Page 1
GBR office: Ipswich FRA office: Saint Vigor d'Ymonville USA:cs.us@costway.com If you're having difficulty, our friendly AUS:cs.au@costway.com customer team is always here to help. GBR:cs.uk@costway.com THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. FRA:cs.f r @costway.com...
Page 2
Left side chair/Chaise côté gauche x1 Before You Start Please read all instructions carefully. Retain instructions for future reference. Separate and count all parts and hardware. Read through each step carefully and follow the proper order. We recommend that, where possible, all items are assembled near to the area in which they will be placed in use, to avoid moving the product unnecessarily once assembled.
Page 3
Single chair/Chaise simple x2 Table and ottoman/Table et pouf Storage box/Boîte de rangement x1 Side frame of left chair Back frame of left chair Seat frame of left chair /Cadre latéral de la /Armature arrière de /Châssis du siège de chaise gauche la chaise gauche la chaise gauche...
Page 4
Back frame Side frame single chair Side frame armless Seat cushion Back cushion Waterproof cover single chair /Chaise simple à single chair /Coussin de siège /Coussin de dossier /Housse étanche /Chaise simple cadre latéral /Chaise simple sans à dossier accoudoirs à cadre latéral U x4 V x4 W x1...
Page 5
Left side chair/Chaise latérale gauche x1 Please don't fasten the screw completely during assembly process. It will be likely to lead to an assembling problem that screw hole position is not aligned. You can fasten completely when all parts have been assembled. Veuillez ne pas serrer complètement la vis pendant le processus d'assemblage.
Page 6
Right side chair/Chaise latérale droite x1...
Page 7
Single chair/Chaise simple x2 Please don't fasten the screw completely during assembly process. It will be likely to lead to an assembling problem that screw hole position is not aligned. You can fasten completely when all parts have been assembled. Veuillez ne pas serrer complètement la vis pendant le processus d'assemblage.
Page 9
Table and ottoman/Table et pouf the base can be adjusted suitable for uneven floors /La base peut être ajustée adaptée aux étages inégaux.
Page 10
Ottoman/Pouf Lift up and rotate 90° /Soulevez et tournez à 90°...
Page 11
Return / Damage Claim Instructions DO NOT discard the box / original packaging. In case a return is required, the item must be returned in original box. Without this your return will not be accepted. Take a photo of the box markings. A photo of the markings (text) on the side of the box is required in case a part is needed for replacement.
