QWM1900
Wireless microphone system
863.0 - 865.0 MHz
(Channel 70)
UHF 863.00 - 865.00 MHz frequency band
SMT technology
Preset 16 channel PLL system
Frequency stabilisation: < ±30ppm
Dynamic range: > 100dB
Total harmonic distortion: < 0.5%
Frequency response: 40Hz-15KHz ±3dB
Power consumption: 100mA
Signal to noise ratio : > 100dB
Image & spurious rejection: > 80dB
Border upon channel rejection: > 80dB
Receiving sensitivity: 5dBuV (SINAD=30dB)
De-emphasis: 50us
4 different q-audio QWM1900 kits available:
Hand held mic system | Wireless headset system | Bodypack system | Instrument/guitar bug system
For the latest instruction manual updates an d information on the entire Q-audio range visit:
www.q-audio.co.uk
Telephone: (+44) (0) 203 598 5164 • Email: info@q-audio.co.uk • Web: www.q-audio.co.uk
If this product is ever no longer functional please take it to a recycling plant for environmentally friendly disposal.
Due to continuous product development, specifications and appearance are subject to change. © Copyright Q-Audio. E&OE.
Advertisement
Related Manuals for Q-Audio QWM1900
Summary of Contents for Q-Audio QWM1900
- Page 1 Telephone: (+44) (0) 203 598 5164 • Email: info@q-audio.co.uk • Web: www.q-audio.co.uk If this product is ever no longer functional please take it to a recycling plant for environmentally friendly disposal. Due to continuous product development, specifications and appearance are subject to change. © Copyright Q-Audio. E&OE.
-
Page 2: Manufacturer Declarations
Thank you for purchasing this Q-Audio product, we are sure that it will serve you for many years to come. To optimise the performance of this product, please read these operating instructions carefully to familiarise yourself with the basic operations of this unit. Please retain them for future reference. This unit has been tested at the factory before being shipped to you. - Page 3 Q-Audio QWM 1900 features Uses the UHF 863.00 - 865.00MHz band Automatic frequency scan searches for available frequencies PLL system, preset 16 non-interference channels SMT technology The receiver uses one 1.5V AA battery The hand held microphone uses a single 1.5V AA battery...
- Page 4 Pairing the receiver with your transmitter (handheld mic or headset or bodypack or guitar bug) 1. Open the receiver’s battery cover and insert a single 1.5V AA battery. 2. Insert the correct battery (or batteries) in the transmitter (handheld mic or headset or bodypack or guitar bug). 3.
- Page 5 3. Power switch 4. Battery compartment cover 5. ACT IR 6. Battery compartment Features of the QWM1900 headset microphone (if supplied with your system) 1. Power switch 2. Antenna 3. ACT IR (shown with battery cover removed) 4. Battery compartment 5.
- Page 6 Features of the QWM1900 guitar bug (if supplied with your system) 1. Battery compartment 2. Antenna 3. Power switch 4. 15dB pad switch 5. ¼ inch jack instrument insert 6. Power supply LED indicator 7. ACT IR (not shown) Features of the QWM1900 bodypack (if supplied with your system) 1.
-
Page 7: Specification
Specification Comprehensive performance UHF 863.00 - 865.00MHz Less than ±30ppm Carrier frequency More than 100dB Frequency stabilisation Less than 0.5% Dynamic range 40Hz-15KHz ±3dB Total harmonic distortion Mix type: 0-±400mV Frequency response Audio output level 100mA Fixed receiver More than 100dB Consume power More than 80dB Signal/noise ratio...
