COLOUR TELEVISION
AV-29J314
AV-29J534
AV-29V314
AV-29V514
AV-29V534
AV-25V314
AV-25V514
AV-21V314
AV-21V514
AV-21V534
AV-21W314
EQUALIZER • CINEMA SURROUND • COMPONENT INPUT
Contents
Knowing your TV's features ....................................................... 3
Remote control buttons and basic functions .............................. 4
TV buttons and functions ........................................................... 6
Setting up your TV ..................................................................... 7
Basic setting for picture .............................................................. 9
Advanced setting for picture ..................................................... 11
Basic setting for sound ............................................................. 12
Advanced setting for sound ..................................................... 13
Favorite channel and video setting .......................................... 14
Customized setting .................................................................. 15
TV channel presetting .............................................................. 17
Additional preparation .............................................................. 20
Troubleshooting ....................................................................... 22
Specifications ........................................................................... 23
INSTRUCTIONS
GGT0041-001A-H
Advertisement
Table of Contents
Related Manuals for JVC AV-29J314
Summary of Contents for JVC AV-29J314
-
Page 1: Table Of Contents
COLOUR TELEVISION EQUALIZER • CINEMA SURROUND • COMPONENT INPUT Contents AV-29J314 AV-21V314 Knowing your TV’s features ............3 Remote control buttons and basic functions ......4 AV-29J534 AV-21V514 TV buttons and functions ............6 AV-29V314 AV-21V534 Setting up your TV ..............7... - Page 2 Thank you for buying this JVC colour television. To make sure you understand how to use your new TV, please read this manual thoroughly before you begin. 7 If you are not going to use this TV for a long period of time, be sure to WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
-
Page 3: Knowing Your Tv's Features
Knowing your TV’s features Main features A2/NICAM You can listen to the stereo sound or bilingual sound from TV programme broadcasting by A2 (STEREO / I or NICAM Sound-multiplex system. ■ FAVORITE CH (Channel) You can register up to four favorite channels for quick recall with one press. AI ECO TV detects the brightness of your room and automatically adjust the picture brightness to a suitable level for a better eye care. -
Page 4: Remote Control Buttons And Basic Functions
Remote control buttons and basic functions No. Press POWER Turn on or off the TV from standby mode. MENU/OK Display menu and confirm selected function. 5 / ∞ / 2 / 3 Select and adjust menu function. CHANNEL -/+ Select the desired channel number. VOLUME -/+ Adjust the volume level. - Page 5 Remote control buttons and basic functions (continued) How to operate menus and menus locations Top menu 2nd menu Location 3rd menu Location INPUT EXT. INPUT P.16 – – MENU Operation Note DISPLAY P.16 – – Display the MENU Press the MENU/OK button To exit the MENU, PICTURE PICTURE MODE...
-
Page 6: Tv Buttons And Functions
TV buttons and functions The illustrations shown below is for 29V and 29J series No. Button/terminal Description Page only, which are used for explanation purpose. L (main power) Press to turn on or turn off the TV’s main power. – Your TV may not look exactly the same as illustrated. -
Page 7: Setting Up Your Tv
Turn on the TV by pressing the main with the video cable (or S-VIDEO cable if available) and audio power button. cables. For details, see the manual of your VCR. JVC logo appears on the screen. Rear of TV COMPONENT VIDEO-1... - Page 8 SETUP TOUR RESTART function. If the JVC logo does not appear, use LANGUAGE, and AUTO PROGRAM functions to make the initial settings. Those functions are located in the INSTALL menu. If the JVC logo appears, although you had made the initial settings, press the TV/VIDEO button to exit from initial settings.
-
Page 9: Basic Setting For Picture
Press the COLOUR SYSTEM button to select a setting. Asia, Middle China, Vietnam, etc. East Hong Kong, etc. Islamic Republic of Iran, Lebanon, Saudi Arabia, etc. SECAM <AV-29J314/AV-29V314/AV-25V314/AV-21V314/AV-21W314> Philippines, Taiwan, Myanmar, etc. NTSC In TV mode: Russia, etc. SECAM AUTO SECAM Czech Republic, Poland, etc. - Page 10 Basic setting for picture (continued) Adjusting the picture – USER WHITE BALANCE You can adjust the desired picture setting when selecting USER You can change the white balance of the picture to better match in PICTURE MODE. the type of video being viewed. Select the WHITE BALANCE in the PICTURE menu, then choose Select the USER in PICTURE MODE under PICTURE menu.
-
Page 11: Advanced Setting For Picture
Advanced setting for picture Press the 5/∞ buttons until the picture become level. Then AI ECO SENSOR (ECO) press the MENU/OK button. You can adjust TV screen contrast according to the brightness of your room. Press the ECO button to select the desired mode. COMPRESS (16:9) Mild contrast (recommended). -
Page 12: Basic Setting For Sound
Basic setting for sound SOUND SYSTEM SOUND MODE You can select an appropriate sound system when abnormal You can choose the desired sound setting. sound occurs even when the picture appears normally. Select the SOUND MODE in SOUND menu, then choose the Press the SOUND SYSTEM button to select a setting. -
Page 13: Advanced Setting For Sound
Advanced setting for sound CINEMA SURROUND EQUALIZER You can enjoy an enhanced sound for wider audience. You can adjust the sound level of each frequencies when selecting Press the CINEMA SURROUND button to select a setting. USER mode in SOUND MODE. Select the USER in SOUND MODE under SOUND menu. -
Page 14: Favorite Channel And Video Setting
Favorite channel and video setting To register the favorite channel Select the desired item that you wish to adjust. CONTRAST BRIGHT SHARP COLOUR You can register and recall 4 favorite channels by using the colour buttons (red, green, yellow, blue). SOUND MODE (USER, DYNAMIC, MUSIC, NEWS) TINT In TV mode, select a TV channel (PR01-99) you desired to register. -
Page 15: Customized Setting
Customized setting CHILD LOCK You can reduce the noise. You can disable the front control buttons of the TV. Select the VNR in the PICTURE FEATURES menu under Select the CHILD LOCK in the FEATURES menu, then choose PICTURE menu, then choose a setting of VNR function. ON or OFF. - Page 16 Customized setting (continued) AUTO SHUTOFF EXT. INPUT (TV/VIDEO) You can set the TV to turn off automatically when no signal is You can select TV or video terminal input with one touch. received for about 15 minutes or longer after the end of a Press the TV/VIDEO button to select an input.
-
Page 17: Tv Channel Presetting
TV channel presetting Choose EDIT/MANUAL, then press the MENU/OK button. To register the TV channels automatically EDIT menu appears. You can register the TV channels into the TV’s channel list automatically. EDIT CH/CC Display the INSTALL menu. CH 09 CH 11 ❇... - Page 18 TV channel presetting (continued) To edit the channel list (PR LIST) To add in the new channel (MOVE and DELETE in the EDIT menu) (INSERT in the EDIT menu) You can edit the TV channel list as you like. You can add in the new channel in the TV channel list as you like. Note: After this operation, other channel’s PR numbers will be You need to find the “CH/CC”...
- Page 19 TV channel presetting (continued) CH/CC number CCIR OIRT AUSTRALIA CCIR OIRT AUSTRALIA CH 33 US-33, W+48 CC 18 S-18 CH 34 US-34, W+49 CC 19 S-19 When you want to use the INSERT CH 35 US-35, W+50 CC 20 S-20 CH 36 US-36, W+51 CC 21...
-
Page 20: Additional Preparation
Additional preparation The illustrations shown in this section are for 29V and 29J series Connecting to rear component/video input only, which are used for explanation purpose. Your TV may not terminal and output terminal look exactly the same as illustrated. Rear of TV Before connecting VCR (for playing) - Page 21 Additional preparation (continued) Firmly insert the Twin Port Bass Blaster Unit connector into Attaching the Twin Port Bass Blaster Unit the BASS SPEAKER OUT terminal. <AV-29J534/AV-29V534/AV-21V534 only> The Twin Port Bass Blaster Unit is packaged together with the TV. Before you use the TV, mount the Twin Port Bass Blaster unit COMPONENT VIDEO-1 ( VIDEO-2 )
-
Page 22: Troubleshooting
Troubleshooting If a problem occurs when you are using the TV, check the below • Cannot operate the • The batteries may be exhausted. Replace with troubleshooting guide before calling for repair. remote control new batteries (see page 7). • Ensure that you are operating the remote less than seven meters from the front of your TV. -
Page 23: Specifications
Specifications Model AV-29J314 AV-29V314 AV-25V314 AV-21V314 AV-21W314 TV RF system B, G (RF mode) PAL, SECAM Colour system (VIDEO mode) PAL, SECAM, NTSC 3.58 MHz, NTSC 4.43 MHz Channel and Frequencies VHF low channel (VL) : 46.25 to 168.25 MHz VHF high channel (VH) : 175.25 to 463.25 MHz... - Page 24 Specifications (continued) Model AV-29J534 AV-29V534 AV-29V514 AV-25V514 AV-21V534 AV-21V514 TV RF system B, G, I, D, K, M Colour system (RF mode and VIDEO mode) PAL, SECAM, NTSC 3.58 MHz, NTSC 4.43 MHz Channel and Frequencies VHF low channel (VL) : 46.25 to 168.25 MHz VHF high channel (VH) : 175.25 to 463.25 MHz UHF channel (U) : 471.25 to 863.25 MHz *Receives cable channel in mid band (X to Z, S1 to S10), super band (S11 to S20) and hyper band (S21 to S41)
