ASSEMBLY AND MOUNTING INSTRUCTIONS

GENERAL

• WARNING-DISCONNECT POWER BEFORE RELAMPING OR
WIRING THE FIXTURE. TURN OFF THE ENTIRE ELECTRICAL
CIRCUIT TO WHICH THE LIGHTING FIXTURE IS ATTACHED
• INSTALLATION AND MAINTENANCE OF THIS FIXTURE
SHOUILD BE COMPLETED BY A LICENSED ELECTRICAN
FAILURE TO INSTALL FIXTURE CORRECTLY COULD
•
RESULT IN SERIOUS INJURY OR DEATH
• READ ALL INSTRUCTIONS BEFORE STARTING

INSTALLATION.

INSTALLATION
STEP 1. Pull the wires out from the outlet box, and install mounting
plate onto the outlet box using the (2) mounting screws.
Strip the fixture wires ½" long at the ends.
STEP 2. Fasten bare ground wire to ground wire from the wall outlet
box (usually green or copper color) or connect ground wire
to green screw on the mounting plate.
STEP 3. Connect the neutral (white) fixture wire coming from the
fixture base to neutral (usually white) outlet wire. Fasten
both wires together with a plastic wire nut and tightly wrap
the wire nut with electrical tape.
STEP 4. Repeat the previous step with the hot (black wires). Make
sure there are no exposed wires or strands that could
cause a dangerous short circuit.

DIMMING

The fixture can be controlled by a wall dimming device. Only use
triac/electronic dimmer. Make sure carton is marked for use with LED
compact fluorescent-incandescent light source only. These can be

CLEANING

Please clean with a soft, dry cloth ONLY! Do not use cleaning products.
www.hudsonvalleylighting.com/mitzi| #mymitzi
H417603 JENNA FLUSH MOUNT
• IF AN EXISTING FIXTURE IS BEING REPLACED, REMOVE IT
AND NOTE TO WHICH WIRE IN THE OUTLET BOX THE
ORIGINAL FIXTURE WAS ATTACHED.
• BEFORE DISCARDING THE CARTON DOUBLE CHECK THE
PACKAGING TO MAKE SURE ALL PARTS HAVE BEEN
FOUND.
• THIS FIXTURE WAS DESIGNED TO BE MOUNTED TO AN
OCTAGON OUTLET BOX. THE BOX MUST BE SECURELY
MOUNTED TO THE STRUCTURE OF THE BUILDING.
FAILURE TO CONNECT THE APPROPRIATE WIRES
CORRECTLY COULD RESULT IN SEROIUS INJURY OR
DEATH!
STEP 5. Carefully place connections back into the outlet box.
STEP 6.
Lift the canopy up over the mounting plate and secure with
mounting nuts.
STEP 7. Install the lamps. The fixture is rated for 60 watt type G25
lamp.
DO NOT EXCEED RECOMMENDED WATTAGE!
STEP 8.
Attach the glass to the socket then secure with ball nuts.
STEP 9. Restore power to the circuit at breaker or fuse box.
provided by your local electrical distributor, home center, or hardware
store.
