Summary of Contents for Huafone HF-801A
- Page 1 ® Model HF-801A QUICK START CONNECTING WIRES Substation (Speaker) Plug 3.5mm wire male end to master station Power Transformer Power Plug on master station Call (248) 629-0170 if you still have troubles setting up system. Page 1 of 4...
- Page 2 ® Model HF-801A INSTALLATION AND OPERATION INSTRUCTION (Optional) Volume control button of substation( VOL) 7.Power switch (Power) 2.Volume control button of master station( 8.Power indicator light VOL) 9.Microphone 3.Master station speaker indicator light 10.Jack to substation (OUT) 4.Substation speaker indicator light 11.Internal MIC jack (MIC.)
- Page 3 Harmonic Distortion: < 0.5% MIC Input Sensitivity: 10 mv Working Humidity: ≤90% Working Temperature: - 4 ℉ ~ + 150 ℉ Note: Huafone reserves the rights to update pictures, specifications, design shown here at anytime without further notice. Page 3 of 4...
- Page 4 ® Model HF-801A INSTALLATION AND OPERATION INSTRUCTION (Vehicle Detection System) Install Batteries 1. Using a screwdriver (not included), remove the Battery Cover of the Sensor, and insert three AAA batteries (not included). Replace the Battery Cover. 2. Using a screwdriver (not included), remove the Battery Cover of the Receiver, and insert three C batteries (not included).
