EF-2036F User Manual
CONSUMER SAFETY INFORMATION
1.
Read this manual before installing and operating this appliance.
2.
Failure to follow these instructions may result in electric shock,
or personal injury.
3.
Do not store or use gasoline or other flammable liquids in vicinity of this appliance.
Electric Fireplace
,
fire conflagration
Advertisement
Table of Contents
Summary of Contents for Sunrection EF-2036F
- Page 1 Electric Fireplace EF-2036F User Manual CONSUMER SAFETY INFORMATION Read this manual before installing and operating this appliance. Failure to follow these instructions may result in electric shock, fire conflagration or personal injury. Do not store or use gasoline or other flammable liquids in vicinity of this appliance.
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION! WARNING Read all instructions before using this heater! This heater is hot when in use. To avoid burns, DO NOT let bare skin touch hot surfaces. If provided, use handles when moving this heater. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9m) from the front of the heater, and keep them away from the sides and rear. - Page 3 NEVER use a wall mount bracket from another manufacturer. This product is not intended to be a primary heat source. It is for supplemental heat only. INDOOR use only! NEVER use this heater outdoors! Doing so may result in electric shock! Risk of electric shock! DO NOT OPEN! No user-serviceable parts inside! ALWAYS turn this heater off before unplugging it from the outlet.
-
Page 4: Parts & Hardware
PARTS & HARDWARE B - Wood Screws C-Drywall anchors A - Fireplace D - Decorative Crystals E - Log set Remote control Specification and Dimension PRODUCT DIMENSIONS 36” 19” 6” 32.8” 18” 10.6” 29.7” EF-2036FU 91.4CM 48CM 15.2CM 83.3CM 45.9CM 27CM 75.4CM... - Page 5 PREPARATION Your appliance is a wall-mounted, recessed and /or mantel installed appliance. Select a suitable location that is not susceptible to moisture and is away from drapes, furniture and high traffic areas. NOTE： Follow all National and local electrical codes. MINIMUM CLEARANCE TO COMBUSTIBLES Measurements are taken from the glass front.
- Page 6 RECESSED TO WALL INSTALLATION WARNING Only qualified person can perform the installation. hole size ( A ) STEP A. Selection a dry wall to open a hole for fireplace box. Size of hole as below chart. Framing Hole Size Model Number EF-2036FU 33.4”(84.84cm) 18.8”(47.75cm)
- Page 7 （C） （E） The fourth screw from top to bottom STEP C. Take off the screws (The fourth screw from top to bottom) in both sides of fireplace. Figure (C) STEP D. Remove packaging attachments from the log set. 1.Remove the front grass. 2.Remove the pear cotton block.
- Page 8 Wall Mounted Installation WARNING Only qualified person can perform the installation. Due to the many different materials used on different walls, it is highly recommended that you consult your local builder before you install this appliance on the wall. 28.5” 1.You can see the 2 clips 2.Install 2 dry wall anchors on the back of the device.
- Page 9 Logset /Crystal Ember Installation WARNING Only qualified person can perform the installation. The fourth screw from top to bottom with different color screw 1.Remove the screws (The fourth screw from top to bottom) on both side of the device to remove the front grass. 2.Take out the log set inside.
- Page 10 WARNING Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure do to so could result in electric shock, fire, serious injury, or death. OPERATION INSTRUCTION： Plug in a power plug hear a long buzzer and the electric fireplace is in standby mode. Press the POWER key on the keyboard to show red, and the rest of the display is not displayed.
- Page 11 High Heating and Low heating setting: If press "HEATER" button on keypad by 3 seconds,can switch between ℉ and℃(Note: this function is not available on the remote control.). Boot default setting temperature is 72℉(22℃), if the room temperature is lower than the setting temperature,Then the electric fireplace high heating mode start to work, if you need electric fireplace heating work in low heating mode, then click the keypad or remote control on the HEAT button to switch the heating on high and low working mode ( first time press the button the display window...
- Page 12 DIMMER FUNCTION : The flame brightness is on the brightest level by the first time. The flame brightness have five levels. If you need to adjust the flame brightness, every time you press the FLAME button, the brightness of the LED lamp front and back will become dark, the display window of digital tube will be on brightness display.
-
Page 13: Temperature Limiting Control
14. Screen protection function: The heaters have a screen protect function, If the heater working without operating on the keypad or remote control for 30 seconds, the heater will automatically turn off all the displayed light expect the power light. If you need wake up the display screen again, you only need to press any button on the keypad or on the remote control then it can be light up again. -
Page 14: Care And Maintenance
CARE AND MAINTENANCE Cleaning ALWAYS turn the heater OFF and unplug the power cord from the outlet before cleaning, performing maintenance, or moving this fireplace. Failure to do so could result in electric shock, fire, or personal injury. NEVER immerse in water or spray with water. Doing so could result in electric shock, fire, or personal injury. -
Page 15: Troubleshooting
Troubleshooting WARNING DISCONNECTED THE APPLIANCE COMPLETELY AND LET COOL PRIOR TO ANY SERVICE. ONLY A QUALIFIED SEVICE PERSON SHOULD SERVICE AND PEPAIR THIS ELECTRIC APPLAINCE. Solution Problem Possible Cause 1.Fireplace turns 1.Fireplace has overheated and 1. Pull the plug, wait 5 minutes to plug it offand will not safety devise has caused back in and turn it on.
