Table of Contents

USER MANUAL
ELECTRIC THERMOSTAT
COUNTERTOP GRIDDLE
MODEL:
SR-EG24-208, SR-EG24-240,SR-EG36-208,
SR-EG36-240,SR-EG48-208,SR-EG48-240,
USR Brands, Inc.
Phone: 800-764-1172 | www.usrestaurant.com | sales@usrestaurant.com
USRESTAURANT® RESERVES THE RIGHT TO CHANGE SPECIFICATIONS WITHOUT NOTICE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STANDARD RANGE SR-EG24-208 and is the answer not in the manual?

Questions and answers

Summary of Contents for Usr STANDARD RANGE SR-EG24-208

  • Page 1 USER MANUAL ELECTRIC THERMOSTAT COUNTERTOP GRIDDLE MODEL: SR-EG24-208, SR-EG24-240,SR-EG36-208, SR-EG36-240,SR-EG48-208,SR-EG48-240, USR Brands, Inc. Phone: 800-764-1172 | www.usrestaurant.com | sales@usrestaurant.com USRESTAURANT® RESERVES THE RIGHT TO CHANGE SPECIFICATIONS WITHOUT NOTICE...

  • Page 2: Attention Owners And Operators

    Attention Owners and Operators Equipment is designed to provide safe and productive processing, cooking and warming of food products as long as the equipment is used in accordance with the instructions in this manual and is properly maintained. Unless the operator is adequately trained and supervised there is a possibility of serious injury.

  • Page 3: Installation

    INSTALLATION The griddles are designed to operate only for the voltages indicated on the dataplate attached to this griddle, and for alternating current (AC) only. WARNING DO NOT CONNECT TO DIRECT CURRENT (DC). The installation of the electric griddle should conform to the: NATIONAL ELECTRIC CODE AND ALL LOCAL ELECTRIC CODES AND ORDINANCES AND THE LOCAL ELECTRIC COMPANY RULES AND REGULATIONS.

  • Page 4: Maintenance And Repair

    TEMPERATURE CONTROL The temperature controls are combination “ON/OFF” switches and thermostats. Turning the dial knob automatically maintains the selected heat range. Thermostat controls the section of the griddle above it and may be set at different temperatures. COOKING Set the thermostat dial knob at the temperature desired. After a short pre-heating period, the thermostat will automatically maintain the selected temperature.

  • Page 5: Electrical Diagrams

    ELECTRICAL DIAGRAMS USRESTAURANT® RESERVES THE RIGHT TO CHANGE SPECIFICATIONS WITHOUT NOTICE...
  • Page 6 ! WARNING: This device should be safely and adequately grounded in accordance with local codes, or in the absence of local codes, with the National Electrical code, ANSI/NFPA 70, Latest Edition to protect the user from electrical shock. It requires a grounded system and a dedicated circuit, protected by a fuse or circuit breaker of proper size and rating.

  • Page 7: Exploded View

    Exploded view Part Q’ty Part Q’ty Griddle plate Temperature Probe bracket 1/2/3/4 Side plate Heating element 1/2/3/4 Side interior plate Rear plate Indicator 1/2/3/4 Terminal connection box Knob 1/2/3/4 Terminal cap Thermostat 1/2/3/4 Heating element clamp 1/2/3/4 Panel Adjustable foot Front interior plate Grease Drawer Bottom plate...
