Directive Systems & Engineering DSE1445LYB Quick Start Manual

Frequency Range:
Number of elements:
Boom Length:
Boom diameter:
Mast diameter
Weight (Shipping)
Connector:
Gain:
3 dB Beamwidth (E Plane):
F/B Ratio:
Maximum Power:
Stacking distance:
Anti-Seize Compound - Apply a small amount of the supplied Anti-Seize Compound to the aluminum joints and
to the threads of the U-Bolts to prevent galling.
BEFORE INSTALLING YOUR NEW ANTENNA, PLEASE BE SURE
1) Unpack antenna and locate the two preassembled antenna sections and the hardware
package. The boom is broken between elements D22 and D23. Remove D22 from the boom
piece and slide boom pieces together to alignment marks. Replace D22 and retighten. (D22 is
the element approximately 0.5 inch from the end of the boom section; it will only fit together
one way.) The booms are marked for your assembly.
2) Straighten any misaligned elements and tighten hardware if necessary.
touch R1, DE or D1, as these are factory set.
3) Attach the boom to mast plate to the boom with the hardware provided. Install the U-
bolts so that the mast comes up directly under the boom.
DSE1445LYB Rev 4/21
Directive Systems & Engineering
Haymarket, VA 20169-1628
2160-2210 MHz Loop Yagi, Model DSE1445LYB

SPECIFICATIONS

Note: All hardware is Stainless Steel unless otherwise noted.
TO READ THE ENCLOSED WARNING PAMPHLET.

ASSEMBLY INSTRUCTIONS

2702 Rodgers Terrace
www.directivesystems.com
703-754-3876
2.160-2.210 GHz
45
90 inches
0.625 inch
1 1/2 inch
3 pounds
Type N female
≅ 20.0 dBi
≅16 degrees
≥ 20 dB
400 Watts average
15 inches Vertical (H)
17 inches Horizontal (E)
(any 25 MHz segment)
But do not
