Morris and Alexander SET-3 Fitting & User Instructions

Fixed height settee raiser

Morris Alexander

SET-3 Morris Fixed Height Settee Raiser

Fitting & User Instructions

IDENTIFICATION OF PARTS (QUANTITY PER PAIR)

Frame Assembly

Hand Wheel (x2)

Settee fixing screws (x8)

Please read these instructions carefully before installation.

Max Weight Loading - 640Kgs/100 stone per pair. Each extra frame used allows an extra 320Kgs/50 stone of weight

This product is only to be installed for the purpose for which it is intended (for raising settees placed on a flat, stable

and horizontal surface).

Ensure that the raised furniture is stable before use.

This raiser is for indoor use only.

Check tightness of hand wheels and fixings periodically.

Clean with damp cloth. Use non-abvasive detergent and dry thoroughly.

For larger pieces of furniture you may require EXT-B2 Extender Bars to safely span the furniture.

Morris Alexander

Chair, Settee and Bed Raising Specialists

Angle Bracket

Settee fixing holes

Adjustable Foot

Morris and Alexander Ltd, Wymans Way, Fakenham Industrial Estate, Fakenham, Norfolk, NR21 8NT

Tel: 01328 855669 Fax: 01328 855256. www.morrisandalexander.com.

Issue 2

Certified to ISO 9001

Table of Contents

Do you have a question about the SET-3 and is the answer not in the manual?

Page 1 For larger pieces of furniture you may require EXT-B2 Extender Bars to safely span the furniture. & Morris Alexander Morris Alexander Morris and Alexander Ltd, Wymans Way, Fakenham Industrial Estate, Fakenham, Norfolk, NR21 8NT Chair, Settee and Bed Raising Specialists Tel: 01328 855669 Fax: 01328 855256. www.morrisandalexander.com. Certified to ISO 9001...
Page 2 Position the settee upside down. This is best achieved by slowly tipping it forward until it comes to rest with it's underside facing upwards. Loosen the hand wheels and adjust the raisers so that they will fit the settee from front to back. Position the raisers as close to each end of the settee as possible.
