Brizo T70308-PC Manual

Two handle tub filler body and tub filler trim kit

Advertisement

Model Number: ____________________
Número del modelo
Numéro de modèle
Date of Purchase: ____________________
Fecha de compra
Date d'achat
Register Online
Regístrese en línea
S'enregistrer en ligne
www.brizo.com/customer-support/product-registration
To reference replacement parts and access additional
technical documents and product info, visit www.brizo.
com
Para referencia sobre las piezas de repuesto y acceder
a documentos técnicos adicionales e información del
producto, visite www.brizo.com
Pour obtenir la référence des pièces de rechange ainsi
que pour avoir accès à d'autres documents techniques
et renseignements sur le produit, allez à www.brizo.com
?
1-877-345-BRIZO (2749)
www.brizo.com/customer-support
Read all instructions prior to installation.
CAUTION
!
Failure to read these instructions prior to installation may result in personal
injury, property damage, or product failure. Manufacturer assumes no
responsibility for product failure due to improper installation.
Lea todas las instrucciones antes de hacer la instalación.
ADVERTENCIA
!
El no leer estas instrucciones de instalación puede resultar en lesiones
personales, daños a la propiedad, o falla en el funcionamiento del producto.
El fabricante no asume ninguna responsabilidad por la falla del producto
debido a una instalación incorrecta.
Veuillez lire toutes les instructions avant l'installation.
AVERTISSEMENT
!
L'omission de lire les présentes instructions avant l'installation peut
entraîner des blessures, des dommages matériels ou le bris du produit. Le
fabricant se dégage de toute responsabilité à l'égard d'un bris du produit
causé par une mauvaise installation.
You may need:
Usted puede necesitar:
Articles dont vous pouvez avoir besoin :
04/19/2022
TWO HANDLE TUB FILLER BODY AND
106556
TUB FILLER TRIM KIT
CUERPO DE LA LLAVE DE AGUA DE DOS
MANIJAS PARA BAÑERAS Y JUEGO DE
ACCESORIOS
CORPS ET TROUSSE DE FINITION
POUR ROBINET DE BAIGNOIRE À DEUX
MANETTES
Available Mounting Options:
Opciones disponibles para la instalación:
Options de montage offertes :
NOTE: Wall, deck or floor risers must be ordered separately. A rough-in is
also required for floor mount models.
NOTA: Las tuberías verticales de pared, encimera o piso deben ordenarse
por separado. Las tuberías internas también se requieren para los modelos
de instalación en el piso.
NOTE : Les tuyaux ascendants pour robinet à montage au mur, sur plage et
sous le plancher doivent être commandés séparément. Un robinet brut est
également requis pour les modèles à montage sous le plancher.
Wall
Pared
Au mur
Sold Separately
Se vende por separado
Vendu séparément
Deck
Encimera
Sur plage
Sold Separately
Se vende por separado
Vendu séparément
Floor
Piso
Sous le plancher
R70200 / R70200-WS (with stops)
Rough sold separately, must be installed
under floor prior to installation of trim.
R70200 / R70200-WS (con topes)
La tubería interior se vende por sepa-
rado, se debe instalar bajo el suelo antes
de la instalación de la moldura/accesorio.
R70200 / R70200-WS (avec robinet
d'arrêt) Robinet brut vendu séparément.
Doit être installé sous le plancher avant
le montage des pièces de finition.
1
Sold Separately
Se vende por separado
Vendu séparément
106556 Rev. B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T70308-PC and is the answer not in the manual?

Questions and answers

Summary of Contents for Brizo T70308-PC

  • Page 1 Pared Au mur Pour obtenir la référence des pièces de rechange ainsi que pour avoir accès à d’autres documents techniques et renseignements sur le produit, allez à www.brizo.com Sold Separately Se vende por separado Vendu séparément 1-877-345-BRIZO (2749) www.brizo.com/customer-support...
  • Page 2 1/8" 3/32" Maintenance If faucet leaks from spout outlet: If faucet exhibits poor flow appearance: 1. SHUT OFF WATER SUPPLIES. 1. Remove stream straightener (5). 2. Clean and re-install. 2. Replace valve cartridge (3) or (4). If faucet exhibits very low flow: If faucet leaks from under handle: 1.
  • Page 3 Body Installation - Wall, Deck or Floor Mounted Tub Fillers Instalación del cuerpo - para la pared, encimera o piso para bañeras/tinas Installation du corps - robinets de baignoire au mur, sur plage ou sous le plancher Cold Side Setup Configuración del lado frío Montage du côté...
  • Page 4 Securely tighten body (9) using an 8mm allen wrench (12) provided. Alternate tightening hot and cold side until firmly securely. Ensure no debris is on valve cartridges and body seating surfaces. Re-install hot/cold valve cartridges (10) using 17mm socket, tighten firmly. Apriete firmemente el cuerpo (9) con una llave Allen de 8 mm (12) provista.
  • Page 5 Spout Installation Handle Installation Instalación del surtidor Instalación de la manija Installation du bec Installation des manettes Note: Lubricate spout adapter (2) o-ring to aid in the insertion of spout. Carefully slide spout (1) onto spout adapter (2), press firmly to ensure spout is seated properly.
  • Page 6 Hand shower Installation La instalación de la regadera de mano Installation de la douche à main Attach hand shower (8) to hose with gasket (2) between connection. Hand Attach hose nut (1) onto outlet (3) including gasket (2) and tighten. tighten conical nut (7) securely.
  • Page 7 CLEANING AND CARE Care should be given to the cleaning of this product. Although its finish is extremely durable, it can be damaged by harsh abrasives or polish. To clean, simply wipe gently with a damp cloth and blot dry with a soft towel. LIMPIEZA Y CUIDADO DE SU LLAVE Tenga cuidado al ir a limpiar este producto.
  • Page 8 Brizo Kitchen & Bath Company Masco Canada Limited, Plumbing Group application” refers to the purchase of the faucet from an authorized Brizo seller by a purchaser who owns but does not live in the residential 55 E. 111th Street Technical Service Centre...
