Model Number
PLATINUM SWIVELER® INDUSTRIAL ICP® ACCELEROMETER
607A11
Performance
Sensitivity(± 15 %)
Measurement Range
Frequency Range(± 3 dB)
Resonant Frequency
Broadband Resolution(1 to 10,000 Hz)
Non-Linearity
Transverse Sensitivity
Environmental
Overload Limit(Shock)
Temperature Range
Enclosure Rating
Electrical
Settling Time(within 1% of bias)
Discharge Time Constant
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Spectral Noise(10 Hz)
Spectral Noise(100 Hz)
Spectral Noise(1 kHz)
Electrical Isolation(Case)
Physical
Size (Hex x Height)
Weight(without cable)
Mounting
Mounting Thread
Mounting Torque(stud)
Mounting Torque(hex nut)
Sensing Element
Sensing Geometry
Housing Material
Sealing
Electrical Connector
Electrical Connection Position
Cable Length
Cable Type
[9]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Group, Inc.
ENGLISH SI
100 mV/g 10.2 mV/(m/s²)
± 50 g ± 490 m/s²
30 to 600,000 cpm 0.5 to 10,000 Hz
1500 kcpm 25 kHz
2
350 µg
3434 µm/sec
± 1 % ± 1 %
≤ 7 % ≤ 7 %
5000 g pk 49,050 m/s² pk
-65 to +250 °F -54 to +121 °C
IP68 IP68
≤ 2 sec ≤ 2 sec
≥ 0.3 sec ≥ 0.3 sec
18 to 28 VDC 18 to 28 VDC
2 to 20 mA 2 to 20 mA
<150 Ohm <150 Ohm
8 to 12 VDC 8 to 12 VDC
2
8 µg/√Hz 78.5 (µm/sec )/√Hz
2
5 µg/√Hz
49.1 (µm/sec )/√Hz
2
4 µg/√Hz 39.2 (µm/sec )/√Hz
8 8
>10 Ohm >10 Ohm
9/16 in x 0.97 in 14 mm x 24.6 mm
1.1 oz 31 gm
Stud Stud
1/4-28 Male 1/4-28 Male
3 to 4 ft-lb 4.1 to 5.4 Nm
2 to 3 ft-lb 2.7 to 4.1 Nm
Ceramic Ceramic
Shear Shear
Stainless Steel Stainless Steel
Welded Hermetic Welded Hermetic
Molded Integral Cable Molded Integral Cable
Side Side
10 ft 3.0 m
Polyurethane Polyurethane
OPTIONAL VERSIONS
[2]
Optional versions have identical specifications and accessories as listed for the standard model
except where noted below. More than one option may be used.
[1] EX - Hazardous Area Approval- contact factory for specific approvals
[1]
Hazardous Area Approval Exia IIC T4, AExia IIC, T4
EEx nL IIC T4, -40°
[3] Hazardous Area Approval
C≤Ta≤121°C, II 1 G
Cl I, Div I, Groups A, B, C, D;
Hazardous Area Approval
Cl II, Div I, Groups E, F, G; Cl
Cl I, Div 2, Groups A, B, C, D;
Hazardous Area Approval
ExnL IIC T4, AExnA IIC T4
EEx nL IIC T4, -40°
Hazardous Area Approval
C≤Ta≤121°C, II 3 G
M
- Metric Mount
Supplied Accessory : Model M080A159A Mounting stud, 1/2-20 to M6 x 1 (1)
TO
- Temperature Output
[1]
Temperature Output Range +36 to +250 °F
[1]
Temperature Scale Factor 5.56 mV/°F + 32
[1]
Electrical Connector Molded Integral Cable
Electrical Connections(Red) Acceleration Output
Electrical Connections(Black)
Electrical Connections(White) Temperature Output
[4]
[5]
[6][7]
NOTES:
[1] Typical.
[2] Conversion Factor 1g = 9.81 m/s².
[3] Zero-based, least-squares, straight line method.
[4] Measured with mounting stud.
[5] 1/4-28 has no equivalent in S.I. units.
[6] 1/8" hex Allen key required for English version, 3mm hex Allen key required for metric
version.
[8]
[7] Stud torque must exceed sensor hex nut torque to ensure proper dismantling.
[8] Twisted shielded pair.
[9] See PCB Declaration of Conformance PS023 or PS060 for details.
SUPPLIED ACCESSORIES:
Model 080A156 Mounting Base (1)
Model ICS-2 NIST-traceable single-axis single-point amplitude response calibration at 6000
cpm (100 Hz) (1)
Entered: AP Engineer: jg Sales: EGY
Date: 4/11/2013 Date: 4/11/2013 Date: 4/11/2013
3425 Walden Avenue, Depew, NY 14043
Revision: J
ECN #: 41189
Exia IIC T4, AExia IIC, T4
EEx nL IIC T4, -40°
C≤Ta≤121°C, II 1 G
Cl I, Div I, Groups A, B, C, D;
Cl II, Div I, Groups E, F, G; Cl
III, Div I III, Div I
Cl I, Div 2, Groups A, B, C, D;
ExnL IIC T4, AExnA IIC T4
EEx nL IIC T4, -40°
C≤Ta≤121°C, II 3 G
+2 to +121 °C
+10 mV/°C
Molded Integral Cable
Acceleration Output
Ground Ground
Temperature Output
Approved: BAM Spec Number:
12650
Date: 4/11/2013
Phone: 800-959-4464
Fax: 716-684-3823
E-Mail: imi@pcb.com
