Assembly Instructions & User's Manual
for
Members Mark Hastings 5pc Gas Fire Pit Set
Item Number:
Model Number: ACE00422-5SC
Customer Assistance
: 1-800-416-3511
(spare/replacement parts)
or Email: customerservice@agio-usa.com
THIS ASSEMBLY MANUAL CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Page 1
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Member's Mark Hastings 5pc Gas Fire Pit Set ACE00422-5SC
Summary of Contents for Member's Mark Hastings 5pc Gas Fire Pit Set ACE00422-5SC
- Page 1 Assembly Instructions & User's Manual Members Mark Hastings 5pc Gas Fire Pit Set Item Number: Model Number: ACE00422-5SC Customer Assistance : 1-800-416-3511 (spare/replacement parts) or Email: customerservice@agio-usa.com THIS ASSEMBLY MANUAL CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Page 1 Need Assistance? Visit us at: samsclub.com/membersmarkhelp...
-
Page 2: Table Of Contents
Table of Contents Quality Statement.............3 Important Safety Information..........3 Before Assembly..............3 Package Contents............4 Product Information............5 Spring Rocker Components..............6 Hardware..............6 Tools................6 Step1................7 Fire Pit Components...............8 Hardware..............8 Tools................8 Step1-Step7............9-11 Care & Use and Storage Instructions........12 Warranty Information............12 Page 2 Need Assistance? Visit us at: samsclub.com/membersmarkhelp... -
Page 3: Quality Statement
Quality Statement Important Safety Information Please read all instructions carefully before assembling this furniture. For your safety, assembly by two or more adults is strongly recommended. Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the structural integrity of the item. Hardware may loosen overtime. -
Page 4: Package Contents
Package Contents 1Set / 3Ctn Box 1 of 3： Component Description Quantity Spring Rocker Box 2 of 3： Component Description Quantity Firepit Base Fire Ice Furniture Cover Box 3 of 3： Component Description Quantity Firepit Table Top Burner Cover Page 4 Need Assistance? Visit us at: samsclub.com/membersmarkhelp... -
Page 5: Product Information
Product information Weight Factory Description Part No. Dimensions Capacity Assembly Spring Rocker 250lb per seat ACE00422 26" W *31 5" D *35" H A.Foot Cap FC0607 Weight Factory Description Part No. Dimensions Capacity Assembly Firepit Table ARW09200 45.75" RD *24.5" H A.Foot Cap FC0553 Description... -
Page 6: Components
Components CHAIR FRAME BASE & ROCKER ASSEMBLY Part No.AR20624 Part No.AR20625 Qty 1 Qty 1 Hardware (H1) (H2) (H3) 5/16" X 42 MM BOLT Ø8.0 X 2.3 MM SPRING WASHER "U" METAL PLATE PART NO:HW0931 PART NO:HW0003 PART NO:HW0644 Qty: 4 Qty: 4 Qty: 2 (H4) -
Page 7: Step1
Step 1 (H1) (H2) (H3) 5/16" X 42 MM BOLT Ø8.0 X 2.3 MM SPRING WASHER U" METAL PLATE Qty: 4 Qty: 4 Qty: 2 (H4) (H6) (H7) 5/16" NUT HEX WRENCH-1 HEX WRENCH-2 Qty: 1 Qty: 1 Qty: 4 CAUTION: Failure to place the “U”... -
Page 8: Components
Components A. FIRE PIT TABLE TOP B FIRE PIT TABLE BASE BURNER COVER Part No.FP3135 Part No. FP3136 Part No. FP3137 Qty 1 Qty 1 Qty 1 D. BURNER PAN PROTECTIVE FIRE ICE RING Part No. FP2147 Part No. FP3138 Qty 1 Qty 1 Hardware... -
Page 9: Step1-Step7
Step 1 - Step 7 Step 1 There are three factory assembled M4 screws in the firepan/burner assembly. Remove those three screws in order to remove the burner pan protective ring. Step 2 (H17) (H19) (H16) Ø20 X Ø6.5 X 2.0 MM HEX BOLT DRIVER 1/4"... - Page 10 Step 3 Place the burner pan protective ring, into the burner as shown in the diagram . Secure the burner pan protective ring to the burner pan by using three M4 screws. (H10) M4 BOLT Qty: 3 (H18) HEX BOLT DRIVER Qty: 1 NOTE: Bolts must be FULLY tightened.
- Page 11 Step 6 Open the door and place the LP tank in the bottom frame. Connect the regulator. Turn the black handle clockwise to tighten. Turn the handle counterclockwise to remove. The hose must point down. Open the control door and check that the valve is turned all the way clockwise to the “OFF”...
-
Page 12: Care & Use And Storage Instructions
Care & Use Instructions CARE AND MAINTENANCE FRAMES Cleaning - Use mild soap and warm water. Do not use abrasive materials, cleansers or bleach products. Rinse with clean water and dry thoroughly. Maintenance - Periodically clean and dry thoroughly. Be sure to drain any water accumulated inside the frames. - Page 13 Distributed by Sam's West Inc. 2101 SE Simple Savings Dr. Bentonville, Arkansas 72716-0745 Made in China Page 13 Need Assistance? Visit us at: samsclub.com/membersmarkhelp...
