ACCESSORY Note There are these accessories in the carton, the style will be different according to the product model. BM4*20 (X6) Quick installation manual Tipping prevention materials -4 -...
4PCS of type M6x10mm screws are required (the length of the screws fixed in the interior of the TV should not be longer than 12mm) Recommend to use SONIQ wall mount and install by professional people (do not operate while the TV is on).
CONTROL BUTTON The following is only functional schematic, And the actual position and arrangement of differect models may be different. Some models has 5 buttons, some models has 7 buttons. Remote control sensor. Indicator LED: RED STANDBY. Key board STANDBY STANDBY Middle key In the standby state, press the STANDBY button to turn on the TV;...
AV Audio channel. Yellow (video) Red (audio R) White(audio L) Red(Pr or Cr) Blue(Pb or Cb) Green(Y) VIDEO EQUIPMENT with YPbPr HDMI Router network interface Optical input HDMI SONIQ does not supply VIDEO EQUIPMENT these cables.
REMOTE CONTROLLER The remote controller cannot be used unless it is within the receivable range. Before you use the remote control, please make sure there's no obstacle between the remote control and the receiver. Open the battery cover and insert 2 "AAA" batteries. Point the remote control at the remote sensor located on the unit.
Page 11
launches the built-in virtual assistant. -9 -...
Page 17
Inputs HDMI 3 Picture HDMI 3 HDMI 2 Contrast HDMI 2 Saturation HDMI 1 HDMI 1 Composite Sharpness Composite Gamma Component Middle Component Consumer Electronic Control(CEC) Color Temperature HDMI control Advanced Video Allow the TV to control HDMI devices Reset to Default -15-...
SPECIFICATIONS Viewing Picture Size (Diagonal) 58inch Resolution 3840x2160 Aspect Ratio 16 : 9 TV System PAL-B/G, SECAM-B/G, DVB-T, DVB-C Video Signal System P AL/NTSC/SECAM Receiving Channel DVB-T:1000, DVB-C:1000, ATV:99 Input Power Voltage 100-240V~, 50/60Hz Power consumption 160 W Audio Output Power THD 7% 2 x10W Signal input/output High-Definition Multimedia Interface(HDMI) x4...
Page 24
AUSTRALIA : www.soniq.com/au/contact-us NEW ZEALAND : www.soniq.com/nz/contact-us...
