Summary of Contents for Sylvania SC171
- Page 1 SC171 17” FLAT COLOR MONITOR REFERENCE MANUAL...
-
Page 3: Table Of Contents
SC171 Reference Manual Table of Contents FCC Information Safety Information Installation Controls & Functions Preset Timing Input Pin Assignment Technical Specifications Troubleshooting... -
Page 4: Fcc Information
FCC Information This equipment has been tested and found to comply with limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protec- tion against harmful interference in a residential installation. This equipment can generates, uses, and radiate radio fre- quency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio... -
Page 5: Safety Information
Safety Information Provided with this monitor is a detachable power supply cord with IEC320 style terminations. It may be suitable for con- nection to any UL listed personal computer with similar con- figuration. Before making the connection, ensure that the voltage rating of the computer convenience outlet is the same as the monitor and that the ampere rating of the computer convenience outlet is equal to or exceeds the monitor current... -
Page 6: Installation
Installation No tools are required to install the SC171. Simply follow the instructions outlined in the next few pages. Connect Power Cord Connect the female end of the power cable to the power input receptacle on the back panel of the SC171. Then, plug the male end of the power cable into an AC outlet. -
Page 7: Controls & Functions
Controls & Functions The OSD menu activates when you press the “1” button. Use either the “UP” button to move your selection up or “DOWN” button to move your selection down. When a sub-menu is present you can use either the “UP” or “DOWN” buttons to select the function you would like to modify. - Page 8 Controls & Functions The OSD menu activates when you press the “1” button. Use either the “UP” button to move your selection up or “DOWN” button to move your selection down. When a sub-menu is present you can use either the “UP” or “DOWN” buttons to select the function you would like to modify.
- Page 9 Controls & Functions Color Select this function, then use the “UP/DOWN” buttons to select 9300°K (Cool White Point), 6500°K (Warm White Point), or User. (Changes on “User” is not recommended) Degauss Selecting this function will demagnetize the CRT when the display becomes discolored or washed out in appear- ance.
-
Page 10: Preset Timing
Preset Timing Standard Refresh Rate Resolution 640 x 350 Industry 70Hz 640 x 480 Industry 60Hz Industry 70Hz 720 x 400 VESA 75Hz 640 x 480 720 x 400 VESA 85Hz 640 x 480 VESA 85Hz VESA 72Hz 800 x 600 800 x 600 VESA 75Hz... -
Page 11: Technical Specifications
Technical Specifications Model SC171 CRT Size 17” Diagonal (16” Viewable) Deflection Angel 90 Degrees Dot Pitch 0.25mm Screen Type Shadow Mask, Anti-Static, Non-Glare Graphics Standards NON-INTERLACED 1280 x 1024 (SXGA), 1024 x 768 (XGA), 800 x 600 Compatibility (SVGA), 640 x 480 (VGA), 1024 x 768 @ 85Hz (Recommended) -
Page 12: Troubleshooting
Troubleshooting The monitor is switched ON, but the Power LED indicator is not lit and there is no display on the screen. Check all the power connections and make sure they are secure. If the monitor is plugged into a surge protector, make sure that the surge protector is switched on. - Page 13 Troubleshooting How do I change the frequency or refresh rate the monitor uses? The refresh rate is controlled by the video card. In your “Display Properties,” press the “Advanced” button. Select the Adapters tab. There should be a list of refresh rates. Why do the characters in the corner of the screen look fuzzier than the center? One of the limitations of a CRT screen is that the focus is...
- Page 14 Access Sylvania Computer Products website to download the latest drivers*, get latest news, view new and upcoming products. You can even register your product online! THIS MONITOR DOES NOT REQUIRE ANY DEVICE DRIVER TO FUNCTION.** Sylvania Computer Products http://www.sylvaniapc.com * You may also purchase the CD at (714) 751-8405 Extension 4024 for Parts Department.
- Page 15 © 2001 Sylvania Computer Products. All rights reserved. This manual may not be copied in whole or in part without the written consent of Sylvania Computer Products. Sylvania Computer Products is not responsible for printing or clerical errors. Product specifications is subject to change without notice. Windows® is a registered trademarks of Microsoft Corporation.
- Page 16 Sylvania Computer Products (714) 751-4889 (714) 708-3767 fax www.sylvaniapc.com Ref No.: 11/21TF1703A00 Copyright © 2001 Sylvania Computer Products Part No.: 00300000299...
