- Page 1 INSTALLATION MANUAL HZ-TTS03 TRIPOD TURNSTILES Revision Date Description Initials 2017-07-02 New template 2018-05-12 Manual update...
- Page 2 Index Chapter 1 – INTRODUCTION ......................... 3 1.1. Product features ..........................3 1.2. Product specifications ........................3 1.3. Product dimensions ........................... 4 Chapter 2 – INSTALLATION ........................... 7 Chapter 3 – TROUBLESHOOTING AND SUPPORT ..................8 Page 2 of 8...
- Page 3 Chapter 1 – INTRODUCTION This manual will address dimensions and the features of the HZ-TTS03 turnstile while also covering the process in which this turnstile is installed. 1.1. Product features The HZ-TTS03 tripod turnstiles have the following features: Material: standard 304 stainless steel with the option of getting 316 stainless steel.
- Page 4 1.3. Product dimensions Top View Page 4 of 8...
- Page 5 Extended Top View Front View Page 5 of 8...
- Page 6 Side View Two Lane Layout Page 6 of 8...
- Page 7 Chapter 2 – INSTALLATION Before proceeding to the installation of the turnstile, unpack all components and check to make sure the all parts from the packing slip are included, verify dimensions and conduit runs. Use the turnstile template to properly align and lay out the site and to determine the right location of the floor stub-ups and anchors.
- Page 8 Chapter 3 – TROUBLESHOOTING AND SUPPORT For Troubleshooting and Support, please contact HZ Security Inc.: Tel: +1.631.300.4000 techsupport@turnstileshz.com Email: Website: http://www.turnstileshz.com Page 8 of 8...
