Single Handle Vessel Sink Faucet
Model Number:
5"
3 13/16"
9 1/2"
2"
1 3/8" Hole Size
3/8" Compression Fitting
Features:
BRG01-TB
- Solid Brass Construction
BRG01-TC
- Single Hole Installation
BRG01-TO
- Drip Free Ceramic Cartridge
- Maximum flow rate 1.2 gpm at 60 psi
- Complies with:
13 7/8"
14"
11"
1
NSF 61-9
ANSI / ASME A112.18.1
IAPMO / UPC / cUPC
CA AB-1953
1 7/8"
2 1/8"
Max. Deck Thickness 1 1/2"
BPC01T Rev. 4 09/2016
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Decor Star BRG01-TB
Summary of Contents for Decor Star BRG01-TB
- Page 1 Single Handle Vessel Sink Faucet Model Number: Features: BRG01-TB - Solid Brass Construction BRG01-TC - Single Hole Installation BRG01-TO - Drip Free Ceramic Cartridge - Maximum flow rate 1.2 gpm at 60 psi - Complies with: NSF 61-9 ANSI / ASME A112.18.1...
- Page 2 (2) issue a refund of the purchase price paid for the product (Valid within 30 days from the date of purchase); or (3) issue a credit to be applied against the purchase of a new Decor Star product. Ship- ping/delivery charges may apply and are in Decor Star USA’s sole discretion.
- Page 3 Important Points • This installation guide is subject to change without notice, please contact us to request the most updated version of this installation guide. • This is a general installation guideline, actual installation may vary. Consult a professional if neces- sary.
- Page 4 Installation A. Shut off water supply at the valves. B. Place the new faucet through flange C. From under the sink, install the black Remove old faucet and clean the (8) on the mounting surface. The faucet rubber washer (13), metal washer (14) mounting surface for installation of new hole should be 1 3/8”...
