RIED HX-308 Instruction Manual

Special ir zoom camera

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Distributed by

INSTRUCTION MANUAL

SPECIAL IR

ZOOM CAMERA

- Before attempting to connect or operate this product, please read these instructions carefully and

P/N : 388037201

save this manual for future use.

PRINTED IN KOREA

- The design and specifications are subject to change without prior notice to improve product's quality.

Table of Contents

Need help?

Do you have a question about the HX-308 and is the answer not in the manual?

Questions and answers

Summary of Contents for RIED HX-308

Page 1 INSTRUCTION MANUAL SPECIAL IR ZOOM CAMERA Distributed by - Before attempting to connect or operate this product, please read these instructions carefully and P/N : 388037201 save this manual for future use. PRINTED IN KOREA - The design and specifications are subject to change without prior notice to improve product’s quality.
Page 2 manual. The user could lose the authority to operate this Holes in metal, through which insulated wires pass, Disposal of your old appliance CAUTION shall have smooth well rounded surfaces or shall equipment if an unauthorized change or modification is made. 1.
Page 3 IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions - All these safety and operating 7. Do not block any ventilation openings. Install in 9. Protect the power cord from being walked on or 12. Refer all servicing to qualified service personnel. instructions should be read before the product is operated.
Page 4: Table Of Contents
CONTENTS FEATURES Features FEATURES ............. SPECIAL FUNCTION ......PACKAGE COMPONENTS ....... DISPLAY ..........x12 Camera x20, x30 Camera PART NAMES AND FUNCTIONS ..... SPECIFICATION ........• 1/2" Sony CMOS sensor • 1/3" Panasonic CMOS sensor • x12 Optical Zoom • x20, x30 Optical Zoom CONNECTIONS ..........
Page 5: Package Components
PACKAGE COMPONENTS PART NAMES AND FUNCTIONS MICRO SD CARD IP RESET CVBS OUT Camera MAIN CABLE MANUAL Manual...
Page 6: Connections
CONNECTIONS INSTALLATION BRACKET INSTALLATION Network Bottom side installation AC24V/DC12V Power Input SPK-OUT(YELLOW) DI/DO RS485(RS485+ : ORANGE, RS485- : BROWN) MIC IN(RED) NETWORK Used to connect the LAN cable.(10/100Mbps supported) POWER Install the camera using screw (Wrench M4*8 D/S) as figure. Place the bracket “...
Page 7: Network
INSTALLATION NETWORK Setting IP address Ceiling installation Using NVTManagement enables to set network settings. 1. Excute NVTManagement. 2. Setting IP address • Double click NVTManagement.exe • Click NVT Scan button to find IP cameras than select the camera. • Input IP address, net mask, gateway and name server address than click Apply button.
Page 8: Main Menu
NETWORK MAIN MENU 4. Camera setting Camera menu is subject to change without prior notice to upgrade and quality increase and we may use slip sheet for the change. 4. 1 Go to setting menu as below. 4. 2 Click Video Source. Please check the camera version and the slip sheet if the camera menu and this manual menu is not matched.
Page 9: Focus
FOCUS EXPOSURE FOCUS EXPOSURE MENU FOCUS MENU EXPOSURE FOCUS MODE AUTO FOCUS MODE AUTO EXPOSURE DISTANCE 1.0m EXPOSURE WHITE BAL ZOOM SPEED WHITE BAL SHUT SPEED IMAGE LENS REFRESH IMAGE IRIS ONE PUSH INTELLIGENCE E.ZOOM INTELLIGENCE SPECIAL FUNC ZOOM PRESET SPECIAL FUNC FLICKERLESS DISPLAY...
Page 10 EXPOSURE EXPOSURE ◈ DSS : Select maximum DSS (Digital Slow Shutter) ◈ DAY&NIGHT : Select Day&Night * 30 / 25 fps mode ► MODE : AUTO↲ / EXT-IN↲ / DAY / NIGHT↲ ► OFF / x2, x4 ▷ AUTO ◈ FLICKERLESS : Select Flickerless mode ►...
Page 11: White Balance
WHITE BALANCE IMAGE WHITE BALANCE IMAGE MENU WHITE BAL MENU IMAGE FOCUS MODE AUTO FOCUS EXPOSURE RED GAIN - - - EXPOSURE MIDDLE WHITE BAL BLUE GAIN - - - WHITE BAL MIRROR IMAGE CHROMA IMAGE SHARPNESS INTELLIGENCE INTELLIGENCE SPECIAL FUNC SPECIAL FUNC DEFOG DISPLAY...
Page 12: Intelligence
IMAGE INTELLIGENCE INTELLIGENCE ◈ SHARPNESS : Adjust sharpness level ► 0 ~ 10 steps ◈ ACE : Select Digital WDR (Wide Dynamic Range) MENU INTELLIGENCE ► OFF / LOW / MIDDLE / HIGH FOCUS PRIVACY EXPOSURE MOTION ◈ DEFOG : Carry out defog function WHITE BAL IMAGE ►...
Page 13 INTELLIGENCE SPECIAL FUNC ◈ MOTION : When there is movement of the subject in the screen, there will be an motion detection SPECIAL FUNC ► OFF / ON↲ ▷ AREA# : Setting 3 areas(1~3) of motion detection MENU SPECIAL FUNC ▷...
Page 14: Display
SPECIAL FUNC DISPLAY DISPLAY ◈ COMM : Set up the camera ID, baud rate, protocol ▷ ID : Select the camera ID MENU DISPLAY ► 1 ~ 255 FOCUS DISP SEL ▷ BAUD RATE : Select serial communication speed EXPOSURE SET TITLE WHITE BAL INIT SEL...
Page 15: Specification
DISPLAY SPECIFICATION Model ◈ SET INIT MSG : modify initial message. (Text edit – max 40 characters) Image Sensor 1/2" Sony CMOS Sensor 1/3" Panasonic CMOS Sensor ◈ LANGUAGE : Select language. ► English / Simplified Chinese / Traditional Chinese / Japanese Total Pixels 1952(H) x 1241(V) = 2.42M Pixels 1956(H) x 1266(V) = 2.48M Pixels...
Page 16 SPECIFICATION SPECIFICATION Model Model Distance Mirror Off / H / V / H&V 0.1 / 1.0 / 3.0 / 5.0 / 10.0 m 0.1 / 1.0 / 3.0 / 6.0 / 10.0 m Sharpness 0 ~ 10 steps Zoom Speed 0(Slow) ~ 7(Fast) Off / Low / Middle / High Lens Refresh...
Page 17 SPECIFICATION SPECIFICATION Model NETWORK Disp Sel (Off / On) ID / Title / Zoom Ratio / System Message Ethernet RJ-45 (10/100BASE-T) Set Title Text Edit Video Compression Format H.264, MPEG-4, MJPEG Init Sel (Off / On) ID / Baud Rate / Protocol / Version / Init. Message Resolution 1080p, 720p, 1024x576, 640x360, D1, 4CIF, VGA Set Init Msg...
Page 18: Drawing
DRAWING DRAWING 2-M4 TAP in-20 TAP DP5.5...
Page 19: Troubleshooting
TROUBLESHOOTING If there are problems in operation, please refer to the items below. If the problem persists, please contact the agent you purchased this product from. Trouble shooting • Nothing appears on the screen. -Please check the power connection. -Please check the video signal line connection. •...
