Summary of Contents for ASI three 60
- Page 1 Single-Use Aseptic Sampling System INSTRUCTIONAL MANUAL Three60 Valve Instructions Pinch and Cut Disconnect Instructions L ife Sciences...
- Page 2 Step 1: Installation of Unit • Remove sample system from sterile package. • Apply a gasket, Three 60 unit and clamp to flange interface of your vessel (1 ½” sanitary connector or a NA port). • Position valve with white depressible tab pointing upward and the turn arrow pointing clockwise for easy push and turn operations.
- Page 3 Step 2: Start Sampling • When you’re ready to take a sample, slightly depress tab feature and begin to turn main body clockwise. CAUTION: Excessive pressure on the tab may cause damage and compromise the locking action. • Once the turn is initiated, release the tab; the tab will lock when the open position is reached.
- Page 4 PINCH AND CUT DISCONNECTION The Pinch and Cut Disconnection is the answer to the industry’s need for a simple method of sealing and disconnecting a tube. With only the operator’s hands, the device will pinch the tube closed, seal the tube ends and “cut” them apart; thus enabling a quick disconnection of the sample bag.
- Page 5 THREE60 SAMPLING SYSTEM INSTRUCTIONS |...
- Page 6 THREE 60 SINGLE-USE ASEPTIC SAMPLING SYSTEM TAKING A SAMPLE MADE TO BE SIMPLE The simple design behind the three60 Sampling System allows you to take a representative sample of your product with minimal effort. For a completely sterile transfer, use a CIP or SIP process to prepare your tank.
