- Page 1 All manuals and user guides at all-guides.com Instruction Manual STVG529BK/W Please read before using this unit. The Singing Machine® is a registered trademark or The Singing Machine Co., Inc.
-
Page 2: Important Safety Information
Warnings All manuals and user guides at all-guides.com WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE CAUTION THIS UNIT TO RAIN OR MOISTURE. RISK OF ELECTRIC SHOCK FCC WARNING: This equipment may generate or use radio frequency DO NOT OPEN energy. -
Page 3: Front View
CONTROL LOCATIONS All manuals and user guides at all-guides.com FRONT VIEW CD Door Monitor REPEAT Button PLAY/PAUSE Button PROGRAM Button STOP Button SKIP Button SKIP Button ON/OFF Button ECHO Control BALANCE Control Monitor ON/OFF Button MIC Holder MIC holder MIC Volume Control MASTER Volume Control ON/OFF LED... -
Page 4: Connecting The Power
All manuals and user guides at all-guides.com DISPLAY TRK 01/18 PROG 00:16:04 P P L L A A Y Y I I N N G G T T I I M M E E R R E E P P E E A A T T M M O O D D E E - - R R E E P P E E A A T T O O N N E E - - R R E E P P E E A A T T A A L L L L - - N N O O R R E E P P E E A A T T F F U U N N C C T T I I O O N N... -
Page 5: Connecting To Your Tv
2. Connect the RCA video cable (Yellow) to the VIDEO OUT jack and the audio cables (White and Red) to the AUDIO OUT jacks located on the back of the Singing Machine. 3. Connect the opposite end of the RCA video cable (Yellow) to the VIDEO IN jack and the audio cables (White and Red) to the AUDIO IN on your TV. -
Page 6: Turning On/Off
OPERATION All manuals and user guides at all-guides.com This unit is designed to play CDs and CD+Gs bearing the identification logo respectively. If the disc does not conform to the standard, it may not play properly. TURNING ON/OFF To turn on the unit, press the ON/OFF button, the ON/OFF LED indicator will light To turn it off, press the ON/OFF button again, the ON/OFF LED indicator will turn off. -
Page 7: Karaoke Functions
OPERATION (continued) All manuals and user guides at all-guides.com REPEAT To repeat the track currently playing, press the REPEAT button once. The REPEAT ONE ( ) indicator will light up. To repeat all tracks, press the REPEAT button twice. The REPEAT ALL ( ) indicator will light up. -
Page 8: Care And Maintenance
Care and Maintenance All manuals and user guides at all-guides.com Care for Compact Discs Treat the compact disc carefully. Handle the compact disc only by its edges. Never allow your fingers to come in contact with the shiny, unprinted side of the compact disc. Do not attach adhesive tape, stickers, etc. -
Page 9: Troubleshooting Guide
CD compartment. Moisture has formed inside the Wait about 20 to 30 minutes to let it CD deck. dry out. The Singing Machine needs to be Power the system OFF and disconnect the machine from electrical outlet for reset. 30 seconds. - Page 10 All manuals and user guides at all-guides.com TROUBLESHOOTING GUIDE (continued) PROBLEM POSSIBLE CAUSE SOLUTION Lyrics do not appear on Video cable is not connected Follow direction in the “ the TV screen properly to the TV. CONNECTIONS” section. TV does not have video line input. Connect from AV OUT of Singing Machine to the VIDEO IN on your TV.
-
Page 11: Audio Section
All manuals and user guides at all-guides.com SPECIFICATIONS AUDIO SECTION OUTPUT POWER (MAXIMUM) ..................5 Watts (RMS) OUTPUT IMPEDANCE.........................8 Ohms CD PLAYER SECTION FREQUENCY RESPONSE.....................100Hz - 20kHz SIGNAL-TO-NOISE RATIO ....................50dB (A-WTD) NUMBER OF PROGRAMS............20 Step Random Access Programming SAMPLING SYSTEM ....................8 Times Over Sampling AUX IN SECTION ...................3.5mm Stereo Headphone Jack MICROPHONE......-73 db 600 Ohm Impedance with 6.3mm Dynamic Microphone POWER SECTION....................DC 12V... - Page 12 All manuals and user guides at all-guides.com Visit Our Website: www.singingmachine.com The Singing Machine Company, Inc. 4060 E. Jurupa St. Unit B Ontario, CA 91761 USA © 2014 PRINTED IN CHINA 529-1406-ENG01...
