L2530
Rev. O
Specifications
Operating Pressure
Valve Type
Motor
Sound Level
Flow Rate
Unloading Pressure
Reservoir Capacity
Dry Weight
Recommended Hydraulic Fluid
1.0 IMPORTANT RECEIVING INSTRUCTIONS
Visually inspect all components for shipping damage.
contact American Rescue Technology products if damage has
occurred.
SAFETY FIRST
2.0 SAFETY ISSUES
American Rescue Technology products are designed and
manufactured to provide excellent service when used for their
intended purpose. Operator safety is a major consideration in the
product design and operator manuals are provided to promote
07/01
ART-10K258
700 bar (10,000 psi maximum)
(2) Dump
Honda GXV 160 5.5 HP (4,1 kW), 4 cycle
See Honda GXV 160 Owner's Manual supplied with pump.
80 dBA at 1 m (3 ft) at no load
3,9 l/min (240 in
0,8 l/min (50 in
140 bar (2,000 psi)
8 Liter (2.1 gallons)
44 kg (97 lbs)
American Rescue Technology Hydraulic Fluid
Instruction Manual
5.5 HP Honda Gas Power Unit
3
/min) at 0 bar (0 psi)
3
/min) at 700 bar (10,000 psi)
their safe use. The company urges all users to read the instruction
manual and to seek operating instructions from qualified
Please
instructors before attempting to use the products.
Although most safety precautions are addressed in factory
authorized training programs as well as throughout this manual,
pay particular attention to the following:
• Power units and tools should be operated by qualified
personnel only.
• Be sure to follow all maintenance procedures and to use only
factory authorized service parts.
ART-10K258
Advertisement
Summary of Contents for American Rescue Technology ART-10K258
- Page 1 Visually inspect all components for shipping damage. Please instructors before attempting to use the products. contact American Rescue Technology products if damage has occurred. Although most safety precautions are addressed in factory authorized training programs as well as throughout this manual,...
- Page 2 • Check hydraulic fluid level before operating power unit. Add fluid when necessary. 3. In Use • Use only American Rescue Technology hydraulic fluid. 4. Full Do not substitute other brands because characteristics may differ. Brake or automatic transmission fluid will not work in the American Rescue Technology system and will damage the equipment.
- Page 3 4.0 OPERATION Check all system fittings and connections to be sure they are tight and leak free. Check gasoline engine gas and oil levels. See Honda GXV160 Owner’s Manual for recommended fluids. Before starting gasoline engine, be sure that the control valve is in the dump (2) position to prevent accidental movement of tool.
- Page 4 6.0 TROUBLESHOOTING A system failure may or may not be the result of a power unit malfunction. To determine the cause of the problem, the complete system must be included in any diagnostic procedure. Refer to Honda GXV160 Owner’s Manual for engine information. Only factory trained personnel should service the power unit or system components.
