3.
USER MANUAL
3.1
ITEM
: FOB LF system
- This system is IBU and inculdes RKE.
- RKE in SMK system is intended for auto door lock or unlock or TRUNK in vehicle.
- This SMK system is to be installde on motor vehicles as *OE item.
*OE : Original Equipment.
*IBU : Intergrated Body control Unit
*RKE : Remote Keyless Entry.
3.2
SYSTEM CONSTRUCTION
3.2.1
SYSTEM IN VEHICLE
① When the lamp of "B+" is 'On', it means that power is supplied.
② When the SSB is pressed in position of INT1 ANT Switch on,
it means a start-up function that ACC_RLY and IGN1_RLY lamp is 'On'(SSB_SW1, SW_2 'On').
③ When the SSB is pressed repeatively, ACC_RLY and IGN1_RLY is 'On' and 'Off', repeatively.
* It shows the status of operation through the lamp used.
Radio Frequency
ANTENNA
(433.92MHz)
Low Frequency
(134.2KHz)
Model : MBECFOB2211
BATTERY
LF ANT
SMK
SSB
