Product List
타입
제품명
ANYSYNC 4K HDMI (Transmitter)
모델명
Cortex-A7 1.5GHz
DDR3 512MB x2, 1600Mbps, 800MHz fCK
NOR 128MBit
스펙
24MHz, 25MHz, 32.768MHz, 37.4MHz
Wi-Fi 5.2GHz External antenna x1 built in case
Rechargeable Li-Po Battery 3.7V 3,500mA
Assembled HDMI cable 10cm
제품명 : ANYSYNC WU HDMI (Transmitter)
ANYSYNC-WUTH
파생모델 1
차이점 : 메모리 용량 DDR3 256MB x2
제품명 : QuickcastPro 4K HDMI (transmitter)
모델명 : QuickCastPro-4K-HT
파생모델 2
차이점 : 케이스 외형
제조사 – 알엔웨어, 판매사 - Optoma
제품명 : QuickcastPro WU HDMI (transmitter)
모델명 : QuickCastPro-WU-HT
파생모델 3
차이점 : 케이스 외형
메모리 용량 DDR3 256MB x2
제조사 – 알엔웨어, 판매사 - Optoma
Note
This device can be used within 20cm.
1)
2)
this device should be installed and operated with minimum distance 20 cm between the radiator and your body. Ex) Desktop, TV, etc
Transmitter
1)
ANYSYNC-4KTH
ANYSYNC 4K USB-C (Transmitter)
ANYSYNC-4KTU
Cortex-A7 1.5GHz
DDR3 512MB x2, 1600Mbps, 800MHz fCK
NOR 128MBit
24MHz, 27MHz, 32.768MHz, 37.4MHz
Wi-Fi 5.2GHz External antenna x1 built in case
Rechargeable Li-Po Battery 3.7V 3,500mA
Assembled USB Type-C cable 10cm
제품명 : ANYSYNC WU USB-C (Transmitter)
모델명 : ANYSYNC-WUTU
차이점 : 메모리 용량 DDR3 256MB x2
제품명 : QuickcastPro 4K USB (transmitter)
모델명 : QuickCastPro-4K-CT
차이점 : 케이스 외형
제조사 – 알엔웨어, 판매사 - Optoma
제품명 : QuickcastPro WU USB-C (transmitter)
모델명 : QuickCastPro-WU-CT
차이점 : 케이스 외형
메모리 용량 DDR3 256MB x2
제조사 – 알엔웨어, 판매사 - Optoma
Receiver
2)
ANYSYNC 4K (Receiver)
2)
ANYSYNC-4KRH
Cortex-A7 1.5GHz
DDR4 1GB x2, 2400Mbps, 833MHz fCK
eMMC 8GB
24MHz, 32.768MHz, 37.4MHz
Wi-Fi 5.2GHz External antenna x2 built in case
DC 5V External Adaptor
Assembled HDMI cable 10cm
제품명 : ANYSYNC WU (Receiver)
모델명 : ANYSYNC-WURH
차이점 : 메모리 용량 DDR4 512MB x2
제품명 : QuickcastPro 4K (Receiver)
모델명 : QuickCastPro-4K-RX
차이점 : 케이스 외형
제조사 – 알엔웨어, 판매사 - Optoma
제품명 : QuickcastPro WU (Receiver)
모델명 : QuickCastPro-WU-RX
차이점 : 케이스 외형
메모리 용량 DDR3 256MB x2
제조사 – 알엔웨어, 판매사 - Optoma
Advertisement
Summary of Contents for RNware ANYSYNC-4KTH
- Page 1 타입 Transmitter Receiver 제품명 ANYSYNC 4K HDMI (Transmitter) ANYSYNC 4K USB-C (Transmitter) ANYSYNC 4K (Receiver) 모델명 ANYSYNC-4KTH ANYSYNC-4KTU ANYSYNC-4KRH Cortex-A7 1.5GHz Cortex-A7 1.5GHz Cortex-A7 1.5GHz DDR3 512MB x2, 1600Mbps, 800MHz fCK DDR3 512MB x2, 1600Mbps, 800MHz fCK DDR4 1GB x2, 2400Mbps, 833MHz fCK...
-
Page 2: Feature Introduction
Feature Introduction 1. Transmitter HDMI (or USB Type-C) connector Battery indicator Status LED Purple : Booting Purple flash(100ms) : Factory setting mode Transmit button Blue : Ready to play Power button Blue flash(1s) : Playing Blue flash(100ms) : Setting mode : HDMI error flash(1s): Receiver not found flash(300ms): HDMI and Receiver error... - Page 3 Feature Introduction 2. Receiver HDMI connector Status LED : Power on Yellow : Playing (or ready in setting mode) Yellow flash(1s) : Ready to play Yellow flash(500ms) : Setting mode Power LED Setting button USB Type-C Connector for DC 5V power...
- Page 4 Operating guide 1. Receiver installation ① Receiver Connect to HDMI port of display #No data communications ② Input power using 5V2A Adaptor ⑤ Ready to Play ③ Red led is on, Yellow is flash Ready to Play ④ Wait about 25~35 seconds...
- Page 5 Operating guide 2. Transmitter installation and synchronize to Receiver ① Press for 1 seconds to Receiver’s setting button ③ Press and hold the Transmitter’s transmit button Ready to synchronize ④ Press for 5 seconds turn on the power ② Ready to synchronize ⑤...
- Page 6 Operating guide 3. Device's screen transmission ① Transmitter Connect to HDMI or USB Type-C port of Device ② Press for 5 seconds turn on the power ※ already synchronized ③ Blue LED Steady on, ready to Transmit ⑥ Screen mirroring ⑤...
- Page 7 Operating guide 4. Charging the battery ③ Red LED is on, Charging ① Low Battery (<20%) ② Input power using 5V Adaptor ※ already power on state ④ Red LED is off ※ Battery LED indicate High : 80 ~ 100% Middle : 20 ~ 80% Low : 0 ~ 20% ⑤...
-
Page 8: Specification
Specification 1. Transmitter Size : 70mm x 70mm x 28mm (Cable Length. 100mm x 20mm) Weight : 120g Battery : 3500mA, 3.7V Li-ion Polymer Battery Charging Power : DC 5V Operating Temperature : 0°C ~ 40°C Resolution : 720P, 1080P, 1920x1200, 3840x2160(30P) Audio : Mono, Stereo Service life : 5.5~6 hours Video Latency : 200~300ms... - Page 9 Specification 2. Receiver Size : 70mm x 70mm x 28mm (Cable Length. 100mm x 20mm) Weight : 55g Input Power : USB Type-C port, DC 5V / 2A Operating Temperature : 0°C ~ 40°C Resolution : 720P, 1080P, 1920x1200, 3840x2160(30P) Audio : Mono, Stereo Video Latency : 200~300ms Distance : ~ 10m...
- Page 10 Notice Wireless distance can be changed according to user environment. • These products can be in the interference of frequency on using • The screen can be cut when the display aspect is not matched with monitor • Please Turn off the transmitter and receiver when not using products •...
- Page 11 • Those implementing acts shall be adopted in accordance with the advisory procedure referred to in Article 45(2). 5) 2014/53/EU Statement Hereby, RNware declares that the radio equipment type ANYSYNC Transmitter & Receiver is in compliance with Directive 2014/53/EU. - Manufacturer - Distributor ...
