start button Keystone distortion correction (horizontal and vertical) Rough adjustment, fine adjustment Position adjustment (horizontal and vertical) Rough adjustment,...

  • Page 9: Status Information Page

    Status information page Click [Projector Control], then [Status information] to display the Status information page. POWER: ON and OFF VOLUME: 0 to 20 INTERNAL TEMPERATURE: Good, Warning and Caution LAMP RUNTIME: 0 to 1500 hours PROJECTOR TYPE: L785 VERSION: Projector firmware...

  • Page 10: Error Information Page

    Items checked for errors Note: In the case of some errors, the standby status is established in order to protect the projector. "WEB STANDBY" must be set to [ON] to display the error information page. (See page 4.) (continued) is displayed on the status information screen, click it...
  • Page 11 The input air temperature is too high. It may be that the INPUT AIR projector is being used where the ambient temperature is TEMPERATURE high such as near a heating appliance. EXHAUST The air exhaust temperature is too high.

  • Page 12: E-Mail Setup Page

    Using Web Browser Control E-mail setup page With this projector, if a problem occurs or if the lamp usage time reaches a set value, an e-mail message can be sent to one or more preset e-mail addresses (maximum two addresses). Click [Projector Control], then [E-mail set up] to display the E-mail setup page.
  • Page 13 ON/OFF toggling for permission to send e-mail when error occurs ON/OFF toggling ON/OFF toggling for for permission to permission to send e- send e-mail based mail based on air intake on lamp usage time sensor temperature The settings for e-mail address 1 are the same. Button to update settings Destination e-mail address field Change lamp usage...

  • Page 14: Dns Server Setup Page

    Using Web Browser Control DNS server setup page Click [Network Setting], then [DNS Server set up] to display the DNS Server Setup page. Secondary DNS server address Available input characters: Numbers (0 - 9), period (.) (ex. (continued) Primary DNS server address Available input characters: Numbers (0 - 9), period (.) (ex.

  • Page 15: Pop Server Setup Page

    POP server setup page Click [Network Setting], then [POP server set up] to display the POP Server Setup page. Toggling between E n a b l i n g / D i s a b l i n g POP before SMTP POP server user name field POP server name field...

  • Page 16: Adjust Clock Page

    New date field Note: If the time becomes incorrect immediately after setting the correct time, then the battery needs to be changed. Contact the dealer where you bought the projector to have the battery changed. Button to update time and date settings...

  • Page 17: Network Status Page

    Network status page Click [Network Setting], then [Network status] to display the Network status page. MAC address display Set subnet mask Set IP address display display Network status display Network software version display...

  • Page 18: Password Change Page

    This page can be used to change the password entered on page 6. The password can be changed even through the PC. See page 4 for information on changing the password through the projector. Click [Change Password]. Button for erasing all...
