MOUNT PRO PR1008 Instruction Manual

Single monitor desk stand
Hide thumbs

Advertisement

Quick Links

Download this manual
Single Monitor Desk Stand
Instruction Manual
PR1008
If you have any questions , please contact us via: help@ohopeglobal.com
32"
75x75
100x100
8kg/17.6lbs
V1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the PR1008 and is the answer not in the manual?

Questions and answers

Related Manuals for MOUNT PRO PR1008

Summary of Contents for MOUNT PRO PR1008

  • Page 1 Single Monitor Desk Stand Instruction Manual PR1008 32" 75x75 100x100 8kg/17.6lbs If you have any questions , please contact us via: help@ohopeglobal.com V1.0...

  • Page 2: Package Contents

    WARNING! If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product, contact Customer Service via help@ohopeglobal.com. Before starting assembly, verify all parts are included and undamaged. Improper installation may cause damage or serious injury.

  • Page 3: Assembly Steps

    ASSEMBLY STEPS STEP 1 Use the 4mm Allen Key (H) to tighten the screws (G) into the pole (D) from the bottom of the base (C).
  • Page 4 STEP 2 Slide the cable clip (E) onto the pole(D). Slide the mounting bracket (B) onto the pole(D). Tighten the mounting bracket (B) on the pole(D) using a 6mm Allen Key (I)
  • Page 5 STEP 3 OPTION A: Flat Back Monitor For flat back monitor, secure VESA plate (A) to monitor using screws (M-A or M-C) and washers (M-E). CAUTION:To select the correct bolts(M-A or M-C) for your monitor, you can try to screw it on your monitor by hand.
  • Page 6 STEP 4 Slide monitor with VESA plate onto mounting bracket. Secure with thumbscrew (F).
  • Page 7 STEP 5 Tighten or loosen tilt joint using 6mm Allen Key (I). STEP 6 Manage cables with installed cable clip (E).
  • Page 8 STEP 7 Store 4mm Allen Key (H) and 6mm Allen Key (I) in cable clip (E). STEP 8 Adjust monitor position and rotation. 90° +45° 360° -45° Note: When tilted, if the monitor sags or does not stay, please fasten the tilting bolt on the mount until the monitor can be held at any angle as needed.

  • Page 9: Product Dimensions

    Product Dimensions 90° ±180°...
  • Page 12 CAUTION AND MAINTENANCE: • Never allow children to climb, stand, hang, or play on any part of monitor or stand. • This product is intended for indoor use only. Using this product outdoors could lead to product failure and personal injury. •...
