Floating Shelves Instruction Manual
Thank you for choosing this STORAGEGEAR product! At STORAGEGEAR we
strive to provide you with the best quality products and services in the industry.
Should you have any issues, please don't hesitate to contact us at
support_us@storagegearclub.com.
IMPORTANT SAFETY INFORMATION
• Check package contents against supplied parts and hardware list to assure that all
components were received undamaged. Do not use damaged or defective parts. lf you
require replacement parts, please contact STORAGEGEAR customer service at
support_us@storagegearclub.com.
• Carefully read all instructions before attempting installation. If you do not understand the
instructions or have any concerns or questions, please contact customer service at
support_us@storagegearclub.com.
• Not all parts and hardware included will be used.
• Using with caution because this product may contain moving parts.
• Do not use this product for any purpose that is not explicitly specified in this manual. Do
not exceed weight capacity. We cannot be liable for damage or injury caused by improper
mounting, incorrect assembly or inappropriate use. Thank you for your understanding.
Model: STFS01
V1.0
Advertisement
Table of Contents
Related Manuals for STORAGEGEAR STFS01
Summary of Contents for STORAGEGEAR STFS01
- Page 1 Floating Shelves Instruction Manual V1.0 Model: STFS01 Thank you for choosing this STORAGEGEAR product! At STORAGEGEAR we strive to provide you with the best quality products and services in the industry. Should you have any issues, please don't hesitate to contact us at support_us@storagegearclub.com.
- Page 2 Tools Needed (Not lncluded) 5/64 in.(2mm) 15/64 in.(6mm) Stud Finder Screwdriver Drill Level Pencil Wood Drill Concrete Drill Supplied Parts and Hardware List Metal Frame Towel Rack Screw with Shelf Long Lag Screw Short Lag Screw M4x50mm M4x30mm Wall Anchor Wall Anchor CAUTION! CAUTION!
- Page 3 Installation Locations for the Floating Shelves Note: 1. For the convenience to fetch something, please leave proper distance between the two floating shelves before installation. 2. If you want to install the two floating shelves vertically, please install the the floating shelf with towel rack under the floating shelf withoiut towel rack and leave a proper distance between the two floating shelves.
- Page 4 Step 1 Secure the Towel Rack [02] to the Shelf on the Metal Frame [01] Secure the towel rack [02] to bottom of the shelf using four short screws [03]. Step 2 Secure Metal Frame with Shelf to Wall Before installation, please identify your wall type. For wood stud installation, follow the step 2A.
- Page 5 Position the metal frame with shelf at your desired height and line up the holes with your stud center line. Level the shelf and mark the holes. 2 in.(50mm) ø5/64 in.(ø2mm) For Long Lag Screw [Not Included] [Optional] WARNING: For wood stud mounting, wall anchors [C] and [D] are not necessary.
- Page 6 Step 2B For Drywall Position the metal frame with shelf [01] at your desired height and make sure the metal frame with shelf [01] is level and flush to the drywall. Mark the holes for the wall anchors [C]. Press and screw wall anchors [C] into the drywall using a screwdriver and turn clockwise.
- Page 7 Step 2C For Solid Concrete and Concrete Block Walls Position the metal frame with shelf [01] at your desired height and make sure the metal frame with shelf [01] is level and flush to the solid concrete and concrete block walls. Mark the holes for the wall anchors [D].
- Page 8 Use the hammer to knock wall anchors [D] into the wall. Be sure the anchors [D] are seated flush with the concrete surface. Install the metal frame with shelf [01] using short lag screws [B] and wall anchors [D], tighten short lag screws [B] until they are pulled firmly against the metal frame.
