JLD Machinery HLS6T-52 Owner's Manual

6 ton log splitter
Hide thumbs
Table of Contents

Advertisement

Quick Links

FOR YOUR SAFETY
READ AND UNDERSTAND THE ENTIRE MANUAL
BEFORE OPERATING MACHINE
MODLE NUMBER : □ HLS6T-52
SERIAL NUMBER :
Both model number and serial number may be found on the main label .
You should record both of them in a safe place for future use.
Save This Manual for Future Reference

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HLS6T-52 and is the answer not in the manual?

Questions and answers

Summary of Contents for JLD Machinery HLS6T-52

  • Page 1 FOR YOUR SAFETY READ AND UNDERSTAND THE ENTIRE MANUAL BEFORE OPERATING MACHINE MODLE NUMBER : □ HLS6T-52 SERIAL NUMBER : Both model number and serial number may be found on the main label . You should record both of them in a safe place for future use.

  • Page 2: Safety Warnings & Cautions

    SAFETY WARNINGS & CAUTIONS SYMBOL AFFIXED TO THE SAFETY WARNINGS & INSTRUCTIONS MACHINE UNDERSTAND YOUR LOG SPLITTER Read and understand the owner’s manual and labels affixed to the log splitter. Learn its application and limitations as well as the specific potential hazards peculiar to it. DRUGS, ALCOHOL AND MEDICATION Do not operate the log splitter while under the influence of drugs, alcohol, or any medication that could affect your ability to use it...
  • Page 3 EXTENSION CORDS Improper use of extension cords may cause inefficient operation of the log splitter which can result in overheating. Be sure the extension cord is no longer than 10m and its section is no less than 2.5mm to allow sufficient current flow to the motor. Avoid use of free and inadequately insulated connections.

  • Page 4: Table Of Contents

    PROTECT YOUR HANDS Keep you hands away from splits and cracks which open in the log; They may close suddenly and crush or amputate your hands. Do not remove jammed logs with you hands. DON’T FORCE TOOL It will do a better and safer job at its design rate. Never try to split logs larger than those indicated in the specifications table.

  • Page 5: Application Conditions

    C and for installation at altitudes no more than 1000m above M.S.L. The surrounding humidity should less than 50% at 40 C. It can be stored or transported under ambient temperatures between -25 C and 55 SPECIFICATIONS Model Number HLS6T-52 Motor 230V~ 50Hz 2000W IP54 Diameter *...

  • Page 6: Set Up And Preparation For Operation

    SET UP AND PREPARATION FOR OPERATION 1. Bolt the Support Leg to the Log Splitter, lift the log splitter by the handles at both ends and place it on a 60 – 75cm high, stable, flat and level work surface. 2.

  • Page 7: Wiring Diagram

    15. Max Pressure Limiting Screw DO NOT ADJUST THE MAX PRESSURE LIMITING SCREW ! Max pressure was set before the log splitter ex work and the max pressure limiting screw is sealed with glue to ensure the log splitter works under pressure no more than 6 tons.

  • Page 8: Log Splitter Operation

    LOG SPLITTER OPERATION This log splitter is equipped with “ZHB” control system that requires to be operated by both hands of the user – Left hand controls the hydraulic control lever while right hand controls the pushbutton switch. The log splitter will freeze upon absence of either hand. Only after both hands release the controls, the log pusher starts to return backward to the starting position.

  • Page 9: Freeing A Jammed Log

    Always set logs firmly on the log retaining plates and work table. Make sure logs will not twist, rock or slip while being split. Do not force the blade by splitting the log on the upper part. This will break the blade or damage the machine.

  • Page 10: Replacing Hydraulic Oil

    REPLACING HYDRAULIC OIL Replace the Hydraulic oil in the log splitter after every 150 hours of use. Take following steps to replace it. Make sure all moving parts stops and the log splitter is unplugged. Unscrew Oil Drain Bolt with Dipstick to remove Turn the log splitter on the Support Leg side over an 4 liters capacity container to drain the hydraulic oil off.

  • Page 11: Sharpening Wedge

    SHARPENING WEDGE After using the log splitters for some time, sharpen the wedge of the log splitter using a fine-toothed file and smooth any burrs or crushed area along the cutting edge. TROUBLE SHOOTING PROBLEM PROBABLE CAUSE REMEDY SUGGESTED Overload Protection Device Contact a qualified Electrician for opening...
  • Page 13 PART LIST HLS6T Name Quantity Name Quantity Oil cylinder Inner sheath ST-Style gasket 44X55 Small spindle sheath Piston Gasket 16 ST-Style gasket Screw M14X1.5 Big spring Pushing plate Piston rod Nut M10 Nuts M14 Support bracket Lift handle Inner hexagon bolt M8X15 Inner hexagon bolt M6X16 Plastic pad 1 Washer 14...
  • Page 14 59 Gear spindle 60 Gear 61 Middle clapboard 62 Column pin 8X25 63 Motor connecting spindle 64 Ring 46.2X1.8 65 Nut 6 66 Inner six angle bolt M6X30 67 Framework oil seal 68 Motor spindle 69 Motor 70 Nut 6 71 Stretching pad 6 72 Frontal aluminum cover of motor 73 steel stop 11...
