SLPU-2P1U1C1S-WL-BK

ELECTRICAL

2 × TR AC Receptacle, rated 15A，125Vac

1x USB-A (Rated 5Vdc, 3.1A)

1x USB-TYPE C port

(Rated 5Vdc, 3.1A 9Vdc, 2A / 12Vdc, 1.5A)

Wireless 3-way switching,controls the rear

receptacle for LED light ﬁxtures.

10' AC cord & plug (ﬂat plug standard)

8" rear/side exiting cord with receptacle.

MECHANICAL

Recessed mounting

CERTIFICATION

FCC compliant and UL Listed

WARRANTY

5 Years

SELF Electronics USA Corporation

3264 Saturn Ct,Peachtree Corners,GA 30092

Dimmension(inches/mm)

7-12/16"(197)

Installation

Cut hole size:

7.40"×2.09"(188mm×53mm)

Tel: +1-770-248-9023

POWER UNIT

2-1/8"(54)

salesus@self-electronics.com

Table of Contents

Need help?

Do you have a question about the SLPU-2P1U1C1S-WL-BK and is the answer not in the manual?

Questions and answers

Summary of Contents for SELF SLPU-2P1U1C1S-WL-BK

Page 1 10' AC cord & plug (ﬂat plug standard) 8" rear/side exiting cord with receptacle. MECHANICAL Recessed mounting Installation CERTIFICATION Cut hole size: 7.40"×2.09"(188mm×53mm) FCC compliant and UL Listed WARRANTY 5 Years SELF Electronics USA Corporation 3264 Saturn Ct,Peachtree Corners,GA 30092 Tel: +1-770-248-9023 salesus@self-electronics.com...
Page 2 POWER UNIT 3-way Switching Function (for SLPU-2P1U1C1S-WL-NI/SLPU-2P1U1C1S-WL-WH/SLPU-2P1U1C1S-WL-BK ONLY) Pairing Press power unit’s start button more than 3 seconds, Power on the blue indicator beside button starts ﬂashing, Power unit enters paring mode. Repeat same operation to another power unit. ﬂashing ﬂashing...
Page 3 10' AC cord & plug (ﬂat plug standard) 8" rear/side exiting cord with receptacle. MECHANICAL Recessed mounting Installation CERTIFICATION Cut hole size: 7.40"×2.09"(188mm×53mm) FCC compliant and UL Listed WARRANTY 5 Years SELF Electronics USA Corporation 3264 Saturn Ct,Peachtree Corners,GA 30092 Tel: +1-770-248-9023 salesus@self-electronics.com...
Page 4 POWER UNIT 3-way Switching Function (for SLPU-2P1U1C1S-WL-NI/SLPU-2P1U1C1S-WL-WH/SLPU-2P1U1C1S-WL-BK ONLY) Pairing Press power unit’s start button more than 3 seconds, Power on the blue indicator beside button starts ﬂashing, Power unit enters paring mode. Repeat same operation to another power unit. ﬂashing ﬂashing...
Page 5 10' AC cord & plug (ﬂat plug standard) 8" rear/side exiting cord with receptacle. MECHANICAL Recessed mounting Installation CERTIFICATION Cut hole size: 7.40"×2.09"(188mm×53mm) FCC compliant and UL Listed WARRANTY 5 Years SELF Electronics USA Corporation 3264 Saturn Ct,Peachtree Corners,GA 30092 Tel: +1-770-248-9023 salesus@self-electronics.com...
Page 6 POWER UNIT 3-way Switching Function (for SLPU-2P1U1C1S-WL-NI/SLPU-2P1U1C1S-WL-WH/SLPU-2P1U1C1S-WL-BK ONLY) Pairing Press power unit’s start button more than 3 seconds, Power on the blue indicator beside button starts ﬂashing, Power unit enters paring mode. Repeat same operation to another power unit. ﬂashing ﬂashing...
