- Page 1 FW-300-M Featuring the First Water 40 water treatment system Operation Manual First Water Systems 770-442-8257 www.firstwaterinc.com...
-
Page 2: Table Of Contents
Table of Contents Operation Manual ..................1 1 Introduction ....................1 1.1 Style Conventions ................1 2 Unpacking ....................2 2.1 Inventory ..................... 2 2.2 Storage ....................3 3 Startup and Operation ................4 3.1 Water Source ..................4 3.2 Component Layout ................5 3.4 Startup .................... -
Page 3: Operation Manual
It is valuable for the proper use of The FW-300-M and should be kept with the unit at all times. Make sure you read and understand the content of the Operator’s Manual. -
Page 4: Unpacking
Operation Manual FW-1200-M 2 Unpacking Upon delivery of your FW-300-M, please inspect for damage and inventory all components. 2.1 Inventory The FW-300-M includes the following components: (1) Water Purification Unit (1) Operation Manual (1) Maintenance Kit (0.5oz silicone grease & 3 x Canister O- Rings) ... -
Page 5: Storage
Operation Manual FW-1200-M 2.2 Storage The FW-300-M should be stored ready for deployment. The following checklist will ensure that your FW-300-M is properly stored. Used filters discarded New filters installed Unit clean and dry Canister O-Rings lubricated and in place ... -
Page 6: Startup And Operation
5. Rain water collected from roof runoff. 6. Surface water from retention ponds, lakes or streams. The FW-300-M does not remove chemical contaminants from water sources. Care should be taken in using a water source from unknown locations or uncontrolled environments. -
Page 7: Component Layout
Allow the system to run for 5 to 10 minutes prior to distributing clean water. This will ensure all carbon particles are flushed and the UV lamp has the proper contact time with water. © 2012 First Water Systems, Inc pg. 5... -
Page 8: Operation
Filters needing to be changed. Pausing Operation The FW-300-M may be turned off and on throughout an event. To stop the flow of water, turn any downstream valves to the off position. The pump will automatically stop. If desired, you may turn off the power to the Filtration Unit to shut off the UV Lamp. - Page 9 Check Silt Screen for debris. Replace the Sediment Filter in housing #1. Restart unit and observe flow rate. If flow rate has not improved, replace the Virus Media Filters. © 2012 First Water Systems, Inc pg. 7...
-
Page 10: Post Operation Care
Follow steps above to remove and dry filter canisters. Drain the UV Chamber by tilting unit slightly and allowing water to flow from the Outlet. Remove and drain all hoses. © 2012 First Water Systems, Inc pg. 8... -
Page 11: Preparing For Storage
Tighten Canisters hand tight only. Coil and store all hoses and accessories. The FW-300-M should be stored ready for deployment. The following checklist will ensure that your FW-300-M is properly stored. Used filters discarded ... -
Page 12: Special Procedures
Inspect and lubricate each (3) Canister O-Rings with Silicone Grease or other food grade lubricant. Tighten Canisters hand tight only 5.3 Replacing UV Lamp Disconnect power from the Filtration Unit. Remove UV Canister from brackets. © 2012 First Water Systems, Inc pg. 10... -
Page 13: Replacing Quartz Sleeve
Stubborn stains usually can be removed with a diluted hydrochloric acid. Reassemble in reverse order. Make sure the quartz sleeve protrudes an equal distance past each threaded nipple. © 2012 First Water Systems, Inc pg. 11... -
Page 14: Uv Lamp Disposal
Mercury added lamps should not be placed in the trash. Dispose of properly. For further information regarding the disposal and recycling of lamps containing mercury, along with Federal and State requirements visit http://www.lamprecycle.org. © 2012 First Water Systems, Inc pg. 12... -
Page 15: Troubleshooting
A small, dripping leak is not abnormal 6.4 Water leaks UV Chamber Inspect Quartz Sleeve for damage Inspect Quarts Sleeve O-Rings and Washers (See “Replacing Quartz Sleeve”) Tighten UV Canister End Cap © 2012 First Water Systems, Inc pg. 13...
