- Page 1 Scan to see the online manual. OWNER'S MANUAL DRYER Read this owner's manual thoroughly before operating the appliance and keep it handy for reference at all times. ENGLISH DL*610** www.lg.com MFL67652537 Copyright © 2022 LG Electronics Inc. All Rights Reserved. Rev.01_120622...
-
Page 2: Table Of Contents
Final Installation Check 26 OPERATION Before Use Loading the Dryer Control Panel Dry Cycles Cycle Modifiers Options and Extra Functions 35 SMART FUNCTIONS LG ThinQ Application Smart Diagnosis Function 36 MAINTENANCE Regular Cleaning 38 TROUBLESHOOTING FAQs Before Calling for Service 43 WARRANTY... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE Safety for a Dryer WARNING Fire Hazard Failure to follow safety warnings exactly could result in serious injury, death or property damage. Do not install a booster fan in the exhaust duct. •... -
Page 4: Warning Statements
IMPORTANT SAFETY INSTRUCTIONS WARNING Risk of Fire Install the clothes dryer according to the manufacturer’s instructions and local codes. Clothes dryer installation must be performed by a qualified installer. • Do not install a clothes dryer with flexible plastic venting materials. If •... - Page 5 IMPORTANT SAFETY INSTRUCTIONS • The appliance must be installed and electrically grounded by qualified service personnel in accordance with local codes. • Disconnect the power cord, house fuse or circuit breaker before installing or servicing the appliance. • When moving or installing the appliance in a different location, call qualified service personnel for installation and service.
- Page 6 • Do not grasp the power cord or touch the appliance controls with wet hands. • Do not modify or extend the power cord. • If the appliance has been submerged, contact an LG Electronics customer information center for instructions before resuming use.
- Page 7 IMPORTANT SAFETY INSTRUCTIONS • Do not put living animals such as pets inside the appliance. • Do not put any part of your body, such as your hands or feet, or metal objects under the appliance. • Do not let your hand get pinched when opening or closing the dryer door. Maintenance •...
-
Page 8: Product Overview
PRODUCT OVERVIEW PRODUCT OVERVIEW Product Features The images in this guide may be different from the actual components and accessories, which are subject to change by the manufacturer without prior notice for product improvement purposes. Front View Control panel Lint filters Leveling feet Reversible door Rear View... - Page 9 PRODUCT OVERVIEW Water inlet hose connection (for steam models) Exhaust duct oulet Product Specifications Model DL*610** Please refer to the rating label for detailed Electrical Requirements information. Dimensions (Width X Depth X Height) 27'' X 29 1/2'' X 44 1/2'' (68.6 cm X 75.0 cm X 113.0 cm) Maximum Depth with Door Open 50 1/4'' (127.5 cm) Gas : 114.0 lb (51.7 kg)
-
Page 10: Installation
10 INSTALLATION INSTALLATION Before Installing Installation Overview Please read the following installation instructions first after purchasing this dryer or transporting it to another location. Choose the proper location. Level the appliance. Vent the appliance. Connect the Gas / Electric dryer. •... -
Page 11: Choosing The Proper Location
INSTALLATION Choosing the Proper • For garage installation, you will need to place the appliance at least 18 inches (45.7 cm) above the Location floor. The standard pedestal height is 15 inches (38 cm). You will need 18 inches (45.7 cm) from the garage floor to the bottom of the appliance. - Page 12 12 INSTALLATION Dimensions and Clearances The following clearances are recommended for the appliance. • Additional clearances should be considered for ease of installation and servicing. • Additional clearances should be considered on all sides of the dryer to reduce noise transfer. Installation Spacing for Recessed Area or Closet Installation Description Dimension/Clearance...
- Page 13 INSTALLATION NOTE • There should be at least a little space around the dryer (or any other appliance) to eliminate the transfer of vibration from one appliance to another. If there is enough vibration, it could cause appliances to make noise or come into contact, causing paint damage and further increasing noise. •...
-
Page 14: Leveling The Appliance
14 INSTALLATION Leveling the Appliance NOTE • If you are installing the appliance on the optional WARNING pedestal, you must use the leveling feet on the • Use long-sleeved gloves and safety glasses. pedestal to level the appliance. The appliance leveling feet should be fully retracted. -
Page 15: Installing The Vent Kit
INSTALLATION With the hinges and cover caps in the new locations, remount the inner door frame onto While supporting the door, remove the 2 the outer door frame with the screws screws on the door hinge, two from each removed in step 3 above. hinge. - Page 16 16 INSTALLATION NOTE • An adapter kit, part number 383EEL9001B, may be purchased from your LG retailer. This kit contains duct components necessary to change the appliance vent location. • Right-side venting is not available on gas models. Bottom Venting...
-
Page 17: Venting The Dryer
INSTALLATION Venting the Dryer Ductwork Maximum length No. of WARNING of 4-inch Wall Cap Type 90° • Gas dryers MUST exhaust to the outdoors. diameter rigid Elbows metal duct • To reduce the risk of fire, combustion, or accumulation of combustible gases, DO NOT Recommended 65 ft. -
Page 18: Connecting Gas Dryers
18 INSTALLATION • Incorrect or inadequate exhaust systems are not • This dryer must be plugged into a 120-VAC, 60- covered by the dryer warranty. Dryer failures or Hz. grounded outlet protected by a 15-ampere service required because of such exhaust fuse or circuit breaker. -
Page 19: Connecting Electric Dryers
INSTALLATION Connecting the Gas Supply Check all pipe connections (both internal and external) for gas leaks with a noncorrosive leak-detection fluid. NOTE • In the Commonwealth of Massachusetts: This product must be installed by a licensed plumber Proceed to Venting the Dryer. or gas fitter. - Page 20 20 INSTALLATION Four-Wire Power Cord WARNING • This appliance must be connected to a grounded • A UL-listed strain relief is metal, permanent wiring system, or an required. equipment-grounding conductor must be run with the circuit conductors and connected to the equipment-grounding terminal or lead on the appliance.
- Page 21 INSTALLATION Reinstall the terminal block access cover. Install UL-listed strain relief into the power cord through-hole. Thread the 4-wire #10 AWG minimum copper power cable prepared in step 1 through the strain relief. White Wire moved from Ground Screw Hot Leads of Power Cord (Black and Red) Neutral Wire (White) Terminal Block Power Cord Ground Wire...
- Page 22 22 INSTALLATION Reinstall the terminal block access cover. Power Cord Ground Wire Ground Screw Three-Wire Power Cord • A 3-wire connection is NOT permitted on new construction after January 1, 1996. White Wire from Dryer Harness • A UL-listed strain relief is required. •...
-
Page 23: Final Installation Check
INSTALLATION Test Dryer Heating Gas Models Close the dryer door and press the Power button to turn the dryer on. Turn the knob to select 20 min, 40 min or 60 min and press the Start/Pause button to start the test. When the dryer starts, the igniter should ignite the main burner. - Page 24 24 INSTALLATION buildup and free of restrictions allows clothes to End of cycle. dry faster and reduces energy use. • At the end of the test cycle, a chime will sound and the appliance will shut off NOTE automatically after a short delay. •...
- Page 25 INSTALLATION Make sure the ductwork is not crushed or Possible Cause & Solution restricted. light High, Electric dryer power cord is not Damp connected correctly, or house power supply is incorrect. Normal • Reset circuit breaker or replace fuse. Do not increase the fuse capacity.
-
Page 26: Operation
26 OPERATION OPERATION Before Use WARNING • To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY INSTRUCTIONS before operating this appliance. Operation Overview Adjust Settings Default settings for the selected cycle can now be changed, if desired, using the cycle Clean the Lint Filter modifier and option buttons. -
Page 27: Loading The Dryer
OPERATION Baby Clothes and Nightgowns Always ensure that the lint filter is properly installed before running the dryer. Running the • Always check the manufacturer’s instructions. dryer with a loose or missing lint filter will damage the dryer and articles in the dryer. Rubber and Plastics •... - Page 28 28 OPERATION Heat Setting Label Directions High Medium No Heat / Air...
-
Page 29: Control Panel
OPERATION Control Panel Control Panel Features Power Button • Press the button to turn the appliance on. Press again to turn the appliance off. NOTE • Pressing the Power button during a cycle will cancel that cycle, and any load settings will be lost. Cycle Selector Knob •... - Page 30 30 OPERATION Cycle Status Indicators • Dry lights up when the appliance is in the drying stage. • Cool lights up when the appliance is in the cool down stage. Flow Sense Indicator • The Flow Sense™ duct blockage sensing system detects and alerts you to blockages in the ductwork that reduce exhaust flow from the dryer.
-
Page 31: Dry Cycles
Sensor Dry Cycles Sensor dry cycles utilize LG's unique dual sensor system to detect and compare the moisture level in clothes and in the air and adjust the drying time as needed to ensure superior results. The appliance automatically sets the dryness level and temperature at the recommended setting for each cycle. - Page 32 32 OPERATION Manual Dry Cycles Cycle Air Dry Description Use this cycle to dry all items (such as plastics or rubber) that can be tumble dried without using heat. Dry Level Not adjustable Temperature Not adjustable Cycle 60 min / 40 min / 20 min Description Use this cycle to select a specific amount of drying time, temperature.
-
Page 33: Cycle Modifiers
OPERATION Cycle Modifiers About Modifier Buttons Each cycle has default settings that are selected automatically. Customize these settings using the cycle modifier buttons. Repeatedly press the button for the desired modifier until the indicator light for the desired setting is lit. Not every option is available with every cycle. -
Page 34: Options And Extra Functions
34 OPERATION Options and Extra Functions 3) Press and hold the Temp. and Dry Level buttons for 3 seconds to activate/deactivate Your dryer includes several additional cycle this function. options to customize cycles to meet your individual needs. NOTE Select the desired option after selecting the •... -
Page 35: Smart Functions
Using Audible Diagnosis to Diagnose Issues Follow the instructions below to use the audible diagnosis method. • Launch the LG ThinQ application and select the Smart Diagnosis feature in the menu. Follow the instructions for audible diagnosis provided in the LG ThinQ application. -
Page 36: Maintenance
36 MAINTENANCE MAINTENANCE WARNING • Unplug the appliance before cleaning. • Never use harsh chemicals, abrasive cleaners, or solvents to clean the appliance. They will damage the finish. Regular Cleaning Cleaning the Lint Filter Always clean the lint from the filter after every Cleaning the Exterior cycle. - Page 37 MAINTENANCE filter in warm, soapy water and allow it to dry thoroughly before reinstalling. NOTE • NEVER operate the appliance without the lint filter in place.
-
Page 38: Troubleshooting
Scan this QR code to quickly access the video search page on the offical LG website. On the lg.com/us home page, click on the Support menu tab to bring up the menu selections. Select Video Tutorials. Type Dryer in the search box on the new page and click the Search button. -
Page 39: Before Calling For Service
TROUBLESHOOTING Before Calling for Service The dryer is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If the dryer does not function properly or does not function at all, check the following before you call for service. - Page 40 40 TROUBLESHOOTING Problem Possible Cause & Solution The appliance does House fuse is blown, circuit breaker has tripped, or power outage has occurred. not heat. • Reset circuit breaker or replace fuse. Do not increase fuse capacity. If the problem is a circuit overload, have it corrected by a qualified electrician.
- Page 41 TROUBLESHOOTING Performance Problem Possible Cause & Solution Clothes are wrinkled. Clothes dried too long (overdried). • Overdrying a load of laundry can lead to wrinkled clothes. Try a shorter drying time or use a lower dry level setting and remove items while they still retain a slight amount of moisture.
- Page 42 42 TROUBLESHOOTING Problem Possible Cause & Solution Clothes have damp Very large load or very small load. Single large item such as a blanket or comforter. spots after a Sensor • If items are too tightly packed or too sparse the sensor may have trouble reading the Dry cycle.
-
Page 43: Warranty
Should your LG Dryer (“Product”) fail due to a defect in materials or workmanship under normal and proper use, during the warranty period set forth below, LG will, at its option, repair or replace the Product. This limited warranty is valid only to the original retail purchaser of the Product (“You”) and applies only when purchased lawfully and used within the United States including U.S. - Page 44 Notice of Dispute. In the event you intend to commence an arbitration proceeding, you must first notify LG in writing at least 30 days in advance of initiating the arbitration by sending a letter to LG at LG Electronics, USA, Inc. Attn: Legal Department-Arbitration 111 Sylvan Avenue, Englewood Cliffs, NJ 07632.
- Page 45 If you and LG are unable to resolve the dispute within 30 days, either party may proceed to file a claim for arbitration.
- Page 46 46 WARRANTY www.lg.com/us/support/repair-service/schedule-repair-continued and clicking on “Find My Model & Serial Number”). You may only opt out of the dispute resolution procedure in the manner described above (that is, by e-mail or telephone); no other form of notice will be effective to opt out of this dispute resolution procedure.
- Page 47 Memo...
- Page 48 LG Customer Information Center For inquiries or comments, visit www.lg.com or call: U.S.A. 1-800-243-0000 1-888-542-2623 CANADA Register your product Online! www.lg.com...
