Deluxe Bottom-Loading
Water Dispenser
with Self-Cleaning
Rated Power: 520W
Voltage: 115V
Frequency: 60Hz
Version A-0 12-2021
USER MANUAL
Free 3 months
extension
original limited warranty
period!* Simply text a
picture of your proof of
purchase to:
1-844-224-1614
*The warranty extension is for the
three months immediately following
the completion of the product's
original warranty period.
Model Numbers CWB412ASB
of the
Advertisement
Related Manuals for Comfee CWB412ASB
Summary of Contents for Comfee CWB412ASB
- Page 1 Simply text a picture of your proof of purchase to: 1-844-224-1614 *The warranty extension is for the three months immediately following the completion of the product’s original warranty period. Model Numbers CWB412ASB Version A-0 12-2021...
-
Page 2: Table Of Contents
TABLE OF CONTENTS page Safety information----------------------------------------------------------------------------------------- Installation and safety precautions-------------------------------------------------------------------- Part name---------------------------------------------------------------------------------------------------- Dispensing water ------------------------------------------------------------------------------------------ Deep cleaning----------------------------------------------------------------------------------------------- Trouble shooting-------------------------------------------------------------------------------------------- Technical parameters ------------------------------------------------------------------------------------- 1 Year limited warranty ----------------------------------------------------------------------------------- WARNING ELECTRICAL REQUIREMENTS A 115 V, 60 Hz, AC only, 15 A or 20 A fused, grounded electrical supply is required. -
Page 3: Safety Information
SAFETY INFORMATION FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN DEATH, FIRE OR ELECTRICAL SHOCK. WARNING To reduce the risk of injury and property damage, user must read this entire guide before assembling, installing and operating water dispenser. WARNING Failure to execute the instructions in this manual can cause personal injury or property damage. - Page 4 DO NOT place water dispenser inside an enclosed space or cabinet. DO NOT operate water dispenser in the presence of explosive fumes. Water dispenser must be position no closer than 8” (20 cm) from wall to permit free airflow between wall and back of dispenser. There must be at least 8”...
- Page 5 WARNING To prevent the water dispenser from tipping, please install the enclosed two safety brackets. Loosen the two screws on the back lower left and right side of the water dispenser. (Refer to illustration on right.) Slide safety bracket under the loose screw and secure the safety bracket to the water dispenser by tightening the screws.
-
Page 6: Installation And Safety Precautions
INSTALLATION AND SAFETY PRECAUTIONS LOCATE DISPENSER NOTE: If the unit has been on its side for a long period of time, place the water dispenser in the upright position for more than 24-hours before turning it on. Place dispenser upright. Locate dispenser on a hard and level surface and in a cool shaded location, near a grounded outlet. - Page 7 PLUG INTO A GROUNDED ELECTRICAL OUTLET Plug power cord into a properly grounded wall outlet. At this time, you will hear the water pump turn on and start filling the water reservoirs with water. It will take approximately 4 to 5 minutes to fill the water reservoirs for the first time.
-
Page 8: Part Name
PART NAME Part Description Part Description Top Cover Drip Tray Hot Water Dispense Button Hot Water On/Off Switch Room Temp. Dispense Button Cold Water On/Off Switch Cold Water Dispense Button Nightlight On/Off Switch Cooling ON Indicator Light Power Supply Cord Drain Outlet Heating ON Indicator Light Self-Cleaning Indicator Light... -
Page 9: Dispensing Water
DISPENSING WATER This unit has been tested and sanitized prior to packing and shipping. During transit dust and odors can accumulate in the tank and lines. Dispense and dispose at least one quart of water prior to drinking any water. Dispensing Cold Water After set-up, it will take 1-hour to get water to the maximum cold water temperature. - Page 10 Empty Water Bottle Indicator Flashing Do not dispense water if the empty water bottle indicator WARNING is flashing, doing so may cause the hot water to overheat and cause damage to the hot water heater. The Hot and Cold water indicator lights will flash together when the water bottle is empty.
-
Page 11: Deep Cleaning
Use the Self-Cleaning Ozone Feature It is highly recommended that you use self-cleaning feature on weekly basis to clean tanks and water lines. To activate the self-cleaning cycle, press in the self-cleaning switch(15), hold for 5 seconds, and release. The power indicator light on the front of the dispenser will begin blinking, indicating the cleaning process is underway. - Page 12 Rinsing, Cleaning, and Draining To prolong the lifetime of the machine, it is recommended that the unit be cleaned and sanitized manually about every six months. To clean the outside of the unit Use a disinfectant of your choice to wipe down the outside of the machine. Disinfectant does not come with this unit.
- Page 13 Once water is completely drained, reposition the drain cover, cold tank cover and the top cover. Ensure that the pipes and wires are connected properly and you may use the dispenser as normal. Cleaning： To remove mineral deposits from the water system, mix 1-gallon of water with 200 grams of citric acid crystals (not included) or a citric acid cleaning solution of your choice.
-
Page 14: Trouble Shooting
TROUBLE SHOOTING Suggested Solution Problem Possible Cause Drain outlet is not secure. Tighten drain cap Water dispenser is leaking Internal water leak. Unplug and replace unit Empty water bottle. Replace empty water bottle Activate the child safety lock by Water dispenser is Child safety lock (hot water) sliding the red lock button to the not dispensing water... -
Page 15: Technical Parameters
TECHNICAL PARAMETERS MODEL CWB412ASB Hot Water Capacity 1 gallon/hr Hot Tank Volume Cold 1/3 gallon Water Capacity Cold 2/3 gallon/hr Tank Volume 1 gallon Package Dimensions 15.2" x 14" x 43.9" inch Refrigerant R134a/36g(1.27oz) 1.6MPa(232psig) High Side Low Side 0.62MPa(90psig)
