AMERICAN GAS LOG, LLC
Models:
WC-181,241,301
WC-181,241,301 W/ Double burner
RCV101,RCV202,ACC26N,ACC26P
PSS101RR, PSS202RR
PSS101, LP202
Burner/Hearth Kits
Check with your local building code agency before you begin installation to ensure compliance with local codes, including
the need for permits and follow-up inspections. If you encounter any problems regarding code approvals, or if you need
clarification of any of the instructions contained here, contact the Technical Services Dept., American Gas Logs, LLC
phone 1.919.331.0078 or 1.919.331.0079.
•
Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING
If the information in these instruc-
tions is not followed exactly, a
fire may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
• What to do if you smell gas:
- Do not try to light any appliance.
- Do not touch any electrical switch. Do not
use any phone in your building.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed
by a qualified installer, service agency, or
the gas supplier.
CAUTION
DO NOT DISCARD THIS MANUAL
Read, understand
•
and follow these
instructions for safe
i n s t a l l a t i o n a n d
operation.
•
•
•
•
In the Commonwealth of Massachusetts:
•
•
•
Installation and service of this
appliance should be performed by
qualified personnel. American Gas
Log, LLC suggests NFI certified or
factory-trained professionals, or
technicians super-
vised by an NFI
certified profes-
sional.
Leave this manual with
•
party responsible for
use and operation.
WARNING
HOT! DO NOT TOUCH.
SEVERE BURNS MAY RESULT.
CLOTHING IGNITION MAY RESULT.
Glass and other surfaces are hot during
operation and cool down.
Keep children away.
CAREFULLY SUPERVISE children in same room as
appliance.
Alert children and adults to hazards of high
temperatures.
Keep clothing, furniture, draperies and other
combustibles away.
This appliance must be installed by a licensed plumber
or gas fitter.
The chimney flue damper, when used with gas logs, will
be welded open or completely removed.
A CO detector shall be installed in the room where the
appliance is installed.
Installation
Instructions
Advertisement
Table of Contents
Related Manuals for American Gas Log WC-181
Summary of Contents for American Gas Log WC-181
- Page 1 Installation and service of this Models: appliance should be performed by WC-181,241,301 qualified personnel. American Gas Log, LLC suggests NFI certified or WC-181,241,301 W/ Double burner factory-trained professionals, or RCV101,RCV202,ACC26N,ACC26P technicians super- PSS101RR, PSS202RR vised by an NFI PSS101, LP202 certified profes- sional.
-
Page 2: Homeowner Reference Information
Opening Size Depth 14” 14” 16” 16” 16 “ 16” Height 16” 16” 18” 18” 20 “ 20” 39” 39” 48” 48” 58” 58” Min. Vent Opening in Square in. American Gas Log, LLC • IM-140 • Rev C 06/2019... -
Page 3: Listing And Code Approvals
Phillips screwdriver CAUTION Tape measure Crescent wrenches Sharp Edges Gas shutoff valve • Wear protective gloves and safety glasses during Non-corrosive leak check solution installation. 3/4 in. wrench, 7/16 in. wrench American Gas Log, LLC • IM-140 • Rev C 06/2019... -
Page 4: Appliance Preparation
Also, be careful not to crimp the tubing while bending. If • Vermiculite (LP only) the tubing becomes crimped, do not use for installation. • Lava Rock • Damper Stop • Log Set (Packaged seperately) American Gas Log, LLC • IM-140 • Rev C 06/2019... -
Page 5: Convert To Left Side Gas Piping
• Low pressure may cause explosion. equal to or less than 1/2 psig. Install regulator upstream of valve if line pressure is greater than 1/2 psig. American Gas Log, LLC • IM-140 • Rev C 06/2019... -
Page 6: Installation Instructions
Turn on the gas and coat each joint with a non-corrosive gas leak check solution. Air bubbles will form indicating any leaks. DO NOT USE A FLAME OR ANY TYPE OF IGNITION SOURCE TO CHECK FOR LEAKS. All leaks American Gas Log, LLC • IM-140 • Rev C 06/2019... -
Page 7: Install The Burner/Pan Assembly
The gas burns at the point of the least resistance. In case of an uneven flame pattern it may be necessary to adjust the materials in the pans (using an object such as a screwdriver) to achieve the desired effect. American Gas Log, LLC • IM-140 • Rev C 06/2019... - Page 8 Do not close the glass doors during appliance operation. • Could cause incomplete combustion of the gas. • Glass doors may be closed when the hearth kit is not being used. American Gas Log, LLC • IM-140 • Rev C 06/2019...
-
Page 9: Important Safeguards
Solid fuels shall not be burned in a fireplace where a decorative appliance is installed. • If glass doors are present, the glass doors must be fully opened while appliance is in operation. American Gas Log, LLC • IM-140 • Rev C 06/2019... -
Page 10: Cleaning Your Appliance
1. Inspect the burner orifice for obstruction. Call a qualified gas to the main burner; the service technician. valve knob is on. B. Defective valve. 1. Replace the gas valve. Call a qualified service technician. American Gas Log, LLC • IM-140 • Rev C 06/2019... -
Page 11: For Your Safety Read Before Lighting
“ON”. Turn gas control knob counterclockwise TO TURN GAS OFF TO APPLIANCE Turn gas control handle clockwise to “OFF” position. Do not force. Control Knob (shown in “pilot” position) American Gas Log, LLC • IM-140 • Rev C 06/2019... - Page 12 11. Activate the burner with the log switch. TO TURN GAS OFF TO Turn gas control handle clockwise to “OFF” position. Do not force. Control Knob (shown in “pilot” position) American Gas Log, LLC • IM-140 • Rev C 06/2019...
- Page 13 12. Instructions are provide in the remote control box for connection and operation. TO TURN GAS OFF TO APPLIANCE Turn gas control handle clockwise to “OFF” position. Do not force. Control Knob (shown in “pilot” position) American Gas Log, LLC • IM-140 • Rev C 06/2019...
- Page 14 UNIVERSAL BURNER Service Parts W/PSS101-S or LP202-S 1 - Burner Pan Assembly 18”, 24”, 30”. 2 - Grate Assembly 18”, 24”, 30”. 1B - Double Burner Pan Assembly 18”, 24”, 30”. American Gas Log, LLC • IM-140 • Rev C 06/2019...
- Page 15 46-6-8B 46-6-8B Stabilizer Brackets 10-1058A 10-1058-A 10-1058-A Install Manual IM-140 IM-140 IM-140 Sand ACC15 ACC15 ACC15 Vermiculite ACC11 ACC11 ACC11 Glowing Embers ACC12 ACC12 ACC12 Lava Rock ACC10 ACC10 ACC10 American Gas Log, LLC • IM-140 • Rev C 06/2019...
- Page 16 UNIVERSAL BURNER PSS101RRN-S NG or PSS202RRP-S 1 - Burner Pan Assembly 18”, 24”, 30”. 2 - Grate Assembly 18”, 24”, 30”,. 1B - Double Burner Pan Assembly 18”, 24”, 30”. American Gas Log, LLC • IM-140 • Rev C 06/2019...
- Page 17 ACC59 ACC59 Stabilizer Brackets 10-1058A 10-1058A 10-1058A Install Manual IM-140 IM-140 IM-140 Sand ACC15 ACC15 ACC15 Vermiculite ACC11 ACC11 ACC11 Glowing Embers ACC12 ACC12 ACC12 Lava Rock ACC10 ACC10 ACC10 American Gas Log, LLC • IM-140 • Rev C 06/2019...
- Page 18 1B - Double Burner Pan Assembly Remote & Reciever 18”, 24”, 30”. Included with RCV101N-S & RCV202P-S May be purchased as accessory with ACC26N-S & ACC26P-S ACC26N-S OR ACC26P-S LOG SWITCH INCLUDED American Gas Log, LLC • IM-140 • Rev C 06/2019...
- Page 19 ACC59 ACC59 Stabilizer Brackets 10-1058A 10-1058A 10-1058A Install Manual IM-140 IM-140 IM-140 Sand ACC15 ACC15 ACC15 Vermiculite ACC11 ACC11 ACC11 Glowing Embers ACC12 ACC12 ACC12 Lava Rock ACC10 ACC10 ACC10 American Gas Log, LLC • IM-140 • Rev C 06/2019...
- Page 20 American Gas Log, LLC. (5)As part of this limited warranty no Labor costs will be paid by American Gas Log, LLC pursuant to this Limited Warranty must be approved in advance of the performance of the work by American Gas Log, LLC and must not exceed the retail price of the replacement part.
- Page 21 This page intentionally left blank. American Gas Log, LLC • IM-140 • Rev C 06/2019...
