Kidde Smoke Alarm
User Guide
Photoelectric Smoke Alarm with Voice,
Hardwire Interconnect,
and Wi-Fi Compatibility
Model P4010ACS-WF
wi-Fi ComPATiBiliTY:
This model requires a home Wi-Fi router
and internet to connect to a mobile device.
( Requires 802.11b/g/n (2.4GHz) Wi-Fi )
noTe: wi-Fi features do not function without AC power.
Kidde wi-Fi AlArm
120V HArdwire
10-YeAr BATTerY BACKUP
(AC Power reqUired)
HArdwire inTerConneCT
wi-Fi ComPATiBle
VoiCe AlArm
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KIDDE P4010ACS-WF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Carrier KIDDE P4010ACS-WF

Summary of Contents for Carrier KIDDE P4010ACS-WF

  • Page 1 Kidde Smoke Alarm User Guide Photoelectric Smoke Alarm with Voice, Hardwire Interconnect, and Wi-Fi Compatibility Model P4010ACS-WF wi-Fi ComPATiBiliTY: This model requires a home Wi-Fi router and internet to connect to a mobile device. ( Requires 802.11b/g/n (2.4GHz) Wi-Fi ) noTe: wi-Fi features do not function without AC power.
  • Page 2 Thank You for Purchasing this Wi-Fi Alarm Hardwired for 120VAC, this model features a non-replaceable, sealed-in battery backup. It also contains a voice message system and Hush Control to temporarily silence nuisance alarms. It is capable of hardwire interconnect, and is Wi-Fi compatible with mobile devices. For best Wi-Fi enrollment results, follow these steps: 1.

  • Page 3: Table Of Contents

    Contents 1. Smoke Alarm: What To Do When The Alarm Sounds . 2. Carbon Monoxide Alarm: What To Do When The Alarm Sounds . 3. Other Alarm Visual And Audible Indicators . 4. Troubleshooting Guide . 5. Introduction, Product Features & Specifications 6.

  • Page 4: Smoke Alarm: What To Do When The Alarm Sounds

    1. Smoke Alarm: What To Do When the Alarm Sounds The smoke alarm pattern is three long beeps with voice “Fire!,” a 1.5 second pause, and three long beeps repeating. The red LED blinks in time with the alarm pattern. •...

  • Page 5: Carbon Monoxide Alarm: What To Do When The Alarm Sounds

    2. Carbon Monoxide Alarm: What To Do When the Alarm Sounds NOTE: This is not a carbon monoxide (CO) alarm, but will receive and transmit a CO alarm signal (with voice message) from an interconnected CO or combination smoke / CO alarm.

  • Page 6: Other Alarm Visual And Audible Indicators

    3. Other Alarm Visual and Audible Indicators Operational Mode Visual Indications Audible Indications Action/Note: Normal (standby) AC power: Green LED on continuously during light conditions, or blink every 60 sec during dark conditions. DC power: Green LED blink approx every 60 sec. Test (button press when no •...

  • Page 7: Troubleshooting Guide

    4. Troubleshooting Guide If you are experiencing a problem with your alarm, or a fault, and are unsure of the next action, please contact product support at 1-877-542-5471 before discharging the battery. You may also write us at: Kidde, 1016 Corporate Park Drive, Mebane, NC 27302, or visit our internet address at www.kidde.com.

  • Page 8: Introduction, Product Features & Specifications

    5. Introduction, Product Features and Specifications introduction This alarm detects products of combustion using photoelectric technology. Ten (10) years after the unit was activat- ed, this unit will automatically alert you that it is time to replace the unit. This is called “End of Unit Life” mode. See Troubleshooting Guide.

  • Page 9: Limitations Of Smoke Alarms

    6. Limitations of Smoke Alarms wArninG: PleASe reAd CAreFUllY And THoroUGHlY • Life safety from fire in residential occupancies is based primarily on early notification to occupants of the need to escape, followed by the appropriate egress actions by those occupants. •...

  • Page 10: Recommended Locations For Smoke Alarms

    7. Recommended Locations For Smoke Alarms • Locate smoke alarms in all sleeping areas. Try to monitor the exit path as the bedrooms are usually farthest from the exit. If more than one sleeping area exists, locate additional alarms in each sleeping area. •...
  • Page 11 Note: measurements shown are to the closest edge NFPA 72 states: “Smoke alarms in rooms with ceiling slopes greater than 1 ft in 8 ft (0.3m in 2.4 m) of the alarm. horizontally shall be located on the high side of the room.” NFPA 72 states: “A row of detectors shall be ot within 6 feet of appliances spaced and located within 3 ft (0.9m) of the peak of the ceiling measured horizontally.”...
  • Page 12 • For mobile home installation, select locations carefully to avoid thermal barriers that may form at the ceiling. For more details, see MOBILE HOME INSTALLATION section. • When mounting the alarm on the wall, use an inside wall with the top edge of the alarm at a maximum of 12” (30.5 cm) below the ceiling.

  • Page 13: Locations To Avoid

    8. Locations to Avoid (See Figures 7-A, 7-B, & 7-C for recommended locations) • In the garage. Products of combustion are present when you start your automobile. • Normal cooking may cause nuisance alarms. If a kitchen alarm is desired, it should have an alarm silence feature or be a photoelectric type.

  • Page 14: Wiring Instructions And Mounting Bracket Installation

    9. Wiring Instructions and Mounting Bracket Installation For best Wi-Fi enrollment results, follow these steps: 1. Scan QR code shown in STEP 1 on the front of the Quick Start Guide. Install the Kidde app. 2. Open the Kidde app. Create and login to your account. Tap “Add a device.” Select “Smoke Alarm.” Follow in-app steps.
  • Page 15 • A maximum of 24 Kidde Safety devices may be interconnected in a multiple station arrangement. The intercon- nect system should not exceed the NFPA interconnect limit of 12 smoke alarms and/or 18 alarms total (smoke, CO, Smoke/ CO Combination, heat, etc.). With 18 alarms interconnected, it is still possible to interconnect up to a total of 6 remote signaling devices and / or relay modules.
  • Page 16 noTe: AC power should be turned off at this stage. Alignment Marks • After selecting the proper location for your Alarm, and wiring (”A” Line) on When mounting Mounting in a hallway, Bracket the "A" line should the AC QUICK CONNECT harness as described in the WIRING be parallel with the hallway.
  • Page 17 noTe: Attaching AC power first, without rotating the alarm onto the mounting bracket, will result in a false low battery trouble condition chirp (see Troubleshooting Guide). You need to activate the battery to elimi- nate the low battery trouble condition chirps. Attach unit to mounting bracket very soon after applying AC power to avoid false low battery notification.
  • Page 18 10. Kidde App Features and Instructions For best Wi-Fi enrollment results, follow these steps: 1. Scan QR code shown in STEP 1 on the front of the Quick Start Guide. Install the Kidde app. 2. Open the Kidde app. Create and login to your account. Tap “Add a device.” Select “Smoke Alarm.” Follow in-app steps.

  • Page 19: Installation, Activation, And Wi-Fi Enrollment

    11. Installation, Activation, and Wi-Fi Enrollment For best Wi-Fi enrollment results, follow these steps: 1. Scan QR code shown in STEP 1 on the front of the Quick Start Guide. Install the Kidde app. 2. Open the Kidde app. Create and login to your account. Tap “Add a device.” Select “Smoke Alarm.” Follow in-app steps.

  • Page 20: Adding Another Device To An Existing Wi-Fi Alarm Network

    B. Open the Kidde App and follow instructions on the App to finish Wi-Fi enrollment. noTe: If no further steps are taken within 15 minutes of initial power up, a voice prompt, “Not Connect- ed” will be heard once, and the Wi-Fi function will turn off. The unit will then perform as a standard hardwired alarm.

  • Page 21: Resetting A Device's Wireless Settings

    11.3 Resetting a Device’s Wireless Settings If you encounter an issue at any point during the Wi-Fi enrollment process, you may reset the device by following the directions below. noTe: wi-Fi features do not function without AC power. “Resetting wireless settings.”...

  • Page 22: Operation And Testing

    12. Operation and Testing operation The alarm is operating once it is activated and testing is complete. When products of combustion (smoke) are sensed, the unit sounds a loud alarm with voice messages. (See Sections 1 and 2 for alarm signal descriptions). Testing imPorTAnT: Retail canned smoke products vary by manufacturer and produce inconsistent results.

  • Page 23: Recognizing Nuisance Alarms

    13. Recognizing Nuisance Alarms Smoke nuisance HUSH : If you know why the alarm is sounding, and you can verify that it is not a life threatening situation, you can push the button on the initiating unit (green LED flashing every second) to silence the alarm for 8-10 minutes. If the smoke is not too dense, that unit, and all interconnected units will silence.

  • Page 24: Permanently Disable Alarm / Discharge Battery

    15. Permanently Disable Alarm / Discharge Battery wArninG: FAilUre To diSCHArGe AlArm BATTerY AS inSTrUCTed Prior To diSPoSAl mAY CreATe PoTenTiAl For liTHiUm BATTerY relATed Fire or HAzArd. wArninG: diSCHArGinG THe AlArm BATTerY iS PermAnenT • Once the alarm battery has been discharged, it cannot be reactivated! •...

  • Page 25: Cleaning Your Alarm

    16. Cleaning Your Alarm Your Alarm Should be Cleaned at least once a Year You can clean the interior of your alarm (sensing chamber) by using compressed air or a vacuum cleaner hose and blow- ing or vacuuming through the openings around the perimeter of the alarm. The outside of the alarm can be wiped with a damp cloth.

  • Page 26: Good Safety Habits

    17. Good Safety Habits develop and Practice a Plan of escape Prepare and practice a home escape plan twice a year, including drills at night. Know two ways out of every room (door & window) and identify a meeting place outside the home where everyone will gather once they have exited the resi- dence.
  • Page 27 Smoke detection – Are more Alarms desirable? For your information, the National Fire Protection Association’s Standard 72 reads: Where required The required number of smoke alarms might not by other governing laws, codes, or standards for provide reliable early warning protection for those areas a specific type of occupancy, approved single and multiple-station smoke alarms shall be installed as separated by a door from the areas protected by the...
  • Page 28 FCC (Contains FCC id: 2AC7z-eSPwroom32Ue) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 29: Service And Warranty

    18. Service and Warranty Ten-Year limited warranty Kidde warrants that the enclosed alarm will be free from defects in material and workmanship or design under normal use and service for a period of ten years from the date of purchase. The obligation of Kidde under this warranty is limited to repairing or replacing the alarm or any part which we find to be defective in material, workmanship or design (part replacement only, no installation), free of charge, upon receiving the alarm with proof of date of purchase, postage and return postage prepaid, to Warranty Service Department, Kidde, 1016 Corporate Park Drive, Mebane, NC 27302.
  • Page 30 For more inFormATion Call Kidde Product Support line at 1-877-542-5471 or contact us at www.kidde.com Kidde 1016 Corporate Park Drive, Mebane, NC 27302 Kidde’s General Privacy Notice can be found at: https://www.corporate.carrier.com/legal/privacy-notice/ A Carrier Company ©2022 Carrier. All Rights Reserved.
