Summary of Contents for CSS SR2501GT

  • Page 1 User Manual SR2501GT Reader Document Revision 02...
  • Page 2 General Specifications The SR2501GT reader is equipped with a dot-matrix display for visual information, keypad for user inputs, and a single push button. Below is the picture of the SR2501GT reader: The general specification of the SR2501GT reader is as follows:...
  • Page 3 Installation At the back of the reader, there is a cable lead with four wires. They are arranged as follows: Colour Function DC +5V Black DC 0V Yellow Signal + for RS485 Orange Signal – for RS485 Brown Signal RXD for RS232 Green Signal TXD for RS232 For mounting the reader onto a wall, remove the dark cover in front of the reader.
