SERVICE MANUAL
EN
ORIGINAL LANGUAGE
For other languages of this service manual as well as additional
product information, please scan the QR code above.
SB-81-012-R1 (12/2022)
TC-UV-01
TRU-CURE UV HANDHELD
(904000 FOR USA)
(NORTH AMERICA)
TRU-CURE UV HANDHELD
TC-UV-02
(UNITED KINGDOM)
TRU-CURE UV HANDHELD
TC-UV-03
(EUROPE)
1 / 12
www.carlisleft.com
Advertisement
Table of Contents
Summary of Contents for Carlisle Fluid Technologies Trisk DeVILBISS Tru-Cure UV-LED
- Page 1 SERVICE MANUAL ORIGINAL LANGUAGE TC-UV-01 TRU-CURE UV HANDHELD (904000 FOR USA) (NORTH AMERICA) TRU-CURE UV HANDHELD TC-UV-02 (UNITED KINGDOM) TRU-CURE UV HANDHELD TC-UV-03 (EUROPE) For other languages of this service manual as well as additional product information, please scan the QR code above. SB-81-012-R1 (12/2022) 1 / 12 www.carlisleft.com...
- Page 2 EC Declaration of conformity Hedson Technologies AB Box 1530 SE-462 28 VÄNERSBORG Sweden declare under our sole responsibility that the product TRU-CURE UV-LED to which this declaration relates, is in conformity with the following standards: EC Declaration of conformity According to testing institutes and according to the machine directive the IRT products in this manual are not defined as machines wherefore the machine directive reference cannot be included in this declaration.
- Page 3 SE 462 28 Vänersborg Sweden declare under our sole responsibility that the products Trisk Devilbiss TRU-CURE UV-LED to which this declaration relates, is in conformity with the following standards: UKCA Declaration of conformity According to testing institutes and according to the machine directive the IRT products in this manual are not defined as machines wherefore the machine directive reference cannot be included in this declaration.
- Page 4 In this part sheet, the words WARNING, CAUTION and NOTE are used to emphasize important safety information as follows: WARNING NOTE CAUTION Hazards or unsafe practices which Hazards or unsafe practices which could result in severe personal Important installation, operation or could result in minor personal injury, injury, death or substantial property maintenance information.
- Page 5 TRU-CURE UV-LED – SAFETY READ ALL INSTRUCTIONS BEFORE USING “TRU-CURE UV LED”. WHEN USING ELECTRICAL EQUIPMENT, BASIC PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING: WARNING WARNING UV RADIATION TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY: UV radiation can cause personal injury and property damage! UV emitted from •...
-
Page 6: Electrical Data
TRU-CURE UV-LED – GENERAL INFORMATION INTENDED USE OF THE PRODUCT ELECTRICAL DATA This Tru-Cure UV-LED unit should be used only to Tru-Cure Battery Battery activate curing of UV-activated putty, filler and base UV-LED charger materials. Tru-Cure UV-LED may not be used for other Battery type Lithium-ion Lithium-ion... -
Page 7: Battery Charge Indicator
0:58 00:59 01:00 TRU-CURE UV-LED – OPERATING INSTRUCTIONS 01:00 01:00 00:59 01:00 CODE: XX PRODUCT DESCRIPTION BATTERY CHARGE INDICATOR The Tru-Cure UV-LED is a hand-held appliance, battery- operated and equipped with a LED module which emits UV and visible light. It is available in wavelength 395 nm, refering to the peak. - Page 8 MARKINGS / MAINTENANCE MARKINGS MAINTENANCE 34,5 PROTECTIVE GLASS Overlay Part no. 413109 Clean the protective glass with a microfiber cloth to make sure all light reaches the object. NOTE Solvents are not allowed. FILTER Clean or replace the filter (no. 5 in chapter 3.1) twice a year or when needed.
-
Page 9: Battery Troubleshooting
01:00 01:00 01:00 00:58 00:59 01:00 BATTERY / TROUBLESHOOTING BATTERY STORAGE TROUBLESHOOTING Remove the battery from the curing device and charger High temperature / Overheating CODE: XX when not in use to ensure a longer life time. Battery Indicator Display: CHANGING/REMOVING THE BATTERY 01:00 01:00... -
Page 10: Spare Parts
Rev. Change no Change description Rev. by Appr. by Appr. date SPARE PARTS Only original spare parts shall be used to maintain the products high safety. PART PART NO. DESCRIPTION 410-0000 GLASSES WITH UV PROTECTION 990000 (USA) Draft 410-0001 FILTER 990001 (USA) 410-0002 FILTER CAP... -
Page 11: Battery Charger
BATTERY CHARGER OPERATION Check if the local main AC voltage level is suitable for the charger. MINIMAL MAXIMAL AC input Voltage INDICATION • Plug the main cable of the charger into an AC main socket. The green LED (1) and the red LED (2) will flash once. -
Page 12: Warranty Policy
This product is covered by Carlisle Fluid Technologies’ materials and workmanship limited warranty. The use of any parts or accessories, from a source other than Carlisle Fluid Technologies, will void all warranties. Failure to reasonably follow any maintenance guidance provided may invalidate any warranty.
